ABB

PEC80 Converter Signal Int

Input Voltage Range: 24V DC
Operating Voltage: 15–30V DC
Current Consumption: 50–200 mA
Isolation Voltage: ≥500V
Analog inputs: ±10V, 4–20mA
Digital inputs :TTL/relay contact

Controller I/O Module

Supply Voltage: 24V DC
Power Consumption: 2–5W
Isolation: 500V AC
Voltage: 24V DC
Switching Frequency: Up to 1 kHz
Range: 0–10V, ±10V, 4–20mA
Resolution: 16-bit (high precision)
Accuracy: ±0.1% FS (full scale)

Control Board

Supply Voltage: 24V DC
Isolation: 500V AC
CPU: 32-bit industrial
Clock Speed: 100–200 MHz
Memory Flash: 8–16 MB
Digital I/O:2–4 channels

Converter Electronics

CONVERTER
POWER CONTROL UNIT
UNS 3670A-Z V1
Input Voltage Range: 380-480V AC
DC Link Voltage: 510-650V DC
Output Power Rating: 15-30kW
Frequency Range: 50/60Hz ±10%
Efficiency: >95%
Switching Frequency: 2-8kHz

Conduction Monitoring Coil

Rated Current: 50A to 5000A
Frequency Range: 50/60Hz ±10%
Output Signal: 0-5V or 4-20mA
Accuracy Class: 1% or better
Phase Shift: <3° at rated current

Three-phase voltage relay

Rated Voltage: 100-480V AC
Frequency Range: 45-65Hz
Input Impedance: >100kΩ per phase
Burden: <0.2VA per phase
Measuring Accuracy: ±1% of set value or ±0.5V
Voltage Unbalance: 5-30% of Un
Contact Rating: 5A @ 250V AC/DC

Flame Controller

Flame Signal Input: 1 or 2 UV
Sensitivity Range: Adjustable 0.1-100μA flame current
Power Supply:100-240V AC ±10%, 50/60Hz
Power Consumption: ≤5VA
Relay Outputs:2-4 SPDT (Form C) relays
Analog Output: 4-20mA flame strength signal

Amplifier Board

Input Voltage Range: ±10V
Output Voltage Range: ±10V
Current Output: 0-20mA / 4-20mA
Gain Range: 1 to 1000
Bandwidth: DC to 10kHz (-3dB)
Input Impedance: >1MΩ
Output Impedance: <100Ω
Common Mode Rejection Ratio (CMRR): >80dB @ 60Hz
Noise Level: <10μV RMS (1Hz to 10kHz)

Universal Input Module

Number of Channels: 8
Voltage: 0–10V
Current: 0–20mA, 4–20mA
Resolution: 16-bit
Sampling Rate: 10 samples/sec per channel
Common-Mode Rejection (CMRR): >120 dB @ 50/60 Hz
Voltage Mode: >1 MΩ
Current Mode: 250 Ω

Gate Driver Board

Input Voltage Range: 15-30V DC
Output Drive Voltage: +15V/-8V
Peak Output Current: ±20A
Isolation Voltage: 2500V AC
Propagation Delay: <100ns
Compatible IGBTs: 1200V-1700V
Gate Resistor Range: 1-10Ω
Input Signal: TTL/CMOS compatible

Control Module

Operating Voltage: 24V DC (±10%)
Power Consumption: 5–10W
Isolation: 1500V AC
CPU: 32-bit RISC-based processor
Clock Speed: 100–200 MHz
Memory Flash:16–32 MB
Digital I/O: 24V DC

Circuit Board

Supply Voltage: 24V DC (±10%)
Power Consumption: 15W (typical)
Operating Current: 0.5-1A
Isolation Voltage: 2000V AC
Main Processor: 32-bit DSP or microcontroller
Clock Speed: 100-200MHz

IGCT MODULE

Voltage Rating:4500V (VCES)
Current Rating:4000A (IT(RMS))
Max. Turn-off Current:6000A (ITGQM)
On-State Voltage Drop:1.85V (typical @ 4kA)
Switching Frequency:Up to 500Hz
Gate Driver Voltage:±20V (isolated)

Power supply module

Input Voltage Range:85-264V AC (47-63Hz)
Output Voltage: 24V DC (±1% regulation)
Output Current: 10A
Power Rating: 240W
Inrush Current: <30A (at 230V AC)
Overvoltage Protection: 28V DC
Overcurrent Protection: 110-130% of rated current
Line Regulation: ±0.5% (85-264V AC)
Load Regulation: ±1% (20-100% load)

Driver board

Model Number: UF C911B108 3BHE037864R0108
Input Voltage: 24V DC
Output Voltage: Adjustable based on application requirements
Operating Temperature: -20°C to 70°C (-4°F to 158°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Humidity Range: 5% to 95% (non-condensing)

Communications I/O Module

Supply Voltage: 24V DC (±10%)
Power Consumption: 3.5W (typical)
Primary Protocol: Profibus DP
Data Rate: 9.6kbps to 12Mbps
Connector Type: 9-pin D-sub
Isolation: 1500V AC
Digital Inputs: 8 channels

Communications I/O module

Supply Voltage:24V DC (±10%)
Power Consumption:4W (typical)
Inrush Current:<15A (20ms)
Backplane Current:500mA max
Output Isolation:3000V AC
Data Rates:9.6 kbps – 12 Mbps
Connector:9-pin D-sub (RS-485)
Address Range:0–126
Isolation:1500V AC

Exciter Control Module

Supply Voltage: 110/220V AC ±10%
Power Consumption: ≤15W
Generator current: 0-5A AC (CT input)
Field voltage: ±200V DC
Field current: ±5V DC
Response Time: <20ms for 95% step response

Control Board

Supply Voltage:24V DC (±10%)
Power Consumption:≤10W
Isolation:1500V AC
Processor:32-bit RISC microcontroller/DSP
Clock Speed:100-200 MHz
Analog Inputs:4-8 channels
Digital I/O:8-16 channels

Power Supply Module

Input Voltage:3-phase: 380-480V AC (±10%), 50/60Hz
Output Voltage:24V DC (±1%)
Output Current:20A (continuous)
Power Rating:480W
Efficiency:>92% (at full load)
Inrush Current:<40A (at 480V AC)

Control Board

Supply Voltage: 24V DC (±10%)
Power Consumption: 8W (typical)
Processor: 32-bit DSP
Clock Speed: 150 MHz
ADC Channels: 16-bit, 12 channels
Analog Inputs:6 channels
Isolation:2500V AC

Control Board

Processor: Dual-core 32-bit DSP
Clock Speed: 300 MHz
Power Supply: 24V DC
Power Consumption: 12W (typical)
Isolation:3000V AC
Control Loop Speed: 25μs (basic)
PWM Resolution: 16-bit @ 8kHz
Protection Response: <10μs

Control Module

Supply Voltage:24V DC
Processor:Triple-core 32-bit DSP
Clock Speed:400 MHz
Memory:512KB SRAM
Power Consumption:18W (typical)
Analog Inputs:12× 18-bit ΣΔ ADC (±15V, 500kS/s)
Analog Outputs:6× 16-bit DAC (0-10V/4-20mA)
Digital I/O:24× configurable (5V TTL to 30V DC)

Control board

Supply Voltage: 24V DC
Power Consumption: 6W typical
Isolation:2500V AC
Processor: 32-bit RISC
Clock Speed: 216 MHz
Memory SRAM: 256KB
Analog Inputs:6 channels
Digital I/O:12 opto-isolated inputs

INVERTER INTERFACE BOARD

Supply Voltage:24V DC (±10%)
Power Consumption:≤5W
Isolation Voltage:2500V AC (input-to-output)
Analog I/O:Range ±10V, 4-20mA
Digital I/O:24V DC
Overvoltage:Auto-cutoff at 30V DC
Short Circuit:Current limiting
ESD Protection:±8kV (all ports)
