Enhanced Keyphasor Module

3.2 Watts typical
21.8 kΩ minimum
Specified at +25°C (+77°F).
Proximity: -2V to -18V
MPU: 5 mV to 50 V peak
Range: 1 RPM to 99,999 RPM
Accuracy: ±0.1% of reading

OVERSPEED DETECTION SYSTEM

OVERSPEED DETECTION SYSTEM
FOR THE 3500 SERIES MACHINERY DETECTION SYSTEM
ELECTRONIC
INPUT IMPEDANCE: 20 K
8.0 WATTS
OUTPUT IMPEDANCE: 550
24VDC
40MA MAX.

Vibration Transmitter

0 1 35 mm DIN rail clips
0 0 Not required
ATEXZone 2 and includes ABS maritimeapproval
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.

3300 XL 8 mm Reverse Mount Probes

330105-02-12-CC-DD-EE3/8-24 UNF threads
90 9.0 meters (29.5 feet)
02 Miniature ClickLoc coaxialconnector
05 CSA, ATEX, IECEx  Approvals

3300 NSv Extension Cable

3300 NSv Extension Cable
040 4.0 meters (13.1 feet)
01 With stainless steel armor, withFEP jacket
00 Not Required

3300 XL 8 mm Probe

3300 XL 8 mm Probe, M10 x 1 thread,without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
05 CSA, ATEX, IECEx  Approvals
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm
StandardProbe-52°C to +177°C
ExtendedTemperatureRange Probe-52°C to +218°C

Tachometer Module

350050M
TACHOMETER MODULE
5.8 WATT
3 LED
550 OHM
2 INPUT

Input/output card

IOC4T
DISCONTINUED BY MANUFACTURER
I/O MODULE

CMC16
CONDITION MONITORING CARD 16 CHANNELS

3500/04 Earthing I/O Module

13671901
GENERAL ELECTRIC
BENTLY NEVADA
136719-01
PROXIMITOR/SEISMIC MONITOR MODULE
BARRIER I.S. EARTH MODULE
TWO I.S. EARTH CONNECTIONS
EARTHING I/O MODULE
241X24.4X103.1MM

3300 XL 11 mm Proximity Transducer

080 8.0 meters (26.2 feet)
00 Standard cable
00 Not required

3300 XL 11 mm Proximity Probes

3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

8415201
DISCONTINUED BY MANUFACTURER
ALARM RELAY OUTPUTS QUAD SIRM

8414501
DISCONTINUED BY MANUFACTURER
SEISMIC DUAL EPOXY RELAY

8414001
DISCONTINUED BY MANUFACTURER
I/O RECORD TERMINAL
SEISMIC
DUAL RELAY

8292601
DISCONTINUED BY MANUFACTURER
RELAY BOARD

Signal Input/Alarm Output Module

8154501
DISCONTINUED BY MANUFACTURER
INPUT/RELAY BD
Tariff Code: 8517620050
Country of Origin: United States

Tachometer Module

3300-50
TACHOMETER
DUAL SETPOINT
4-20 MA OUTPUT
SINGLE CHANNEL MONITOR
