ABB

Reverse Conducting Thyristor IGCT

Reverse Conducting Integrated Gate-Commutated Thyristor
VDRM = 4500 V ,ITGQM = 3600 A ,ITSM = 20·10³ A
VT0 = 1.24 V , rT = 0.51 mΩ ,VDC = 2800 V
Mounting force 41kN
High snubberless turn-off rating
Optimized for medium frequency
High electromagnetic immunity
Simple control interface with status feedback
AC or DC supply voltage
Option for series connection

Printed Circuit Board

Layer Count:4-layer PCB
Material:FR-4 (Flame Retardant)
Copper Weight:1 oz/ft² (35μm)
Operating Voltage:24V DC (±10%)
Power Consumption:15W (max)
Input Channels:8 analog (16-bit resolution)
Output Channels:6 digital (2A max)
Isolation Voltage:2500V AC

CHOPPER CONTROL BOARD

Model Number:NBRC-61C (61357246F)
Type:Chopper Control Board
Operating Voltage:24V DC (±10%)
Power Consumption:8W (typical)
Signal Levels:0-10V analog, 24V digital
Isolation Voltage:1500V AC (input-to-output)
PWM Frequency:2kHz (adjustable)
Current Regulation:±1% of setpoint
Response Time:<5ms (90% step change)
Resolution:12-bit (analog signals)

Analog Control Module

Operating Voltage:24V DC (±10%)
Power Consumption:6W (typical)
Input Channels:16 digital (24V)
Output Channels:8 relay (5A @ 230V AC)
Isolation Voltage:1500V AC (field to logic)
Processor:32-bit RISC
Clock Speed:100MHz
Memory:2MB Flash, 512KB RAM
Scan Time:1ms (typical)

EXTENSION I/O BOARD

contains more channels
16 binary inputs
8 binary outputs
8 analog inputs
4 analog outputs
Time out setting by software
Watchdog function

Central Processing Unit

processor module
128 kBmemory
8 DI, 6 DO-T,24 V DC
onboard Ethernet
with pluggable I/O terminalblocks

Control Unit

Processor:Dual-core 1.2GHz
Memory:2GB DDR3 RAM
Storage:8GB Flash
Execution Speed:10ms cycle time (typical)
Operating Voltage:24V DC (±10%)
Power Consumption:15W (typical)
Isolation Voltage:1500V AC (field to system)

Optical fiber board

Fiber Type:Multi-mode (62.5/125μm)
Wavelength:850nm/1300nm
Data Rate:1Gbps (1000BASE-SX)
Connector Type:Duplex LC
Transmission Distance:Up to 550m (MMF)
Operating Voltage:5V DC (±5%)
Power Consumption:3.5W (typical)
Interface:PCI Express

Bus Coupling Module

Processor Module

Operating Voltage Range:  24 V DC
Current Consumption:  500 mA to 1 A
Operating Temperature:  0°C to 60°C
Storage Temperature:  -20°C to 70°C

Panel Controller

Control Circuit Voltage: 24V DC (±15%)
Analog inputs :0–10V, 4–20mA
Temperature: -10°C to +50°C (derate 2% per °C above 40°C)
Humidity: <95% non-condensing
