ALL MANUFACTURERS

3300 XL 11 mm Proximity Probes

330709 3300 XL 11 mm Probe
M16 x 1.5 thread,without armor
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 Multiple Approvals

SINAMICS POWER MODULE

SINAMICS POWER MODULE
PM240-2 WITHOUT FILTER
WITH BUILT IN BRAKING CHOPPER
3AC380-480V +10/-10% 47-63HZ
OUTPUT HIGH OVERLOAD: 11KW FOR 200% 3S
150% 57S,100% 240S
AMBIENT TEMP -10 TO +50 DEG C
OUTPUT LOW OVERLOAD: 15KW FOR 150% 3S
110% 57S,100% 240S
AMBIENT TEMP -10 TO +40
FSC PROTECTION IP20
WITHOUT CONTROL UNIT AND PANEL APPROVED
FOR CU FIRMWARE- VERSION V4.6

Drive board

Drive Integration:Sinamics S110
Supply Voltage:24V DC (±15%)
I/O Capabilities:Max ≤ 16 axes
Working Temp:-20℃ … 85℃⁵ storage

Control Unit

Primary Input Voltage:3AC 380–480V
Input Frequency:50/60Hz
Auxiliary Power:24V DC ±10%
DC Link Operating Voltage Range:510–680V DC
Overvoltage Shutdown Threshold:830V DC
Peak Feedback Current Capability:≤150%
Digital Inputs:14 channels

POWER INTERFACE MODULE

Input Voltages Monitored:400–690V AC
Control Voltage:24V DC
Signal Resolution:±0.5% accuracy
Input Frequency Window:48–63Hz

FIELD SUPPLY

Input Voltage:100–690V AC/DC
Frequency (AC):45–65 Hz
Starting Current:≤4 In (inrush) at 70%
Output Voltage (Main):25–28V DC
Output Power:Static-rated at 50W sustained
Max. Ripple Peak:300mVp-p at 100% load
Efficiency Efficiency:>90% at nominal load

TSE module

Internal Part Number: C98043-A7007-L4
Product Description: TSE Module
Product Category: Spare Part
Application Siemens DC Drives
Export Control Regulations: ECCN: N / AL: N

DC Speed Regulator

SINAMICS DCM
DC converter for two-quadrant drives
B6Cconnection
Input: 400V 3AC, 174A
controllable: Field rectifierD485/210
MRE-GEEF6S22
Output: 485 V DC, 210 A

MM440 Brake Board

Product Type:Brake Board
Series:MICROMASTER 440
Voltage Range:up to 800 VDC
Operating Temperature:-10 °C to +50 °C
Storage Temperature:-40 °C to +70 °C

Mains-thyristor module

Masterdrives
Mains-thyristor module
SKKT, 2x 273A
1600V

SMART LINE MODULE

SINAMICS S120
SMART LINE MODULE
INPUT: 3AC 380-480V, 50/60HZ
OUTPUT: DC 600V, 90A, 55KW FRAME
SIZE: BOOKSIZE INTERNAL AIR COOLING
INCL. DRIVE-CLIQ CABLE

CompactFlash card

SINAMICS S120
CompactFlash card
without performance expansion
including licensing (Certificate of License)
V4.5

SINAMICS S120
SENSOR MODULE
SMC40 BOARD FOR EVALUATION
OF ENDAT 2.2 ENCODER 30 MM WIDTH

Double Motor Module

SINAMICS S120
Double Motor Module
input: 600 V DC
output: 400 V 3 AC, 3 A/3 A type of
construction: booksize internal air cooling optimized
pulse patterns and support of the extended
Safety Integrated functions
incl. DRIVE-CLiQ cable

Inverter drive

MICROMASTER 440
built-in class A filter 380-480 V
3 AC +10/-10% 47-63 Hz
constant torque 5.5 kW overload 150% 60 s
200% 3 s square-law torque 7.5 kW
245x 185x 195 (HxWxD)
degree of protection IP20
ambient temperature -10+50 °C without AOP/BOP

Servo amplifier

Single-phase: 120–240V AC
DC bus option: 350V DC
Three-phase: 200–480V AC
Continuous: 1.2‒7.8 kW
Peak Current: Up to 28.5‒45A
 Velocity/Compliance loop: 2 kHz
Current loop: ≤0.002 ms

OPERATOR PANEL

OPERATOR PANEL
PMU
PARAMETER ASSIGNMENT UNIT
FOR DESIGNS A / B
SIMOVERT MASTERDRIVES

Current Transformer

Symmetry resistance
3x 2K7 Ohm 190W 5%
Power:1kV
Primary Current:15 A
Accuracy Class:1 or 3
Voltage:400-440 V
Phase:Three Phase

CU240B-2DP Control Unit

SINAMICS G120
Control Unit CU240B-2
DP B type PROFIBUS DP 4 DI
1 DQ, 1 AI, 1 AQ PTC/KTY/thermoclick
interface USB and SD/MMC
interface degree of protection IP20
ambient temperature 0 to +50 °C
without Power Module

GATE/POWER MODULE BOARD

GATE/POWER MODULE BOARD
SIMOREG DRIVES
POWER-INTERFACE
GATING + SV(POWER-INTERFACE)
(C98043-A1601-L1)

Machinery Control

Series:MM430
Input Voltage:380–480V AC ±10%
Input Frequency:50/60Hz ±5%
Output Power:7.5 kW

C751-009 I/O Module

Digital Inputs (DI) : 8 × 24V DC
Digital Outputs:4 × Relay Outputs
AC capacity:≤250V
Operating Voltage DC:+24 VDC +10%
Power Consumption:≤5W
Storage Temperature:-10˚C- +60˚C

Rectifier interfaces Module

Rectifier interfaces Module
PER2 for infeed/regenerative
feedback Supply units
with Designs H and K 3 AC 500-575V
50/60 Hz and 660-690V 3AC
50/60 Hz

INVERTER CPU BOARD

Processor: Infineon C167xx-series
Flash EPROM: ≥1 MB
SRAM: 128‒512 KB data cache
EEPROM: 8‒16 KB
On-Board Power: +5VDC ±1%
Temperature operating:-15˚C to +70˚C

Replacement IPD card

SINAMICS S120
Replacement IPD card
for air-cooled Basic Line Module
1100kW 500-690V 3AC/1400A
