AMIKONG EXCESS CONTROL SYSTEM PARTS
Specializing In:Automation Spares(DCS, PLC, CNC) Servo Drives HMI Power supplies Controllers
-
Please try to be as accurate as possible with your search.
-
We can quote you on 1000s of specialist parts, even if they are not listed on our website.
-
We can't find any results for “”.
SEE PRODUCTS IN SEARCH PAGE ()
In Stock
Ships by Thursday, July 2
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 1756-EN2T
-
Product Model1756-EN2T
-
Spare Model1756EN2T
-
Product ParametersControlLogix EtherNet/IP bridge Module 10/100 FE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size3.5x14x14.5cm
-
ManufacturerAllen-Bradley
-
Weight0.2 kg
-
Ethernet-IP Communication Rate10/100 Mbps
-
Insulation Voltage30 Volts Continuous
-
Integrated PortsOne (1) RJ45; One (1) USB 1.1
-
Current Draw1 Amp
-
LocationChassis (any slot)
-
Current Rating1.2 Amps
Description
The Allen-Bradley 1756-EN2T is a ControlLogix EtherNet/IP communication interface module designed to provide high-speed Ethernet connectivity for ControlLogix automation systems. Manufactured by Rockwell Automation, the module enables communication between ControlLogix controllers, distributed I/O devices, HMIs, SCADA systems, drives, and other EtherNet/IP-enabled equipment over standard industrial Ethernet networks.
The 1756-EN2T serves as a bridge between the ControlLogix backplane and Ethernet networks, supporting real-time I/O messaging, controller-to-controller communications, data acquisition, remote programming, diagnostics, and supervisory control functions. Its high-performance architecture makes it suitable for large-scale industrial automation applications requiring reliable network communications and deterministic data exchange.
The 1756-EN2T serves as a bridge between the ControlLogix backplane and Ethernet networks, supporting real-time I/O messaging, controller-to-controller communications, data acquisition, remote programming, diagnostics, and supervisory control functions. Its high-performance architecture makes it suitable for large-scale industrial automation applications requiring reliable network communications and deterministic data exchange.
Revisions
Revision Part #
Also known as
Alternative Names
1756EN2T
I756-EN2T
I756EN2T
I756 EN2T
I756-ENZT
I756 ENZT
Information
Overview
Manuals
Technical notes
Product Applications
Formally Mount the Module
Features:
- Ethernet Communication Module
- 30 Volts Continuous
- 32 to 140 degrees Fahrenheit (0 to 60 degrees Celsius)
The 1756-EN2T Allen-Bradley Communication module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1756-EN2T Communication module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 1756-EN2T supports 10 to 100 Mbps EtherNet/IP communication rates and uses Twisted pair copper media. It supports 256 Logix and 128 TCP/IP communication connections. It can support a maximum of 8 axes for integrated motion on the Ethernet/IP Network and draws 1 A current at 5.1 Volts DC. It has a maximum power dissipation of 5.1 Watts and thermal dissipation of 17.4 BTU/hour.
It can be installed in any slot in the ControlLogix Chassis. For wiring, it uses unshielded RJ45, category 5, twisted-pair cable connectors to interface with the controller. To operate an EtherNet/IP network, parameters such as an IP address, Subnet masks, Gateway, etc. must be defined. The 1756-EN2T bridge has various functions like providing support for messaging, distributed I/O, and tags.
It encapsulates messages within standard TCP/IP protocol. ControlNet and DeviceNet network protocols allow it to share a common application layer. It does not require any scheduling or routing table to store information. Other features include a protected mode, an electronic keying, a device level ring network, and a parallel redundancy protocol network support.
- Distributed Process Racks:Hazardous field I/O to safe central rack
- Flow Meter and Custody Transfer Bridging:TCP/Modbus data from meters/gauges
- Emergency Shutdown System (ESD) Pipelines:SIL2 safety signals for pipeline valves
- Batch and Recipe Control:Connects ControlLogix to FactoryTalk Batch servers
- High-Speed Packaging Lines:Fast comms for sensors & pneumatic gates
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Align the module: Position the circuit board with the top and bottom guide rails inside the chosen chassis slot.
Slide and seat: Slide the module firmly into the chassis until the top and bottom retaining tabs click, locking the module flush against adjacent cards.
Removal/Insertion Under Power (RIUP): The 1756 architecture supports RIUP, meaning you can install or remove this communication module while chassis backplane power is actively applied without destroying the hardware.
Technical notes
Equipped with a 10/100 Mbps RJ45 Ethernet port, the 1756-EN2T supports EtherNet/IP communications based on the Common Industrial Protocol (CIP). The module facilitates real-time data exchange between controllers, operator interfaces, drives, remote I/O systems, and supervisory applications. Support for produced and consumed tags allows efficient controller-to-controller communications, while explicit messaging capabilities enable data exchange with a wide range of industrial devices.
FAQs
-
What is the 1756-EN2T?
+It is a communication bridge for the ControlLogix platform that enables data exchange over EtherNet/IP networks. -
What are the connection capacities?
+It supports up to 256 Logix (CIP) communication connections and 128 TCP/IP connections. -
Is this product brand new?
+Yes, AB 1756-EN2T is brand new, original, unused, and factory sealed
