Technical specifications for GD C806 B01 3BHE036290R0001
-
Product ModelGD C806 B01 3BHE036290R0001
-
Spare Model3BHE036290R0001 GDC806 B01
-
Product ParametersGATE DRIVE BOARD
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
Estimated Shipping Size17x8.3x5cm
-
ManufacturerABB
-
Weight0.15 kg
-
Input Voltage24 VDC
-
Analog Inputs0–10 VDC / 4–20 mA
-
Fieldbus SupportPROFIBUS DP
-
Operating Temperature-20°C to +70°C
-
Storage Temperature-40°C to +85°C
-
Humidity5–95% non-condensing
Description
3BHE036290R0001
GDC806B01
PC BOARD
Channel-wise electrical isolation
GDC806B01
PC BOARD
Channel-wise electrical isolation
Information
Overview
Manuals
Technical notes
Product Applications
Safety & Pre-Installation
Features:
- LXEU100B
- Gate Drive Board
- Specific ACS2000
The GD C806 B01 3BHE036290R0001 ABB Gate Drive Board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB GD C806 B01 3BHE036290R0001 Gate Drive Board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
One of the most vital aspects of the GDC806 B01 is its commitment to signal integrity in "noisy" electrical environments. Because it operates in close proximity to high-frequency switching and high-voltage busbars, it relies heavily on fiber optic communication. By using light pulses instead of electrical wires for the firing commands, the board eliminates the risk of ground loops and false triggering caused by massive electromagnetic fields. This ensures that the power converter operates with absolute synchronicity and safety.
- Drive Control Systems: Specifically used to control and optimize drive functions, ensuring high-performance motor management
- Manufacturing Automation: Found in complex manufacturing lines that require precise speed and torque control for machinery
- Energy Management: Applied in power conversion and energy systems to facilitate efficient drive operations and reduce energy loss
- Marine & Process Industries: Utilized in heavy-duty environments like marine propulsion and chemical processing where rugged design is essential
- Material Handling: Employed in conveyor systems and automated warehouses to manage motor-driven movement
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Lockout/Tagout: Disconnect all power sources and verify the absence of voltage. Wait at least 5 minutes after disconnection to allow intermediate circuit capacitors to discharge.ESD Protection: Use an antistatic wrist strap and avoid touching electronic components directly to prevent damage from electrostatic discharge.Cleanliness: Vacuum the area around the drive to prevent the cooling fan from pulling dust into the new board during start-up
FAQs
-
What is the function of the 3BHE036290R0001?
+It acts as a drive board responsible for driving components, typically within a larger drive control system. -
What is the ABB GD C806 B01?
+It is a Gate Drive Unit (part of a Gate Drive + Active Crowbar Limit [ACL] Unit) used in Medium Voltage AC (MVAC) drives. -
Can I replace a B01 unit with a B02?
+While both are for the ACS2000, they are distinct revisions. The GD C806 B02 (Part Number 3BHE039017R0101) is a later revision. You should consult the specific ACS2000 Spare Parts Catalog for your drive's serial number to ensure firmware and hardware compatibility before substituting revisions. -
Is this product brand new?
+Yes, ABB 3BHE036290R0001 GDC806 B01 is brand new, original, unused, and factory sealed
