ABB

Control Board

3ASC25H203
PC BOARD

Accuray Module

Operating Voltage: 24 VDC
Signal Voltage: ±10 VDC or 5 VDC
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
Protection Class: IP20
High-resolution signal processing:16-bit ADC/DAC

Profibus DP-VI Communication Interface Module

PROFIBUS DP PROFIBUS-DPV1 fieldbus interface.
Supervisory functions of I/O ModuleBus
Isolated power supply to I/O modules
OSP handling and configuration
Input power fused
Hot Configuration In Run
HART pass-through

Analog Input Module - RTD

8 channels for RTD
(Pt100, Cu10, Ni100 and Ni120 and resistor) inputs
3-wire connection to RTDs
14 Bit resolution
Inputs are monitored for open-circuit,
shortcircuit and has a input grounded sensor

Distributed Digital I/O Device

DIGITAL I/O MODULE
32 DIGITAL INPUTS
24 VDC
1-WIRE
SCREW TERMINALS / PLUGGABLE
IP20

System Power Module

IPSYS01
DISCONTINUED BY MANUFACTURER
POWER SYSTEM MODULE
2/4 AMP
120/240 VAC
125 VDC
50/60 HZ
Tariff Code: 8504409540
Country of Origin: United States

Power Supply

SDCSPOW4
DISCONTINUED BY MANUFACTURER
POWER SUPPLY BOARD

DRIVES HIES

Commander 100 Process Controller

C1000200STD
DISCONTINUED BY MANUFACTURER
PROCESS CONTROL 1/8 DIN W/2 ADDL RELAYS 1 DIG IN

Measurement Card

SDCS-PIN-51-COAT
Analog Inputs (AI):0–20 mA/4–20mA
PT100/RTD temperature
Channel Capacity: 8/16 channels
Resolution: ≥16-bit ADC
Sampling Rate: up to 1 kHz
Accuracy: ±0.1% of full scale
Operating Temperature: -25°C to +70°C
Humidity: Up to 95% non-condensing.

24VDC MControl Board

Binary Input Module

HIEE300910R0001
BINARY INPUT MODULE

RDCU Drive Control Unit

Analog Inputs: 2 channels
Analog Outputs: 2 channels
Digital Inputs: 6 channels
Digital Outputs: 3 relay outputs
Operating Temperature Range: -10°C to +55°C
Storage Temperature Range: -40°C to +70°C
Humidity: 5%-95% (non-condensing)
Protection Level: IP20

PC Drive Digital Processor Module

3ASD573001A1
DISCONTINUED BY MANUFACTURER
PC DRIVE BOARD
DIGITAL PROCESSOR

YPK112A Communication Module

YPK112A
DISCONTINUED BY MANUFACTURER
PC COMMUNICATION BOARD PAL-CIRCUIT

Tension Controller

Analog: 0–10 VDC or 4–20 mA
Response Time: ≤1 ms
Accuracy: ±0.1% of full scale
Supply Voltage: 24 VDC (±10%) or 100–240 VAC
Power Consumption: ≤10 W (typical)
Operating Temperature: 0°C to +55°C (32°F to +131°F).
Humidity: 5–95% non-condensing.

Power supply module

Power supply module

MB 300 Dual Ethernet Port Kit

Communication Protocol:MasterBus 300 (MB 300)
Ethernet Ports:2 x RJ45 (8-pin)
Transmission Speed:10 Mbit/s
Data Rate:200 Datasets/s
Operating Temperature:Up to 55°C
Protection Class:IP20 (according to EN60529, IEC 529)
Power Consumption:150 mA @ 24 VDC

Disconnect Switch-600V-30A-3 Pole-Class J

OS30AJ12
DISCONNECT SWITCH ONLY
30 AMP
3 POLE
600 VAC
J FUSE
DIN RAIL MOUNT
Tariff Code: 8536904000
Country of Origin: Finland

IGCT Module Board 5SHX 1960L0004. 3A

3BHL000390P0101
DISCONTINUED BY MANUFACTURER
IGCT MODULE

AI810 Analog Input Module

8 channels for 0...20 mA, 4...20 mA
0...10 V or 2...10 V d.c.
single ended unipolar inputs
1 group of 8 channels isolated from ground
12 Bit resolution
Input shunt resistors protected to 30 V by PTC resistor
Analog inputs are short circuit secured to ZP or +24 V
The input withstand HART communication.

SNAT-617-CHC Control Module

SNAT617CHC
CHOPPER CONTROL BOARD

Power Supply Module

S400 Fieldbus Modem

DSTC452
DISCONTINUED BY MANUFACTURER
ABB
ASEA BROWN BOVERI
MODEM
FSK
FOR SERIAL I/O BUS
COAX
Tariff Code: 8517620050
Country of Origin: Sweden
