ALL MANUFACTURERS

Vibration Transmitter

0 4 0-4 mils pp (0-100 μm pp)
5 0 5.0 metres (16.4 feet)
0 2 Bulkhead screws
0 0 Not required
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.

PS307 Power Supply -10A

LONG-LIFE FAN

Type:  D2D160-CE02-11
(Was D2D160-BE02-11)
Voltage:  230V/400V
Power:  700 Watts

CPU314C-2 DP Processor

TP 277 6" Touch Panel

Touch Panel TP 170B Color

1715 16 Point Digital Input Module

High-speed Analog I/O Module

Inputs:4 high speed sub-millisecond differential
Module Type:High Speed Analog Input / Ouptut Module
Outputs:2 high speed current-voltage
Input signals ranges:± 10V
0…10V; 0…5V; 0…20 mA
Input Resolution:14 bits across ±10.5V DC
12 bits across 21 mA
No. of Outputs 2 high speed current/ voltage
Output Resolution:13 bits across 21 mA = 2.8 µA/bit;
14 bits across 21.8V = 1.3 mV/bit
Output Signal Ranges:± 10V; 0…20 mA

SITOP REDUNDANCY MODULE 10A

SITOP PSE202U 10A
Redundancy module
Input/output:
24 V DC suitable for
decoupling two SITOP
power supplies with
maximal per 5 A output current

Simatic S7-300 Rail

SIMATIC S7-300
mounting rail
length: 530 mm

PSU200M Power Supply - 5A

SITOP PSU200M 5 A
stabilized power supply
input: 120/230-500 V
AC output: 24V DC/5 A
1-phase and 2-phase AC or DC
supply voltage at DC 110 ... 220 V
input voltage at DC 88 ... 350 V

ControlLogix Power Supply Bundle

Input Voltage:120/240VAC
Input Voltage Range:85-264VAC
Max Inrush Current:20 Amperes
Output Power:75 W @ 0…60 °C (32…140 °F)
Annunciator Power:240V AC 50/60 Hz, 240V DC, 50 mA, resistive only
Hold Up time:2 cycles @ 60 Hz; 2 cycles @ 50 Hz
Input Voltage:85-265 VAC

RING REPEATER

RING REPEATER
CONTROLNET
FIBER
DUAL FIBER OPTIC CHANNEL
DIN RAIL MOUNTING
FOR 62.5/125 UM MULTI-MODE
USE TO 10000 M

Frequency Converter Rectifier Module

POWER SUPPLY

PM3326B612E
POWER SUPPLY
17 AMP
100/240 VAC
50/60 HZ
