ABB

BRANCHING UNIT

Rated Voltage:690V AC
Current Rating:44A continuous
Short-Circuit Capacity:50kA (1s)
Power Connections:4-in/8-out configuration
Isolation Voltage:3000V AC

Circuit Board

Operating Voltage:24V DC (±10%)
Power Consumption:2W (typical)
Signal Range:0–24V DC, 4–20mA
Resolution:12–16-bit
Short-Circuit Protection:Self-resetting fuse

Compact and powerfulautomatic voltage regulators

Excitation current  5 A cont., 10 A
ceiling@ 70° C ambient temp.
Digital:4 outputs, 8 inputs
Analog:2 outputs
Mechanicals:IP20
Certifications:CE, DNV/GL, Traction

Control panel

ACS580 CONTROL PANEL
Assistant control panel
Protection Class:IP54 (Front Panel)
MTBF:>150,000 hours
Display Type:LCD (Backlit)
Resolution:128 x 64 Pixels
Languages:Multi-language support
Keypad:Membrane/Sealed (Dustproof)

Voltage Drive Circuit Board

POWER MASTER BOARD
VOLTAGE DRIVE CROWBAR CIRCUIT BOARD
Input Voltage:24V DC (±10%)
Output Voltage:0-10V (Programmable)
Current Rating:2A (Max Continuous)
Frequency Range:0-400Hz
Isolation Voltage:1500V AC

Automatic Voltage Regulators

Maximized operating time
Ensures safe machine operation
Guarantees the quality of delivered energy
Seamless integration with the power plant control systems

AC500 Communication module

Function:PROFIBUS master
Communication Protocol:PROFIBUSMaster
Communication Interface:Serial
Number of Hardware Interfaces:RS-485 1
Data Transmission Rate:12000 kbit/s
Degree of Protection:IP20

Rechargeable lithium-ion battery

Rechargeable lithium-ion battery
3.7V, 2,4Ah
Non-restricted
Common recommendations for storage of Li-ion batteries
are at -20° to 25° C and to charge the batteries once
per year to 40% (or 3.75V/cell) of their capacity and
never let them discharge to below 2.0V

88TK05 Station- Bus Coupler Module

Supply Voltage:24V DC (±15%)
Power Consumption:1.8W (typical)
Interface:9-pin D-Sub
Bus Termination:Integrated
Bus Protocol:PROFIBUS DP (EN 50170)
Transmission Rate:9.6Kbps to 12Mbps
Address Range:0-125
Max Number of Slaves:125
Electrical Isolation:500V AC

Inverter Circuit Board

Model Number:AGPS21C (64668064)
Type:SACS800 Inverter Circuit Board
Input Voltage Range:85-264V AC (47-63Hz)
Output Voltage:24V DC (±1%)
Output Current:5A (continuous)
Power Rating:120W
Efficiency:>88%
Inrush Current:<30A (at 230V AC)

Inverter Memory Card

Memory Type:Flash EEPROM
Storage Capacity:2MB
Write Cycles:100,000 cycles
Interface:Proprietary ABB connector
Operating Voltage:3.3V DC (supplied by drive)
Power Consumption:<50mA
ESD Protection:±8kV contact discharge

Asymmetric Thyristor IGCT

Asymmetric Integrated GateCommutated Thyristor
VDRM = 4500 V , ITGQM = 4000 A
Mounting force 40kN
High snubberless turn-off rating
Optimized for medium frequency
High electromagnetic immunity
Simple control interface with status feedback
AC or DC supply voltage
Option for series connection

Reverse Conducting Thyristor IGCT

Reverse Conducting Integrated Gate-Commutated Thyristor
VDRM = 4500 V ,ITGQM = 3600 A ,ITSM = 20·10³ A
VT0 = 1.24 V , rT = 0.51 mΩ ,VDC = 2800 V
Mounting force 41kN
High snubberless turn-off rating
Optimized for medium frequency
High electromagnetic immunity
Simple control interface with status feedback
AC or DC supply voltage
Option for series connection

Printed Circuit Board

Layer Count:4-layer PCB
Material:FR-4 (Flame Retardant)
Copper Weight:1 oz/ft² (35μm)
Operating Voltage:24V DC (±10%)
Power Consumption:15W (max)
Input Channels:8 analog (16-bit resolution)
Output Channels:6 digital (2A max)
Isolation Voltage:2500V AC

CHOPPER CONTROL BOARD

Model Number:NBRC-61C (61357246F)
Type:Chopper Control Board
Operating Voltage:24V DC (±10%)
Power Consumption:8W (typical)
Signal Levels:0-10V analog, 24V digital
Isolation Voltage:1500V AC (input-to-output)
PWM Frequency:2kHz (adjustable)
Current Regulation:±1% of setpoint
Response Time:<5ms (90% step change)
Resolution:12-bit (analog signals)

EXTENSION I/O BOARD

contains more channels
16 binary inputs
8 binary outputs
8 analog inputs
4 analog outputs
Time out setting by software
Watchdog function

Central Processing Unit

processor module
128 kBmemory
8 DI, 6 DO-T,24 V DC
onboard Ethernet
with pluggable I/O terminalblocks

Control Unit

Processor:Dual-core 1.2GHz
Memory:2GB DDR3 RAM
Storage:8GB Flash
Execution Speed:10ms cycle time (typical)
Operating Voltage:24V DC (±10%)
Power Consumption:15W (typical)
Isolation Voltage:1500V AC (field to system)

Optical fiber board

Fiber Type:Multi-mode (62.5/125μm)
Wavelength:850nm/1300nm
Data Rate:1Gbps (1000BASE-SX)
Connector Type:Duplex LC
Transmission Distance:Up to 550m (MMF)
Operating Voltage:5V DC (±5%)
Power Consumption:3.5W (typical)
Interface:PCI Express

Panel Controller

Control Circuit Voltage: 24V DC (±15%)
Analog inputs :0–10V, 4–20mA
Temperature: -10°C to +50°C (derate 2% per °C above 40°C)
Humidity: <95% non-condensing

IGBT Module

Rated Voltage (V_CEO): 600 V
Collector Current (I_C): 60 A (continuous)
Peak Collector Current (I_Cpeak): 120 A (pulsed)
Gate-Emitter Threshold Voltage (V_GE(th)): 4.0 V (typical)
Input/Output Signal Voltage: 15 V / 15 V
Max Power Dissipation (P_diss): 200 W (maximum)

Inverter IGBT trigger board

Input Voltage:+24V DC
Turn-On Voltage: +15V ±0.5V
Turn-Off Voltage: -8V to -15V
Switching Frequency:Up to 10–20 kHz
Optical Isolation: ≤2500 V RMS
Operating Temperature: 0°C to +70°C
Storage Temperature: -40°C to +85°C

CIRCUIT BOARD

Supply Voltage:24V DC (±10%)
Power Consumption:<10W (typical)
Processor:32-bit microcontroller
Memory Flash: 8MB+, RAM: 4MB+
Operating Temp.:-25°C to +70°C
Humidity:5–95% RH (non-condensing)

Processor module

Display Type:LCD
Communication Interface:Serial/FBP/Ethernet
Memory Size:9728 kB
Memory Size User Data:5632 2 kB
Memory Size User Program:4096 2 kB
Memory Type User Data:RAM
Controller Processing Time:0.000002 ms
Degree of Protection:IP20
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

Gate Unit Power

3BHB005243R0105
GATE UNIT POWER SUPPLY
(KUC755 AE105)
