ALL MANUFACTURERS

Measurement Card

Power Supply: Typically 24 V DC
Input Voltage Range: typically 0-10V DC
Operating Temperature Range:
Typically -20°C to 70°C (-4°F to 158°F)
Storage Temperature Range:
Typically -40°C to 85°C (-40°F to 185°F)
Humidity:  5% to 95%, non-condensing

Analog Input Module - RTD

ICSI16E1 Binary Input Unit

FPR3316101R1032
DISCONTINUED BY MANUFACTURER
INPUT MODULE BINARY 220VAC 24VDC PROCONTIC CS31

Industrial Circuit Voltage Converter

Drive Control Unit

Control Panel

Operating Temperature Range:
 -10°C to +55°C
Storage Temperature Range:
From -20°C to +70°C
Power Supply: 24V DC

LED Data Adapter Module

Input Voltage:380V to 480V
Board Type: frequency inverters and VFDs
AC input: 380V to 480V AC
Frequency Control:0 Hz to 400 Hz
Operating Temperature:0°C to 40°C
Storage Temperature: -20°C to 70°C

TERMINATION UNIT

NTDO02
TERMINATION UNIT
DIGITAL POWER OUT
NET 90
8 OUTPUTS

Coaxial Cable for RIO/Infi-Net Communications

Bailey Infi 90
NKCL01-10
10 foot length
Coaxial Infinet/ RIO Communication Cable
PLANT COMMUNICATION CABLE

DSTD108 Connection Unit

Analog Input Board

Number of Channels: 8 channels
Current: 4–20 mA, 0–20 mA
Voltage: 0–10 VDC, ±10 VDC
Resolution: 16-bit
Accuracy: ±0.05%
Drift: ±0.005%/°C
Channel-to-Channel: 250 VAC.
Channel-to-Backplane: 1500 VAC
Supply Voltage: 24 VDC (±10%)
Power Consumption: ≤2 W (typical)

Programmable Logic Controller

TF620 Process Connector

TF610 Process Connector

Control Board

Power Supply: 24V DC
Operating Temperature: -20°C to +60°C.
Mounting: Rack-mounted

Control Board

Logic Side: 24 V DC (±10%)
High-Side Gate Drive: 15 V
Negative Turn-Off Voltage: -8 V
Isolation Voltage: 2500 V AC
Output Current (Gate Drive): 2-5 A
Rise/Fall Time: <100 ns
Operating Temperature: -20°C to +70°C

Control Board

Power Supply Input:24 VDC ±10%
Logic Voltage Levels:5 VDC (TTL)
Communication Interface:Fiber-optic, RS-485
Input Voltage (Power Cell):230–690 VAC
Max Cells per Drive:10–28 cells
Operating Temperature:–20°C to +55°C (0–45°C ideal)
Relative Humidity:≤95% (non-condensing)
Altitude:Up to 1000 m (no derating)

I/O Board

GH180 GH1 8024VDC User
I/O Board,
A5E41987327, A5E36881503
USER IO BOARD

Pcb Circuit Board

A5E32168144
Siemens Robinson
Pcb Circuit Board
high-voltage inverter

Power Supply

Robicon NXG Power Supply
High Voltage Inverter DCR Power Supply
AC Input: 480V–600V AC
Input Current: Typ. 10–20 A
DC Output Voltage: 24V–48V DC (±1%)
Efficiency: >90%
Power Factor: ≥0.95
Isolation Voltage: ≥2500 VAC
Standard: –20°C to +55°C

Medium Frequency Converter

Robicon Medium Frequency Converter
6SR0960-0CD01-1AD0
Siemens Robicon
Converter Type:100–800+ Hz
Input Voltage:AC 400–690 V (3-phase)
Output Range:AC 200–720 V
Frequency Output:150–600 Hz
Rated Power:250 kW
Efficiency:≥95%

GH180 Backplane PCA

Low-voltage control signals:5V, 24V DC
Medium-voltage isolation:up to 4160V
Control signals: ≤ 5A
Gate driver power: ≤ 10A
PWM signals to IGBT gate drivers
DC bus voltage sensing

GH180 VFD CF Card

Storage Capacity: Typically 128MB
Interface: IDE/ATA compatible
File System: FAT16 or FAT32
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Shock Resistance: 1500G operating, 2000G non-operating
Vibration Resistance: 10G

Cell Control Board

Robicon Cell Control Board
PCA, COATED
ISA BACKPL ANE
14SLOT 6SR3960-0CD01-0AD0

MULTI LANGUAGE KEYPAD ASSEMBLY CHINESE

A5E02669561 A5E02624585
LDZ252090.11 NGSC
A1 A460A68.23
MULTI LANGUAGE KEYPAD
ASSEMBLY CHINESE
