Ethernet Adapter Module

Sample intervals from 10 seconds to 60 min
Graphical browser-based log viewer
Sends logs by E-mail or FTP
Data is saved in Microsoft
Excel compatible CSV files.

Field Kit

3BSE005177R0001
DISCONTINUED BY MANUFACTURER
CONTROL BOARD I/O MODULE DIGITAL EXTERNAL ISLOATED

COMMUNICATION BOARD

SDCSDSL4
COMMUNICATION BOARD
DCS-LINK DRIVE-TO-DRIVE
DEDICATED TO THE DCS800
BASED ON CAN BUS.
THIS COMMUNICATION ADAPTER IS USED IN
12-PULSE OPERATION
AND COMMUNICATION /
CONTROL OFEXTERNAL FIELD SUPPLIES
DCF803-0035
THIS BOARD IS STANDARD IN AL

Communication Board

Series: SDCS
Operating Voltage: Typically 24V DC
Power Consumption:  5-10 W
Current Consumption: 200-400 mA
Operating Temperature Range: -20°C to 70°C (-4°F to 158°F)
Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)

Supervision Board

SAFT132CBS
DISCONTINUED BY MANUFACTURER
SUPERVISION BOARD
CPU
LED ARRAY

LonWorks Adapter Module

ADAPTER MODULE
INCLUDES TWO OBJECTS
A NODE OBJECT AND A DRIVE OBJECT
LONWORKS NETWORK

DDCS Communications Module

DDCS COMMUNICATION MODULE
SPARE KIT
64606964
DDCS COMMUNICATION BOARD 3

Watchdog Timer Module

57087234
DISCONTINUED BY MANUFACTURER
PC BOARD
TIMER
WATCHDOG

NPOW-41 Power Supply Board

NPOW41
ASEA BROWN BOVERI
NPOW-41
POWER SUPPLY BOARD

COMMUNICATIONS ADAPTER

COMMUNICATIONS ADAPTER
RS-232 TO RS-485
3 METER RJ11 COMMUNICATIONS CABLE
FOR DRIVE WINDOWS LIGHT

Profibus Adapter Module

Enclosure: Plastic
Mounting: Onto a standard mounting rail
Settings: Via drive interface (control panel)
Current Consumption: 70 mA at 24 V d.c
All materials are UL/CSA approved
Complies with EMC Standards EN 50081-2 and EN 50082-2

I/O Module

Processor:32-bit RISC-based
Memory:16 MB Flash, 8 MB RAM
I/O Capacity:Up to 128 S800 I/O modules
Power Supply:24V DC (±10%)
Power Consumption:5W (typical)
Operating Temp:-25°C to +70°C
Humidity:5–95% (non-condensing)

Ethernet Adapter module

Power Supply :24 V DC
Module Type : NETA-01 V1.x
Mounting: On to a standard mounting rail
Settings : Through drive parameters and/or DIP switches
Current consumption: 80 mA at 24 V DC ±10%

DSU CONTROL BOARD

3 digital inputs
3 + 1 digital outputs
DDCS communication link
+24 VDC (500 mA) to supply auxiliary equipment
isolated firing pulses
voltage measurements
Uc (DC busbar voltage)
Uac (supplyvoltage), synchronisation
heatsink temperature measurement
current measurement
earth fault current measurement
7-segment display

Digital I/O Extension Module

Digital I/O Extension Module
contains 2 digital inputs and 2relay outputs
2IN 24-250VDC 2OUT 250VAC

Field Kit

NDBU85C
ACS800 BRANCHING UNIT
8 CONNECTION RATED FOR 5MB
1 RATED FOR 10MB

Field Kit

BRAKING CHOPPER
AIR COOL
690V
1/9MIN
600AMP MAX

DRIVE CONTROL UNIT

JCU01
DRIVE CONTROL UNIT
TERMINATION
2 AMP
250 VAC/30 VDC
2X8 SIGNAL

ANALOG I/O EXTENSION

Input Signal Types: Voltage (0-10V, ±10V)
Accuracy: ±0.1% of full scale
Output Resolution: 12-bit or 16-bit
Output Load Resistance: 500Ω max
Voltage Supply Range: 24V DC nominal
Power Consumption: < 10 W
Operating Temperature:-20°C to +60°C
Storage Temperature:-40°C to +85°C

HTL encoder interface

Differential push-pull HTL encoders
Single-ended push-pull HTL encoders
Open collector HTL encoders
Open emitter HTL encoders
+15 V DC ± 20% 200mA (max.)
+24 V DC ± 20% 200mA (max.)

Resolver Interface Module

Power Supply Voltage: 24 VDC ± 10%
Power Consumption: Typically less than 2 W
Resolver Excitation Voltage: 4-8 V RMS
Resolver Frequency Range: 2 kHz to 15 kHz
Input Channels: 1 Resolver input
Resolution: 12-bit to 16-bit resolution depending on configuration
Accuracy: ±0.05 degrees

TTL encoder interface

Output voltages:
+5.5 V DC -5%, -8%, 180 mA
+24 V DC ±15%, 150 mA
Maximum cable length:
30 m with a 5 V encoder
(0.5 mm2 cable for power supply)
CH A, CH B, CH Z, CH U, CH V, CH W: RS-422/485,

Control Panel

Device used for controlling andprogramming
Can be attached directly to
the module ordoor of the cabinet
The keys are flat, labeled push-buttons
LCD display: 4x20 characters

Basic Control Panel

ACSCPC
BASIC CONTROL PANEL
KEYPAD MODULE
NUMERIC LCD DISPLAY
COPY FUNCTION
FOR ACS310/320/350/355/550 INVERTER DRIVES
J404 OPTION

Gate Unit Power Supply

3BHB004661R0101
ASEA BROWN BOVERI
GATE UNIT POWER SUPPLY
4AMP
