ABB

Power Board

Input Voltage:24V DC (±10%) or 115/230V AC
Output Voltages:+5V, ±15V, +24V DC
Power Capacity:100W (max)
Inrush Current:15A (for 20ms at 230V AC)
Efficiency:>90% (at full load)
Fiber-Optic Signal Isolation :2500V AC

Drive Board +IGBT Module

Voltage Rating:1700V
Current Rating:450A (continuous)
Max Junction Temp.:150°C
Switching Frequency:Up to 5kHz
Gate Drive Voltage:+15V/-5V
Isolation Voltage:2500V RMS
Power Consumption:25W (typical)
Protection Response:<2μs (short-circuit)

Pulse Transformation Board

Power Supply:24 V DC
Differential: ±12 V.
Power consumption: < 5 W
Single-ended: 0–24 V
Output Voltage:
TTL: 0–5 V.
HTL: 0–24 V

Drive power board

Input Voltage:3-phase 380-480V AC (±10%)
Output Voltages:+24V DC (control)
Power Capacity:500W (continuous)
Switching Frequency:20kHz (PWM)
Efficiency:>92% (at full load)

Control board

Input Voltage:24V DC (±10%)
Power Consumption;25W (typical)
Isolation :1500V AC (field to logic)
Vector control
Torque/speed regulation
PID controllers
Communication;Ports 2x Ethernet, 1x RS-485

Interface Board

Input Voltage:24V DC (±10%)
Power Consumption:8W (typical)
Isolation Voltage:1500V AC (channel-to-channel)
Communication Speed:Up to 1Mbps
Signal Channels:16 digital I/O

Interface Board

Input Voltage:24V DC (±10%)
Power Consumption:12W (max)
Isolation Voltage:2500V AC (channel-to-bus)
Input Current :5mA @ 24V DC
Voltage Range:0-30V DC

PCB Board

Input Voltage:24V DC (±10%)
Power Consumption:15W (typical), 20W (max)
Isolation:1500V AC
Processor:32-bit RISC
Clock Speed:800MHz
Memory:512MB DDR3 RAM, 1GB Flash
Real-Time Clock:Battery-backed (CR2032)
Communication Interfaces:2x Ethernet, 1x RS-485

AIR FLOW SENSOR

AIR FLOW SENSOR
0.04 AMP
24 V

IGBT Inverter Module

Voltage Rating:1200V
Current Rating:300A (continuous)
Max Junction Temp.:150°C
Switching Frequency:Up to 20kHz
Gate Drive Voltage:+15V/-5V
Isolation Voltage:2500V RMS
Protection Features:DESAT, UVLO, OT
Response Time:<2μs (short-circuit)

Cooling Fan

Voltage Rating:24V DC (±10%)
Current Draw :0.8A (max)
Power Consumption:19.2W
Startup Voltage:≤18V DC
Airflow:340 CFM (5.7 m³/min)
Static Pressure:120 Pa
Speed:3200 RPM (±10%)
Noise Level:55 dB(A) at 1m

Input/Output Unit

Power Supply:24V DC (±10%)
Power Consumption:8W (typical)
Response Time:<1ms (input), <0.5ms (output)
Surge Protection:30V DC
Channels:16x digital
Voltage Range:24V DC (±10%)
Current Rating:5mA (min)
Isolation :1500V AC

PCB CARD

Input Voltage:24V DC (±10%)
Power Consumption:15W (typical)
Processor:32-bit RISC @ 800MHz
Memory:512MB RAM, 2GB Flash
Real-Time Clock:Battery-backed (10-year life)
I/O Capacity:Supports up to 512 I/O points

BRANCHING UNIT

Rated Voltage:690V AC
Current Rating:44A continuous
Short-Circuit Capacity:50kA (1s)
Power Connections:4-in/8-out configuration
Isolation Voltage:3000V AC

Circuit Board

Operating Voltage:24V DC (±10%)
Power Consumption:2W (typical)
Signal Range:0–24V DC, 4–20mA
Resolution:12–16-bit
Short-Circuit Protection:Self-resetting fuse

Compact and powerfulautomatic voltage regulators

Excitation current  5 A cont., 10 A
ceiling@ 70° C ambient temp.
Digital:4 outputs, 8 inputs
Analog:2 outputs
Mechanicals:IP20
Certifications:CE, DNV/GL, Traction

Control panel

ACS580 CONTROL PANEL
Assistant control panel
Protection Class:IP54 (Front Panel)
MTBF:>150,000 hours
Display Type:LCD (Backlit)
Resolution:128 x 64 Pixels
Languages:Multi-language support
Keypad:Membrane/Sealed (Dustproof)

Voltage Drive Circuit Board

POWER MASTER BOARD
VOLTAGE DRIVE CROWBAR CIRCUIT BOARD
Input Voltage:24V DC (±10%)
Output Voltage:0-10V (Programmable)
Current Rating:2A (Max Continuous)
Frequency Range:0-400Hz
Isolation Voltage:1500V AC

Automatic Voltage Regulators

Maximized operating time
Ensures safe machine operation
Guarantees the quality of delivered energy
Seamless integration with the power plant control systems

AC500 Communication module

Function:PROFIBUS master
Communication Protocol:PROFIBUSMaster
Communication Interface:Serial
Number of Hardware Interfaces:RS-485 1
Data Transmission Rate:12000 kbit/s
Degree of Protection:IP20

Rechargeable lithium-ion battery

Rechargeable lithium-ion battery
3.7V, 2,4Ah
Non-restricted
Common recommendations for storage of Li-ion batteries
are at -20° to 25° C and to charge the batteries once
per year to 40% (or 3.75V/cell) of their capacity and
never let them discharge to below 2.0V

88TK05 Station- Bus Coupler Module

Supply Voltage:24V DC (±15%)
Power Consumption:1.8W (typical)
Interface:9-pin D-Sub
Bus Termination:Integrated
Bus Protocol:PROFIBUS DP (EN 50170)
Transmission Rate:9.6Kbps to 12Mbps
Address Range:0-125
Max Number of Slaves:125
Electrical Isolation:500V AC

Inverter Circuit Board

Model Number:AGPS21C (64668064)
Type:SACS800 Inverter Circuit Board
Input Voltage Range:85-264V AC (47-63Hz)
Output Voltage:24V DC (±1%)
Output Current:5A (continuous)
Power Rating:120W
Efficiency:>88%
Inrush Current:<30A (at 230V AC)

Inverter Memory Card

Memory Type:Flash EEPROM
Storage Capacity:2MB
Write Cycles:100,000 cycles
Interface:Proprietary ABB connector
Operating Voltage:3.3V DC (supplied by drive)
Power Consumption:<50mA
ESD Protection:±8kV contact discharge

Asymmetric Thyristor IGCT

Asymmetric Integrated GateCommutated Thyristor
VDRM = 4500 V , ITGQM = 4000 A
Mounting force 40kN
High snubberless turn-off rating
Optimized for medium frequency
High electromagnetic immunity
Simple control interface with status feedback
AC or DC supply voltage
Option for series connection
