SDCSDSL4
COMMUNICATION BOARD
DCS-LINK DRIVE-TO-DRIVE
DEDICATED TO THE DCS800
BASED ON CAN BUS.
THIS COMMUNICATION ADAPTER IS USED IN
12-PULSE OPERATION
AND COMMUNICATION /
CONTROL OFEXTERNAL FIELD SUPPLIES
DCF803-0035
THIS BOARD IS STANDARD IN AL
Series: SDCS
Operating Voltage: Typically 24V DC
Power Consumption: 5-10 W
Current Consumption: 200-400 mA
Operating Temperature Range: -20°C to 70°C (-4°F to 158°F)
Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)
Enclosure: Plastic
Mounting: Onto a standard mounting rail
Settings: Via drive interface (control panel)
Current Consumption: 70 mA at 24 V d.c
All materials are UL/CSA approved
Complies with EMC Standards EN 50081-2 and EN 50082-2
Power Supply :24 V DC
Module Type : NETA-01 V1.x
Mounting: On to a standard mounting rail
Settings : Through drive parameters and/or DIP switches
Current consumption: 80 mA at 24 V DC ±10%
3 digital inputs
3 + 1 digital outputs
DDCS communication link
+24 VDC (500 mA) to supply auxiliary equipment
isolated firing pulses
voltage measurements
Uc (DC busbar voltage)
Uac (supplyvoltage), synchronisation
heatsink temperature measurement
current measurement
earth fault current measurement
7-segment display
Input Signal Types: Voltage (0-10V, ±10V)
Accuracy: ±0.1% of full scale
Output Resolution: 12-bit or 16-bit
Output Load Resistance: 500Ω max
Voltage Supply Range: 24V DC nominal
Power Consumption: < 10 W
Operating Temperature:-20°C to +60°C
Storage Temperature:-40°C to +85°C
Differential push-pull HTL encoders
Single-ended push-pull HTL encoders
Open collector HTL encoders
Open emitter HTL encoders
+15 V DC ± 20% 200mA (max.)
+24 V DC ± 20% 200mA (max.)
Power Supply Voltage: 24 VDC ± 10%
Power Consumption: Typically less than 2 W
Resolver Excitation Voltage: 4-8 V RMS
Resolver Frequency Range: 2 kHz to 15 kHz
Input Channels: 1 Resolver input
Resolution: 12-bit to 16-bit resolution depending on configuration
Accuracy: ±0.05 degrees
Output voltages:
+5.5 V DC -5%, -8%, 180 mA
+24 V DC ±15%, 150 mA
Maximum cable length:
30 m with a 5 V encoder
(0.5 mm2 cable for power supply)
CH A, CH B, CH Z, CH U, CH V, CH W: RS-422/485,
Device used for controlling andprogramming
Can be attached directly to
the module ordoor of the cabinet
The keys are flat, labeled push-buttons
LCD display: 4x20 characters
Input Voltage: 24V DC
Current Consumption: 100-500mA
Power Rating: Usually around 5-10W
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% non-condensing
