I/O Module

Power Supply: Typically on 24V DC
Input Voltage: Typically 24V DC for digital inputs
Output Voltage: Usually 24V DC.
Operating Temperature: Typically between 0°C and 55°C
Storage Temperature: Typically ranges from -20°C to 70°C
Humidity: Typically rated for 5% to 95%

SSI Speed Sensor Interface

Frequency:62.5 kHz
Cable Length Support: Up to 350 meters
Internal Logic Supply: +5V DC
Encoder Supply: +24V DC
Current Limit: Typically 250mA

Quad Processor Pack

two processors running synchronously
flash memory for system and application program
RAM with battery backup
a redundant communication link
RAM for the redundant communication link data
data comparators for the processors and their memory
data exchange with its communication modules
Surge Protection ±1kV (I/O lines)

Digital Output Module

Channels: 20 single-ended channels
Voltage: ±10 V DC
Current: 0–20 mA, 4–20 mA
Voltage Inputs: >1 MΩ.
Current Inputs: 250 Ω
Noise Rejection: >80 dB (50/60 Hz)
Channel-to-Backplane: 1,500 V AC RMS

Yokogawa Power Module

COMMUNICATION UNIT

Data Throughput: Up to 10,000
RAM: 512 KB
Voltage: +5V DC
Consumption: 10 W (typical)
Isolation:1500V AC
Fiber optic: Up to 4 km
Max Nodes: Up to 250 devices per loop

Control unit

Processor:32-bit
I/O Capacity Up to 1,024 I/O points
Voltage: +5V DC
Consumption: 15 W
Battery Backup:BCL003 battery module

Modbus TCP Interface Module

Data Types:16-bit & 32-bit integers
Voltage: 5 V DC
Power Consumption: Typically 1.5 W
Isolation:1500 V AC galvanic

Central Processor

Multi Fuel-flame Detector

Detection Range:Up to 40 meters
Response Time:< 3 seconds
Supply Voltage:24 V DC
Power Consumption:4–8 W (DC)
Relay Contacts: 2× SPDT
Analog Output: 4–20 mA

100-BASE-T CABLE (20M)

Cable Type:Industrial Ethernet (CAT5e)
Length:20 meters (±1%)
Bandwidth:100 MHz
Data Rate:100 Mbps
Impedance:100Ω ±15%
DC Resistance:≤9.38Ω/100m
Capacitance:≤5.6nF/100m
Max Voltage:30V AC

100-BASE-T CABLE (10M)

Category:CAT5e
Length:10.0 meters (±1%)
Bandwidth:100MHz
Data Rate:100Mbps
Characteristic Impedance:100Ω ±15%
Conductor Gauge:24 AWG stranded copper
DC Loop Resistance:≤9.38Ω/100m
Capacitance:≤5.6nF/100m
Max Operating Voltage:30V rms

100-BASE-T CABLE (5M)

100-BASE-T CABLE (5M)
Category:CAT5e
Length:5.0 meters (±0.5%)
Data Rate:100Mbps
Impedance:100Ω ±15%
Conductor Gauge:24 AWG stranded
DC Resistance:≤9.38Ω/100m
Capacitance: ≤5.6nF/100m
Max Voltage:30V AC

EUCN Cable 20 m

EUCN Cable 20 m
(Tree B-Green Boots)
Length:20 meters (±1%)
Data Rate:1Gbps
Impedance:100Ω ±10%
DC Resistance:≤7.5Ω/100m
Capacitance:≤4.5nF/100m
Conductors:4 twisted pairs (23 AWG)

100-BASE-T CABLE (10M)

10 m (33 ft)
Data Rate:100Mbps
Characteristic Impedance:100Ω ±15%
Max DC Resistance:9.38Ω/100m
Capacitance:≤5.6nF/100m
Insertion Force:≤20N
Durability:≥750 mating cycles

100-BASE-T CABLE (5M)

5 m (16 ft)
Cable Type:Ethernet Patch Cable
Category:CAT5e
Length:5 meters (±0.5%)
Data Rate:100Mbps
Impedance:100Ω ±15%
Conductor Gauge:24 AWG stranded copper
DC Resistance:≤9.38Ω/100m

100-BASE-T CABLE

100-BASE-T CABLE  (2M)
2 m (6.5 ft)
(Y) = Yellow codedboots
(G) = Green codedboots

RELAY CABLE ASSEMBLY

50.0 METER LENGTH
DO (SOURCE)
RELAY CABLE ASSEMBLY

RELAY CABLE ASSEMBLY

40.0 METER LENGTH
DO (SOURCE)
RELAY CABLE ASSEMBLY

RELAY CABLE ASSEMBLY

30.0 METER LENGTH
DO (SOURCE)
RELAY CABLE ASSEMBLY

RELAY CABLE ASSEMBLY

20.0 METER LENGTH
DO (SOURCE)
RELAY CABLE ASSEMBLY

RELAY CABLE ASSEMBLY

10.0 METER LENGTH
DO (SOURCE)
RELAY CABLE ASSEMBLY
