ALL MANUFACTURERS

1336 PLUS II AC Drive

1336FBRF75AAEN
DISCONTINUED BY MANUFACTURER
AC DRIVE
1336 PLUS II ADJUSTABLE FREQUENCY
380-480 V AC
513-620 V DC
5.5 KW / 7.5 HP
IP 20 / NEMA 1 ENCLOSURE
FRAME SIZE A4
Tariff Code: 8504409570
Country of Origin: United States

SLC Lithium Battery

1747BA
LITHIUM BATTERY ASSEMBLY (FOR RAM MEMORY RETENTION)
NON-RECHARGEABLE
3 VOLT
850 MAH

Compact I/O module

1769IQ32
INPUT MODULE
COMPACTLOGIX
DC DIGITAL
32 POINT
10-30 VDC
SINKING / SOURCING
LED INDICATORS
DIN RAIL MOUNT

TP1500 Comfort Panel

SIMATIC HMI TP1500 Comfort
Comfort Panel, touch operation
15" widescreen TFT display
16 million colors, PROFINET interface
MPI/PROFIBUS DP interface
24 MB configuration memory
Windows CE 6.0

MA0186100
S908 RIO COAX NET SPLITTER
1 INPUT
2 OUTPUTS

CPU Module

140CPU43412
DISCONTINUED BY MANUFACTURER
CPU MODULE
486
2MEG SRAM 2 X MODBUS 1XMODBUS KYSW
Tariff Code: 8537109060
Country of Origin: United States

Hot Standby Module

140CHS11000
DISCONTINUED BY MANUFACTURER
STANDBY MODULE
HOT QUANTUM S911
CONCEPT VERSION
PROWORX 32 NXT VERSION V2.0
10 MBIT/S
700 MA
13/848 MS SWITCHING TIME
FIBER OPTIC 3 M
Country of Origin: France

Processor module

Operating Voltage: 24 VDC
Typical: 6 W
Maximum: 6 W
Operating Temperature Range: -20°C to +70°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% non-condensing

Load Sharing Module

9907175
LOAD SHARING MODULE
ISOCHRONOUS & DROOP LOAD-SHARING
24 VDC SUPPLY
WITHOUT PWM OUTPUT SURGE PROTECTION
FOR DIGITAL SPEED CONTROL

speed control device

Model Type:peed Control, Isochronous
Prime Mover Type:Diesel or Gas Turbine
VDC Power Supply:24
Power Supply: 24 VDC
Frequency Range: Operates within a 3000-6000 Hz range.
Input/Output: Compatible with
Woodward actuators 1712, 1724, 512, and 524.
Ambient Temperature Range: -40°C to 167°C (-40°F to 334°F).
Power Consumption: Up to 95 watts.

Guardmaster Safety Relays

Input Voltage: 24V DC.
Rated Voltage Range: 20.4V DC to 28.8V DC.
Max Current Consumption: Typically 50 mA.
Relay Contacts Ratings: 250VAC, 3A, 30VDC.
Operating Temperature Range: Typically -20°C to +55°C

ControlLogix-XT Logix5563 Processor

1756L63XT
CONTROLLER
CONTROLLOGIX MODULE
8 MB USER MEMORY
MEMORY CONTROLLER
5.1/24VDC
14MA
1.2A
EXTENDED TEMPERATURESERIAL PORT
250 CONTROLLER CONNECTIONS
DISPLAY LEDS
1200MA

ControlLogix Logix5563 Processo

1756L63
CONTROLLER MODULE
CONTROLLOGIX
LOGIX 5563
32 TASKS
100 PROGRAMS / TASK
1 PORT RS-232 SERIAL
8 MB USER MEMORY
478 KB I/O MEMORY

SIGNAL CONDITIONING BOARD

8019038002R
CIRCUIT BOARD ASSEMBLY
SIGNAL CONDITIONING BOARD
FOR INVERTER

RECTIFIER BOARD PKGD CUSTR SCB

RECTIFIER BOARD PKGD CUSTR SCB
Input Voltage:380V AC (±10%), 3-phase
Input Frequency:50/60Hz (±5%)
Output Voltage:540V DC (nominal)
Output Current:10A continuous, 15A peak (5 sec)
Efficiency:≥92% at full load
Ripple Voltage:<3% of Vout (full load)

Ethernet Diagnostische Module

DIAGNOSTICS MODULE
REMOTE ACCESS
4 PORT
ETHERNET

Block I/O Module

179116BC
DISCONTINUED BY MANUFACTURER 06/30/2015
I/O BLOCK MODULE
16 INPUT
16 OUTPUT
10-30 VDC
BLOCK I/O MODULE
24V DC

Network InterfaceCard

1784PKTS
DISCONTINUED BY MANUFACTURER
INTERFACE CARD
PCI BUS
W/ RIO SCANNER
1 CHANNEL

ProcessLogix Processor

ProcessLogix CPU Controller Module
Can be installed into any
two consecutive slots of the chassis
(default location is slots 1 and 2)
Operating Temperature Range: 0°C to 60°C
Storage Temperature Range: -40°C to 85°C
Relative Humidity: 5% to 95% non-condensing

ControlLogix Analog Current/Voltage Input Module

1756SCIF8H
DISCONTINUED BY MANUFACTURER
INPUT MODULE
8-POINT
ANALOG
W/HART PROTECTION
CONTROLOGIX
Country of Origin: United States

ControlLogix Remote I/O Communication Module

1756RIO
COMMUNICATIONS MODULE
CONTROLLOGIX
REMOTE I/O SCANNER/ADAPTOR
1 CHANNEL

ControlLogix Logix5564 Processor

CPU MODULE
CONTROLLOGIX
LOGIX5564
16 MB MEMORY

COMMUNICATION INTERFACE MODULE

COMMUNICATION INTERFACE MODULE
DATA HIGHWAY PLUS BRIDGE
REMOTE I/O SCANNER
2 CHANNEL
850 MA
24 VDC

Termination Panel

1746HT
TERMINAL PANEL
DIN RAIL
ESTOP
FAST I/O
ENCODER
DRIVE
EXT POWER 5VDC
15VDC
24VDC
