PC adapter USB A2 USB adapter (USB V2.0)
for connection of a PG/PC or notebook to
SIMATIC S7 via PROFIBUS or MPI contain USB cable 5 m
MPI cable 0.3 m can be
used under Windows XP/Vista/ Windows
7 32/64 bit and higher
SIMATIC S7-300
CPU 313C
Compact CPU with MPI
24 DI/16 DO, 4 AI
2 AO, 1Pt100
3 high-speed counters (30 kHz)
Integr. power supply 24 V DC
workmemory 128 KB
Front connector (2x 40-pole)
Micro Memory Card required
SIMATIC S7-200 CN
CPU 226 Compact device
AC power supply 24 DI DC/16 DO relay
16/24 KB progr./10 KB data
2 PPI/user-programmable interface
this S7-200 CN product
only has CE approval
CPU Energy Pack
CPE305 / CPE310
Saving CPU Data During Power Failures
4.5 years @ 60o ; 10+ years @ 0-50o
CPE 305 and CPE 310
0 to 60°C (32°F to 140°F)
3 ft. (0.91m)
CPE305 CPU Supported
Operating Temperature Range:-40°C to 85°C
Input Voltage Range:90VAC to 264VAC
Output Voltage:DC 24V
Power Consumption:≤ 15W
Communication Interface:RS-232, RS-485
Relay Output:4 channels
LED Indicators:Status and alarm indicators
Certifications:CE, UL, CSA
Length:5.0 meters (16.4 feet)
Conductor Size:0.382 mm² (22 AWG)
Temperature Range:-29°C to +121°C (-20°F to +250°F)
Voltage Rating:300V AC/DC
Minimum Bend Radius:≥12× cable diameter
