ALL MANUFACTURERS

TERMINAL CABLE

TERMINAL CABLE
CABLE ASSEMBLY
FBM2XX
TYPE 4
3M LENGTH

Term Cable

FBM 2xx
TYPE 1
TERM CABLE
3 METERS
P/N - P0916DC

Memory Card

Memory capacity 32/64 MB
Access width 16 bits
Designed as 5 V card
Program voltage of 12 Vss
Write protection via operating software

Vibration Sensor Input Module

Channels 10-12 can be
used as an analog input of ±10 V
Analog inputs individually
configurable for sensitivity
24 bit A-D resolution with a
dynamic range ≥ 96 dB
Adjustable sampling
rate up to 51.2 kHz
Adjustable analog and digital filtering

ETHERNET/IP-ETHERNET/IP

Part Status Active
Function Gateway
Modulation or Protocol EtherNet/IP™
Applications General Purpose
Interface RJ-45 Ethernet
Data Rate (Max) 1Mbps
Operating Temperature °C Min -25 °C
Operating Temperature °C Max 65 °C
Storage Temperature °C Min -40 °C
Storage Temperature °C Max 85 °C

SPINDLE DRIVE BOARD

POWER CONNECTION MODULE
DC300 SPINDLE DRIVE BOARD
CNC
Input/Output: typically 0-10V, 4-20mA
Operating Temperature Range: Typically -40°C to +70°C
Power Input: Receives AC or DC

Industrial Relays

KUEP Series
Contact Current Class = 5A to 10A Class, LessThan 16A
Contact Rated Current = 10 A
Terminal Type = Quick Connect, Solder
Contact Arrangement = 1 Form X (NO,Bridging)

POWER RELAY

Rated current AC-1:  16 A
Rated current DC-1: 10 A
Rated current DC-13: 2 A
Rated voltage AC: 400 V
Rated voltage DC: 220 V
Minimum current: 10 mA
Minimum voltage: 10 V
Versorgungsspannung: AC
Nominal supply voltage min.: 115 V
Nominal supply voltage max.: 115 V

DC Power Supplies

Input voltage :20 to 30 Vdc
Input Current: 5A max
Output Voltage: +15V DC & -15V DC
Ripple & Noise: <10 mV RMS
Voltage Regulation: ±1%

MICRO ANALOG BOARD

Input/Output:
typically 0-10V, 4-20mA
Operating Temperature Range:
Typically -40°C to +70°C
Function:
Processes and converts analog signals

Digital I/O Module

Nominal Voltage Options:
24 VDC, 48 VDC, 125 VDC, or 250 VDC.
Input Voltage Range: ±20% of nominal value
Logic 0 (Low): 0-3 V
Logic 1 (High): 15-250 V
Operating Temperature Range: -40°C to +70°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

Control Module

POWER SYSTEM
16AMP 115V
AC/DC DISTRIBUTION
115V 50/60HZ

CONTROL COMMUNICATION GATEWAY

Power Supply: Typically 24V DC
Operating Temperature Range: Typically -40°C to +85°C
Storage Temperature Range: -40°C to +85°C.
Humidity: humidity up to 95% (non-condensing).

Prolinx Communication Module

Power Supply 24 VDC nominal
Current Load 500 mA max@ 24 VDC
Operating Temperature –20 to 50°C (–4 to 122°F)
Storage Temperature –40 to 85°C (–40 to 185°F)
Relative Humidity 5 to 95% (non-condensing)
Configuration SerialPortDB-9M RS-232 only
No hardware handshaking

General Purpose Relays

Product:Power Relays
Type:Miniature
Coil Voltage:24 VDC
Relay Contact Form:2 Form C (DPDT-NO, NC)
Contact Current Rating:10 A
Contact Termination:Plug Pin
Mounting Style:Socket
Switching Voltage:250 VAC, 125 VDC
Coil Termination:Plug Pin
Coil Type:Non-Latching

General Purpose Relays

Product:Power Relays
Type:Standard
Coil Voltage:220 VAC to 240 VAC
Relay Contact Form:4 Form C (4PDT-NO, NC)
Contact Current Rating:5 A
Contact Termination:Plug Pin
Mounting Style:Socket
Switching Voltage:250 VAC, 125 VDC
Coil Termination:Plug Pin
Coil Type:Non-Latching
Coil Resistance:18.79 kOhms

Bi-power Relay

2-pole
Single contact
With operation indicator
Plug-in Terminals
24 VDC

Hybrid Power Relay

Series G9H
Packaging Bulk
Part Status Obsolete
Mounting Type Socketable
Circuit SPST-NO (1 Form A), Hybrid
Output Type AC
Voltage - Input 9.6 ~ 14.4VDC
Voltage - Load 100 V ~ 240 V
Load Current 10 A
Termination Style Plug In
Operating Temperature -25°C ~ 60°C
Approval Agency
CSA, UR

Process Interface Board

Voltage Rating:24V DC
Operating Temperature Range: -10°C to +60°C
Storage Temperature Range: From -20°C to +70°C
Humidity: humidity up to 95% (non-condensing).
Overcurrent Protection: Yes
Overvoltage Protection: Yes
Short-Circuit Protection: Yes
Ingress Protection: Typically rated IP20 or higher,
depending on the enclosure and environmental requirements.

Control Card

Voltage Rating:24V DC
Operating Temperature Range: -10°C to +60°C
Storage Temperature Range: From -20°C to +70°C
Overcurrent Protection: Yes
Overvoltage Protection: Yes
Short-Circuit Protection: Yes
Ingress Protection: Typically rated IP20 or higher,
depending on the enclosure and environmental requirements.

Console Interface Board

Rated Voltage: 24V DC
Current Rating: 1-5A
RS-232 / RS-485 Serial Ports
or Ethernet (TCP/IP)
Operating Temperature Range: -10°C to +60°C
Storage Temperature Range: -20°C to +70°C
Humidity: Typically operates in environments
with 0% to 95% non-condensing humidity

AC Servo Controller

Product Type AC Servo Controller
Nominal Bus Output Voltage 300V DC
Continuous Current(RMS) 45A
Peak Current(RMS) 90A
Continuous Power Output 15 KW
Peak Power Output 30 KW
Input Circuit Breaker Rating 38A RMS
Circuit Breaker Interrupt Rating 1300A
Static Gain 1.5x Rated Motor I/RPM

I/O ALARM MODULE

I/O ALARM MODULE
TRISEN TURBOSENTRY
16 DIGITAL OUTPUTS
OPERATING VOLTAGE: 24V DC
OPERATING TEMPERATURE RANGE: -40C TO 70C
DIMENSIONS: 12.5 X 4.5 X 5.5 INCHES

Remote Expansion Chassis

Power Supply:18 to 32 VDC
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Humidity: 5% to 95%, non-condensing
Output Channels: 16 or 32
Output Voltage: 32 VDC
Certifications: IEC 61508 SIL3

TB Option Card

the DC-300 drive
Operating Voltage  24V DC
Operating Temperature Range: -10°C to +60°C
Storage Temperature Range: -20°C to +70°C
