ALL MANUFACTURERS

ANALOG INPUT MODULE

INPUT MODULE
ANALOG
DIFFERENTIAL./ SINGLE ENDED INPUT
16 CHANNEL
4-20 MA
0-5 VOLT
60 WATT
POWER & STATUS LED
HIGH LEVEL / G3

Quad Processor Pack (conformal coated)

Remote Node Controller EMOD

1C31203G01
REMOTE I/O NODE CONTROLLER
+5V power for the module

51304485100
DISCONTINUED BY MANUFACTURER
INPUT MODULE
DIGITAL

Main Processor Module

Nominal input voltage:24 V D
Operational voltage range:
24 V DC –15%/+20% + 5% AC ripple
Logic power:8 W maximum
input voltage:33 V DC
reverse input voltage:–0.6 V DC
Short circuit current limit per input:2.4 A maximum

Digital Input Baseplate

Fault current130 mA,
typical200 mA, maximum
Voltage Range: Typically 24 V DC
High (ON): 15–30 V DC
Low (OFF): 0–5 V DC
Channel-to-channel isolation: ≥ 1500 V AC/DC
Typical: < 10 ms

Digital Output Baseplate

Voltage Range: 24 V DC
Max Continuous Current: 2 A per channel
Inrush Current: Supports up to 5 A for 100 ms
Channel-to-channel isolation: ≥ 1500 V AC/DC
Turn-On Delay: < 1 ms
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)

Trusted Expander Processor

Input Voltage: 24 VDC (Nominal)
Current Consumption: Typically 1.5 A
CPU Type: 32-bit microprocessor based
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)

Digital Input Module

DIGITAL INPUT PROCESSOR MODULE
32 INPUT CHANNELS
IOPS CONFORMALLY COATED
24 VDC
120/240 VAC
DI IOP
(MC-PDIX02)

IOP351
DISCONTINUED BY MANUFACTURER
RELAY OUTPUT MODULE

6636166A3
DISCONTINUED BY MANUFACTURER
KEYBOARD ASSEMBLY
