DSXW 110 SG-Interface
One measurement channel incl. supply ±10V
(square) 320 Hz, sensor signal and measurement
signal. DI/DO: 24 V d.c.
AO: resolution 12 bits + sign
0 to ±10 V or 0 to ±20 mA
800xA Advant control systems
24V DC nominal
Input voltage range: 20V to 30V DC
Approximately 10-15W
Current Consumption:0.5 A (typical) at 24V DC
Maximum pulse frequency: 10 kHz
Minimum pulse width: 50 µs
Input Voltage: 24 V DC
Power Consumption: 10-20 W
Ethernet Ports: 2 x 10/100 Mbps
PROFIBUS DP (via optional module)
Modbus (RTU/TCP)
OPC UA (depending on firmware)
