ALL MANUFACTURERS

POWER SUPPLY MODULE

Redundant CPU
Redundant Power
Redundant I/O cable
Cyclic scan
Time-driven interrupts
InternalMemory interrupts

CPU Module

Max. I/O: 3,072Pts
128KB Program Memory
IEC, Standard
Reiterative operation
fixed cycle operation
constant scan
Ladder Diagram

Redundant Controller

Minimum PowerConsumption
where thereare no expansion IOMs
Power is supplied to the controller
I/O modules through the power input terminals
the controller IOTA and the left endplate, (when used)
The relevant specifications at each
power input terminals are detailed below

CAB Developer

CAB Developer
Application Development Tools
Application Enablers
Enables ODBC driver
ODBC data exchange

Equipment Point Adders to Database Size

100 Equipment Point Adders to Database Size
Application Development Tools
and Application Enablers
Enables ODBC driver
ODBC data exchange
server automation object features

Quad Processor Pack

Two processors running synchronously
Flash memory for system and application program
Flash memory for backup of system and application program
RAM with battery backup (battery located in BKM-0001)
Aredundant communication link with the other Control Processor
RAM for the redundant communication link data
Data comparators for the processors and their memory
Data exchange with its communication modules

PlantCruise 50,000 SCADA Points Redundancy Adder

Server Redundancy
SCADA Points
PlantCruise 50,000 SCADA Points
Redundancy Adder

PlantCruise 100 SCADA Points Adder

PlantCruise 100 SCADA Points Adder
to Database Size
PlantCruise SCADA Point Adder 100 POINT

PlantCruise 100 Process Point Adder

PlantCruise 100 Process Points Adder
to Database Size
Software License
PlantCruise DCS System
Requires PlantCruise Base (CV-DBASE1)

PlantCruise Process points with base

Active Directory/LDAP
PlantCruise (Process Points License)
Up to 50,000
Scan Rate:100ms (configurable)
Alarm Handling:10,000 alarms/sec
Historical Data Storage:1M tags @ 1-sec intervals
Redundancy Switchover:<1 sec

PlantCruise Base Software

SCADA Interfaces
OPC and Data Exchange Options
Version Designation:CV-DBASE1
Type:Process Control System
Architecture:Distributed Client-Server
Deployment:Virtualized/Physical
Real-time Control:100ms scan cycles
I/O Capacity:50,000 points
Alarm Management:10,000 alarms/sec
Historical Storage:1M tags @ 1sec intervals
Redundancy:Hot standby servers

Safety Builder R100.3 software

Model Number:FS-SMSB-ST-120
Software Name:Safety Builder R100.3
Processor:Intel i7 2.8GHz or equivalent
RAM:16GB (32GB recommended)
Storage:500GB SSD
Basic Windows 2000/XP

Eddy Current Displacement Sensor

Linear Measurement Range 2 mm (80 mils)
Initial Air Gap 0.5 mm (20 mils)
Frequency Range (-3 dB):0 to 20,000 Hz
Rise Time:<15µs
Supply Voltage Range-23V to -32V

CPU MODULE

2MLK-CPUH-CC
CPU
I/O MODULE
NON-IEC
HIGH PREFORMANCE
CONFORMANCE COATED

CONNECTOR CABLE

CONNECTOR CABLE
I/O LINK
30V
20PX28AWG
40-PIN FEMALE CONNECTOR
3 FT LENGTH

CONNECTOR CABLE

CONNECTOR CABLE
I/O LINK
30V
20PX28AWG
40-PIN FEMALE CONNECTOR
4-1/2 FT LENGTH

DeviceNet Master module

Model Number:2MLL-DMEB
Type:DeviceNet Master/Scanner Module
Input Voltage:24V DC (18-36V)
Power Consumption:5.5W (typical)
Network Interface:5-pin screw terminal
Isolation:1500V AC
Surge Protection:±2kV

PROFIBUS-DP REMOTE INTERFACE

PROFIBUS-DP REMOTE INTERFACE
I/O MODULE
Profibus, Remote Interface
DP standard
used on ML200 racks only

Computer Link I/F Module

Model Number:2MLL-CH2B
Type:High-Speed Computer Communication Interface
Input Voltage:24V DC (18-36V)
Power Consumption:3.8W
Isolation :1500V AC )
Port Configuration:2x serial ports
Surge Protection:±2kV
Data Rate:300-115.2kbps

Analog Input and Output Module

Model Number:2MLL-C42B
Type:High-Density Analog I/O Module
Channels:4 AI + 2 AO (Isolated)
Resolution:16-bit (0.0015% of span)
Voltage Ranges:±10V, 0-10V
Current Ranges:0-20mA, 4-20mA
Accuracy:±0.05% of span
Update Rate:10ms/channel
Isolation:1500V ch-ch

Cnet I/F Module

Model:2Mll-c22B / C22B
Operating System:V5.00
Communication Interface:Cnet I/F, RS-232C, 2Ch
Input Voltage:24V DC
Power Consumption:4.8W (typical)
Network Connector:BNC
Isolation:1500V AC
Surge Protection:±2kV

Fast Ethernet Module

Product Type : Fast Ethernet
Modules : 2MLL-EFMFB
Ethernet Standard : IEEE802.3U
Protocol : TCP-IP, UDP-IP
Input Voltage:24V DC (18-36V)
Power Consumption:5.5W (max)
Isolation :2500V AC (copper-to-fiber)
Surge Protection:±4kV

Fast Ethernet Module

Product Type : Fast Ethernet
Modules : 2MLL-EFMT
Ethernet Standard : IEEE802.3U
Protocol : TCP-IP, UDP-IP

ANALOG INPUT MODULE

INPUT MODULE
MASTERLOGIC-200
8 POINT
ANALOG
8 channel Current Input Module

Digital Output Module

DIGITAL OUTPUT MODULE
12/24 VDC
0.5 AMP
16 POINT
TRANSISTOR OUPTUT
PHOTO COUPLER ISOLATION
RESPONSE TIME 1 MS OR LESS
