ABB

CHOPPER CONTROL BOARD

Model Number:NBRC-61C (61357246F)
Type:Chopper Control Board
Operating Voltage:24V DC (±10%)
Power Consumption:8W (typical)
Signal Levels:0-10V analog, 24V digital
Isolation Voltage:1500V AC (input-to-output)
PWM Frequency:2kHz (adjustable)
Current Regulation:±1% of setpoint
Response Time:<5ms (90% step change)
Resolution:12-bit (analog signals)

EXTENSION I/O BOARD

contains more channels
16 binary inputs
8 binary outputs
8 analog inputs
4 analog outputs
Time out setting by software
Watchdog function

Central Processing Unit

processor module
128 kBmemory
8 DI, 6 DO-T,24 V DC
onboard Ethernet
with pluggable I/O terminalblocks

Control Unit

Processor:Dual-core 1.2GHz
Memory:2GB DDR3 RAM
Storage:8GB Flash
Execution Speed:10ms cycle time (typical)
Operating Voltage:24V DC (±10%)
Power Consumption:15W (typical)
Isolation Voltage:1500V AC (field to system)

Optical fiber board

Fiber Type:Multi-mode (62.5/125μm)
Wavelength:850nm/1300nm
Data Rate:1Gbps (1000BASE-SX)
Connector Type:Duplex LC
Transmission Distance:Up to 550m (MMF)
Operating Voltage:5V DC (±5%)
Power Consumption:3.5W (typical)
Interface:PCI Express

Panel Controller

Control Circuit Voltage: 24V DC (±15%)
Analog inputs :0–10V, 4–20mA
Temperature: -10°C to +50°C (derate 2% per °C above 40°C)
Humidity: <95% non-condensing

Station- Bus Coupler Module

88TK05C-E
Procontrol P14
Station- Bus Coupler Module
GJR2393200R1210

DIGITAL OUTPUT CARD

DSTD110A
DIGITAL OUTPUT CARD
Connection Unit for
Digital Output Board
32 channels, max 60 V

Interface module

9 different coil voltages
DC versions: 12 V, 24 V, 48 V, 110 V
AC versions: 24 V, 48 V, 110 V, 120 V, 230 V
Output contacts:
1 c/o contact (16 A) or
2 c/o contacts (8 A)

Control board card

HIEE300888R0002
UAC389 AE02
Pulse Amplifier Interface module

IGBT Module

Rated Voltage (V_CEO): 600 V
Collector Current (I_C): 60 A (continuous)
Peak Collector Current (I_Cpeak): 120 A (pulsed)
Gate-Emitter Threshold Voltage (V_GE(th)): 4.0 V (typical)
Input/Output Signal Voltage: 15 V / 15 V
Max Power Dissipation (P_diss): 200 W (maximum)

MEASUREMENT UNIT BOARD

HIEE300890R0001
LD MUB-01
UAC383 AE01
MEAS. UNIT BOARD

Inverter IGBT trigger board

Input Voltage:+24V DC
Turn-On Voltage: +15V ±0.5V
Turn-Off Voltage: -8V to -15V
Switching Frequency:Up to 10–20 kHz
Optical Isolation: ≤2500 V RMS
Operating Temperature: 0°C to +70°C
Storage Temperature: -40°C to +85°C

CIRCUIT BOARD

Supply Voltage:24V DC (±10%)
Power Consumption:<10W (typical)
Processor:32-bit microcontroller
Memory Flash: 8MB+, RAM: 4MB+
Operating Temp.:-25°C to +70°C
Humidity:5–95% RH (non-condensing)

Processor module

Display Type:LCD
Communication Interface:Serial/FBP/Ethernet
Memory Size:9728 kB
Memory Size User Data:5632 2 kB
Memory Size User Program:4096 2 kB
Memory Type User Data:RAM
Controller Processing Time:0.000002 ms
Degree of Protection:IP20
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

Gate Unit Power

3BHB005243R0105
GATE UNIT POWER SUPPLY
(KUC755 AE105)

INTERFACE BOARD

3BHE004573R0143 UFC760 BE143
control board
0-10V, 4-20mA
Isolation:1500V AC

Analog Input Module

Series: UDC920 Series
Input Voltage Range:0-10V, 4-20mA
Input Current: 4-20mA, 0-20mA, or 0-24mA.
Input Resistance:250Ω to 500Ω for 4-20mA
Resolution: 12 to 16 bits
Signal Types:4-20mA
Operating Temperature Range:-20°C to +60°C
Storage Temperature Range: -40°C to +85°C
Humidity Range: 5% to 95% relative humidity

ADCVI-BOARD

Voltage Input Range: ±10 V
Current Input Range: 4–20 mA
ADC Resolution: 12-bit or higher
Sampling Rate: Up to 10 kHz per channel
Voltage: >1 MΩ
Current: 250 Ω
Supply Voltage: 24 VDC ±10%
Power Consumption: <15 W

Subcategory Fan

FAN
230VAC
50/60HZ
1.31/1.45AMP
300/330WATT
2050/2550MIN-1
8UF
400VDB

CONTROL UNIT

CONTROL UNIT
DRIVE CONTROL ASSEMBLY
SCREW CLAMP TERMINALS
WITH COMMS ADAPTER PORT
(3AUA0000036521)

CONTROL UNIT KIT

CONTROL UNIT KIT
ACS800 MD DriveSecti CONTROL UNIT KIT
Power Supply: 24 VDC ±10%
Digital Inputs: 8x
Analog Inputs/Outputs: 0–10 VDC or 4–20 mA
Operating Temperature: 0°C to +55°C

2-port Ethernet adapter

Power Supply:
Typically 24 V DC
Range: Typically -10°C to +55°C
Storage Temperature: Typically -40°C to +70°C

LONG-LIFE FAN

D2D160CE0211
LONG-LIFE FAN
CENTRIFUGAL COOLING FAN ASSEMBLY
230/400V
700/1055W
50/60 HZ
1.9/2.82 AMP
(64650424)

IGCT Module

Blocking Voltage : 4500V
Maximum Repetitive Off-State Voltage:4500V
Gate Trigger Voltage (VGT): 1.5V–2.5V
Peak Surge Current (ITSM): 25–30kA
Critical Rate of Current Rise (di/dt): 1kA/µs
Turn-On Time (ton): <5µs
Turn-Off Time (toff): <10µs
Switching Frequency: Up to 500Hz
