ABB

Analog Input Module

Series: UDC920 Series
Input Voltage Range:0-10V, 4-20mA
Input Current: 4-20mA, 0-20mA, or 0-24mA.
Input Resistance:250Ω to 500Ω for 4-20mA
Resolution: 12 to 16 bits
Signal Types:4-20mA
Operating Temperature Range:-20°C to +60°C
Storage Temperature Range: -40°C to +85°C
Humidity Range: 5% to 95% relative humidity

HVD Board

Series: XV Series
Voltage Rating: 380V to 690V AC
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range:-40°C to +85°C
Humidity Range: Generally supports 5% to 95%

Control board

Voltage Rating: 24 V DV
Operating Temperature: -10°C to +50°C
Storage Temperature: -25°C to +70°C.
Humidity Tolerance: 5% to 95%

Gate Driver Board

Operating Temperature Range:-40°C to +85°C
Voltage Rating (IGBT Voltage):up to 1700 V
Gate Drive Voltage:  15 V

ADCVI-BOARD

Voltage Input Range: ±10 V
Current Input Range: 4–20 mA
ADC Resolution: 12-bit or higher
Sampling Rate: Up to 10 kHz per channel
Voltage: >1 MΩ
Current: 250 Ω
Supply Voltage: 24 VDC ±10%
Power Consumption: <15 W

Subcategory Fan

FAN
230VAC
50/60HZ
1.31/1.45AMP
300/330WATT
2050/2550MIN-1
8UF
400VDB

CONTROL UNIT

CONTROL UNIT
DRIVE CONTROL ASSEMBLY
SCREW CLAMP TERMINALS
WITH COMMS ADAPTER PORT
(3AUA0000036521)
