Range of product:Altivar
Product or component type:Communication module
Communication port protocol:Profibus DP V1
Electrical connection:1 female connector SUB-D 9
Transmission rate:9.6 kbps...12 Mbps
Elliptical clamp shape improves access
to earth cables and straps up to 50 mm
Low maintenance flat jaw interface
Measures ground resistance from 0.05 Ω to 1500 Ω
Measures true RMS ground leakage current from
0.5 mA rms to 35 A rms
CAT IV 600 V safety rating
Backlit LCD display
Application Memory:4 MB
Safety Memory:2 MB
Non-volatile memory:2GB via 1784-SD2
Local I/O modules:31 I/O modules
Communication Ports:1 Type B 2.0
Full-Speed USB and 2 Ethernet/IP Ports
Communication rate, Ethernet:10 Mbps / 100 Mbps / 1 Gbps
User Memory:4 MB + 2 MB safety
Ports:2 Ethernet
Range of Product:Modicon Premium Automation platform
Product or Component Type:Double-format PL7 processor
Software Designation:PL7 Junior/Pro
Number of racks:16 4/6/8 slots/8 12 slots
Discrete I/O processor capacity:1024 I/O
Analogue I/O processor capacity:128 I/O
Number of application specific channel:32
MICROMASTER 440
without filter 380-480 V
3 AC +10/-10% 47-63 Hz
constant torque 15 kW
overload 150% 60 s,
200% 3 s square-law torque 18.5 kW
520x 275x 245 (HxWxD)
degree of protection IP20 ambient
temperature -10+50 °C
without AOP/BOP
MICROMASTER 440
without filter 380-480 V
3 AC +10/-10% 47-63 Hz
constant torque 5.5 kW
overload 150% 60 s,
200% 3 s square-law torque 7.5 kW
245x 185x 195 (HxWxD)
degree of protection IP20
ambient temperature -10+50 °C
without AOP/BOP
Max number of mountable I/O modules:8
Number of mountable Power suply modules:2
S Standard type
0 19-inch rack-mounted
BASE MODULE
STYLE S1
STANDARD TYPE
19 INCH RACK
DIN MOUNT
(92F306027)
Interface:RS-422/RS-485 (2 ports)
How connected:Multipoint
How communicates Half-duplex/Full-duplex
How synchronizes Start-stop synchronization
Transmission code ASCII/binary
Character length:7/8 bits
Stop bit :1/2 bits
Parity check None/even/odd
Transmission distance Maximum:1200 m
Current consumption:500 mA
Number of input channels:12, isolated
Allowable input voltage:±5 V
Between input and system: 1500 V AC for 1minute
Power ON :2 MΩ or more
Power OFF: 2 MΩ or more
Allowable total resistance of signalsource plus wiring:40 Ω or less
Effect of allowable signal source resistance (1000 Ω): ±20 μV
Measurement current:1 mA
Temperature drift:Max. ±30 ppm/°C
Maximum current consumption:450 mA (5 V DC)
Allowable input voltage ±5 V.
Withstanding voltage :1500 V AC for 1minute
Power ON 2 MΩ or more
Power OFF 2 MΩ or more
Accuracy ±0.03% of full scale (for 0 to 400 Ω)
Allowable total resistance of signalsource plus wiring:40 Ω or less
(wiring resistance per wire)
Temperature drift:Max. ±30 ppm/°C.
Maximum current consumption:450 mA (5 V DC)
Number of input channels:32
Rated input voltage:24 V DC
Input ON voltage:18 to 26.4 V DC
Input OFF voltage:5.0 V DC or less
Input current (at rated input voltage):4.1 mA±20 % / channel
Instantaneous allowable maximum input voltage:30.0 V DC
Input response time:8 ms or less
Minimum ON detection time:20 ms
Maximum ON/OFF cycle:25 Hz
Maximum current consumption:500 mA (5 V DC)
Number of output channels:64
Rated applied voltage:24 V DC
Load voltage:24 V DC, 100 mA
Field power supply voltagerange:20.4 to 26.4 V
Output ON voltage maximumvalue:2 V DC
Leak current maximum valuewhen output OFF:0.1 mA
Output format:Current sink
Number of input:channels16, non-isolated
Input signal:4 to 20 mA
Allowable input current/voltage:27 mA
Accuracy:±0.1% of full scale
Data refresh cycle:10 ms
Input step response time:100 ms
Transmitter power supply:22.8 to 26.4 V
Setting of 2-wire or 4-wiretransmitter
For each channel by setting pin
Power Requirements 5 VDC, ± 5% a
USB Annunciator Keyboard: 300 mA (max)
Output Impedance: 1200 Ohms Nominal
Nominal Level: 0.437 to 0.133
Peak to Peak Amplitude, Vpp: 0.872
Operating Temperature 0 to 40°C (32 to 104°F)
Storage Temperature -40 to +70°C (-40 to 158°F)
Humidity range, storageand operating:
20% to 80%, non-condensing
