PowerFlex 700 AC Drive 30 A at 15 kW 20B

Processor Module

SCP46151
PROCESSOR MODULE
ENHANCED RFI
ISA STANDARD G3
FOR SSC60S
SSC60D

Digital Output Module

Number of outputs 16-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 3.4 A minimum
Maximum leak current at output off status 1.6 mA
Output format Current source
Maximum load current 0.2 A/output line
Minimum load current 35 mA
Load resistance range 120 to 685 Ω
Output response time 30 ms maximum

Current Input Module

Number of input channels:16, isolated
Input signal:4 to 20 mA
Allowable input current:24 mA
Accuracy:±16 µA
Data update period:10 ms
Drift due to ambient temperature change:±16 µA/10 ˚C
Maximum current consumption:230 mA (5 V DC), 540 mA (24 V DC)

ESB Bus Coupler Module

Function: ESB bus master interface function
Number of connectable units: 9 units maximum
Transmission speed: 128 Mbps
(I/O module data transmission)
Transmission distance: 10 m maximum
Current consumption: 0.5 A

Digital Input Module - 8DI 24VDC

CPU103 Processor Module

Compact Tension Measurement Unit

Digital Input Module
