CompactLogix 5370 L1 Ethernet Processor Module

Product Family:5370 L1
Product Type:CompactLogix Controller
Communication ports:(1) USB; (2) Ethernet I/P
Ethernet topologies:Linear, Star and Device level Ring (DLR)
Ethernet nodes:8 Nodes
Maximum number of I/O modules supported: 8 Modules - Point I/O
No. of Task:32 Task
No. of Program per Task:100
No. of Embedded Inputs:(16) 24 VDC
Mounting:DIN Rail
Current draw @ 5V DC:1A
Integrated Motion:Supported
Motion Axes:1 or 2

Current Input Module

Number of input channels 16 channels,
module isolation (*5)
Rated input range 4 to 20 mA
Permissible input range 0 to 25 mA
Input impedance during Power-OFF 500 kΩ minimum
Data update frequency 40 ms
Temperature drift ±16 µA/10 °C
Withstand voltage 1.5 kV AC between input signal and system for 1 minute

DIGITAL I/O MODULE

DIGITAL I/O MODULE
HORIZONTAL UNIT
6 FORM A OUTPUTS
4 DIGITAL INPUTS

UNIVERSAL RELAY

UNIVERSAL RELAY
SERIES UR
CT/VT MODULE
3-PHASE
1A/5A

CPU module

Ethernet: 10/100 Mbps
Operating Temperature: -40°C to +70°C.
Storage Temperature: -40°C to +85°C.
Humidity: 5% to 95% non-condensing.
Low voltage: 24-48 V DC.
High voltage: 100-250 V AC or 110-250 V DC
Power Consumption: Maximum 50 W

Processor Module

Operating Voltage Range:  24 V DC
Current Consumption:  500 mA to 1 A
Operating Temperature:  0°C to 60°C
Storage Temperature:  -20°C to 70°C

Digital Signal Processor Control Board

Series: Mark V
Power Requirements: +5 V dc, 6 A
Number of relay channels: 12
Trip Solenoid Rating: 125 V dc
Power supply voltage: 28 V dc
Voltage Range: 18 - 32 VDC
Mounting Option: DIN-rail mounting
Operating temperature: -30 to +65 degrees Celsius

CANAL CABLE PREFAB D-CLIQ 2M

SIGNAL CABLE PREFAB 0.5M

REASSEMBLIED SIGNAL CABLE 8M

SIGNAL CABLE PREFAB D-CLIQ 1M

SIGNAL CABLE PREFAB D-CLIQ 7M

D-CLiQ CABLE IP20/20-PREFAB W/O 24V 6M

3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 70 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

SINAMICS S120 DOUBLE MOTOR MODULE INPUT

DOUBLE MOTOR MODULE
SINAMICS S120
INPUT: 600 VDC
OUTPUT: 3 PHASE 400 VAC
18A/18A
FRAME BOOKSIZE
C-TYPE
INTERNAL AIR COOLING

Single Motor Module

SINAMICS S120
SINGLE MOTOR MODULE
INPUT: DC 600V
OUTPUT: 3AC 400V, 132A
FRAME SIZE: BOOKSIZE INTERNAL
AIR COOLING OPTIMIZED PULSE SAMPLE
AND SUPPORT OF THE EXTENDED
SAFETY INTEGRATED FUNCTIONS
INCL. DRIVE-CLIQ CABLE

Screw Clamp E Terminal Base

Position Measurement Module

Series:XM
Part Number:1440-TPS02-01RB
Item Name:Measurement Module
Type:XM-320 Position
Sub Brand:XM
Voltage Rating :24 VDC
Amperage Rating:200 mA
Wattage:5.28 W
Number Of Channels:2
Temperature Rating:-20 To 65 degrees Celsius
Mounting:Terminal Base

Control Supply Module
