469P5HIA20EH
DISCONTINUED BY MANUFACTURER
MOTOR MANAGEMENT RELAY
BASE UNIT 469
CURRENT TRANSFORMER INPUTS - 5 AMP
90-300 V DC
70-265 V AC
48/62 HZ
4-20 MA ANALOG OUTPUTS
ENHANCED FRONT PANEL
HARSH CONFORMAL COATING
Communications processor CP 343-1
for connection of SIMATIC S7-300
toIndustrial Ethernet via ISO and TCP/IP
PROFINET IO controller or PROFINET IOdevice
integrated 2-port switch ERTEC 200
S7 communication, fetch/write
SEND/RECEIVE RFC1006, multicast, DHCP
NTC- CPU sync, with and withoutdiagnostics
initialization via LAN,
2x RJ45 connection for LAN with 10/100 Mbit/s
SIMATIC S7-300
CPU 313C-2DP COMPACT CPU WITH MPI
16 DI/16 DO, 3 FAST COUNTERS (30 KHZ)
INTEGRATED DP INTERFACE
INTEGRATED 24V DC POWER SUPPLY
64 KBYTE WORKING MEMORY
FRONT CONNECTOR (1 X 40PIN)
AND MICRO MEMORYCARD REQUIRED
SSTPFBSLC
DISCONTINUED BY MANUFACTURER
BACKPLANE COMMUNICATION MODULE
SLC 500
PROFIBUS ADAPTER MODULE
FOR SLC
1 PROFIBUS
5 VDC BACKPLANE
750 MA
Tariff Code: 8517620050
Country of Origin: Canada
8 channels for 230 V a.c./d.c.
relay Normal Open (NO) outputs
8 isolated channels
Output status indicators
OSP sets outputs to predetermined
state upon error detection
1794ASB
DISCONTINUED BY MANUFACTURER 2015-03-30
REMOTE I/O ADAPTER
24 VDC
FLEX
8 POINT
NETWORK: UNIVERSAL REMOTE I/O
I/O MODULE
Tariff Code: 8517620050
Country of Origin: United States
1771IFE
DISCONTINUED BY MANUFACTURER 05/31/2017
INPUT MODULE
16 POINT
ANALOG
12 BIT
0.75 AMP
5 VDC
Tariff Code: 8538909100
Country of Origin: United States
Number of inputs:16, nonisolated
On-state voltage, min:159V AC
On-state voltage, nom:240V AC
On-state voltage, max:264V AC
On-state current, min:5.30 mA
On-state current, max:13.29 mA
Nominal input impedance:22.2 kΩ
Nominal input current:11 mA @ 240V AC
Flexbus current:32 mA @ 5V DC
Power dissipation, max:6 W @ 264V AC
Number of I/O channels:16, nonisolated
On-state current:50 mA min per output
Surge current:7 A for 40 ms each
Off-state leakage, max:2.5 mA
Field Bus current:116 mA
Power dissipation, max:6 W @ 264V AC
Thermal dissipation, max:20.47 BTU/hr @ 264V AC
1734IT2I
I/O MODULE
TEMPERATURE
2 DIFFERENTIAL THERMOCOUPLES INPUTS
175 MA POINT BUS CURRENT
24 VDC
Tariff Code: 8538907080
Country of Origin: Singapore
AC SERVO DRIVE
VARIABLE FREQUENCY
3 PHASE
380/480 VAC
50/60 HZ
20 HP
29 AMP
NORMAL DUTY
OPEN LOOP VECTOR CTRL
CLOSED LOOP IND MOTOR CTRL
REGENERATIVE CONTROL
Discrete output number16
Discrete output typeSolid state protected
Discrete output voltage:24 V DC positive conforming to EN/IEC 61131-2 19...30 V
Discrete output current:0.5 A
Current per channel:0.625 A
Minimum load impedance:48 W
isalotion resistance:> 10 MOhm 500 V
Current consumption:80 mA at 5 V DC
Discrete input voltage:24 V DC positive
Sensor power supply:19…30 V
Discrete input current:3.5 mA
isalotion resistance:< 10 MOhm 500 V DC
ambient air temperature for operation:0…60 °C
Ambient air temperature for storage:-25…70 °C
