SIMATIC DP
ELECTRONIC MODULE
FOR ET 200S, 2 AI STAND
I-4DMU 15 MM WIDE, +/-20MA
13 BIT + SIGN,4 .. 20MA
12 BITFOR 4-WIRE
TRANSDUCER CYCLE TIME
65 MS/CHANNEL WITHLED SF
SIMATIC S7-1200
CPU 1214C
compact CPU
AC/DC/relay
onboard I/O: 14 DI24 V DC
10 DO relay 2 A; 2 AI 0-10 V DC
power supply: AC 85-264 V AC at 47-63 Hz
program/data memory 150 KB
Operator Interface and HMI
PC Control
Network Configuration, Troubleshooting and
Diagnostics
I/O Emulation! Device Development
Operational temperature: 0 to 50 C (32 to 122 F)
Storage temperature: -25 to 70C (-13 to 158 F)
Power requirements: +5 V +/- 5% 400 mA
6ES53043UB11
DISCONTINUED BY MANUFACTURER
SIMATIC S5
CONNECTION IM 304 (IN MAIN UNIT)
FOR DECENTRAL CONNECTION UP TO 600M
FROM ED TO CD AS WELL AS COUPLING OF CENTRAL DEVICES FOR S5-150H-155H-115H-115F
Tariff Code: 8517620050
Country of Origin: Germany
Speed Range: 0–20,000 RPM
Frequency Input: 0.1 Hz to 10 kHz
Sensor Excitation: 8–24 V DC for powered probes
Analog Output: 4–20 mA or 0–10 V
Voltage: 24 V DC (±10%) or 100–240 V AC (±15%, 50/60 Hz).
Power Consumption: ≤15 W
Vibration Resistance: ≤5 g (10–500 Hz)
Immediate Recovery from Power Loss
High Resolution Static, Orbit, and Spectrum Data
Ethernet Link to Data Manager
Two Independent Startup/Shutdown Buffers
255 with K-bus extension
128 byte input and 128 byte output
automatic detection up to 12 Mbaud
1 x D-sub 9-pin socket with shielding
shielded copper cable, 2 x 0.25 mm²
24 V DC (-15%/+20%)
70 mA + (total K-bus current)/4, 500 mA max.
1750 mA
max. 24 V DC/max. 10 A
500 V (power contact/supply voltage/fieldbus)
-25…+60°C/-40…+85°C
