          PRODUCT DESCRIPTION

          1756-IB16 16-point 12/24 V DC input module

          Allen-Bradley 1756-IB16 is a ControlLogix DC input module with 16 sinking input points arranged in two groups of eight. It serves nominal 12/24 V DC field circuits over a 10 to 31.2 V DC operating range.

          Selectable ON and OFF filters allow input response to be adjusted for the connected signals. The module provides group-to-group and input-to-backplane isolation without point-to-point isolation, and draws 100 mA at 5.1 V plus 2 mA at 24 V from the backplane.
          BEFORE YOU BUY

          Confirm the complete 16-point 12/24 v dc input module

          Send a label photo for review >>
          ACTUAL APPLICATIONS

          Application context for 1756-IB16

          1756-IB16 supports compatible ControlLogix 1756 I/O installations across the application categories below, subject to system configuration.
          • 01 · CHEMICAL & PETROCHEMICAL

            Basic Chemicals and Specialty Chemical Manufacturing

            Petrochemical ManufacturingFine Chemical Manufacturing
          • 02 · AUTOMOTIVE

            Vehicle Manufacturing and Automotive Component Production

            Commercial Vehicle ManufacturingAutomotive Electronics Manufacturing
          • 03 · METALS & MINING

            Metal Production and Mineral Resource Extraction

            Nonferrous MetallurgyNonmetallic Mining

          Technical specifications for 1756-IB16

          • Product Model
            1756-IB16
          • Product Parameters
            16-point 12/24 V DC input module
          • In stock
            1 unit
          • Manufacturer
            Allen-Bradley
          • Input points
            16, eight per group
          • Input type
            12/24 V DC sinking
          • Operating voltage
            10 to 31.2 V DC
          • Nominal voltage
            24 V DC
          • OFF-to-ON hardware delay
            290 us typical; 1 ms maximum
          • Selectable ON filter
            0, 1 or 2 ms
          • ON-to-OFF hardware delay
            700 us typical; 2 ms maximum
          • Selectable OFF filter
            0, 1, 2, 9 or 18 ms
          • 5.1 V backplane current
            100 mA
          • 24 V backplane current
            2 mA
          • Maximum power dissipation
            5.1 W
          • Continuous isolation
            250 V input-to-backplane and group-to-group
          • Point-to-point isolation
            None
          View all additional
          Ask for Quote

          Alternative Names

          1756-IB16 ControlLogix 1756 I/O 16-point 12/24 V DC input module 1756 I/O 16, eight per group input points
          SYSTEM & REPLACEMENT CHECK

          Information needed before ordering

          Three direct checks to secure your system integration and minimize ordering risks.

          Information

          System integration Replacement check Manuals & support
          SYSTEM INTEGRATION

          Integrate 1756-IB16 16-point 12/24 v dc input module

          1756-IB16 provides the documented function of a 16-point 12/24 V DC input module in the ControlLogix 1756 I/O platform. Match the complete article and revision with the host architecture before engineering approval.
          Review input points (16, eight per group), input type (12/24 V DC sinking) and operating voltage (10 to 31.2 V DC) against the electrical and functional design.
          Apply the documented connection and supply limits, validate nominal voltage (24 V DC) and retain the completed test record with the system documentation.

          Features:

          • Confirm input points: 16, eight per group
          • Match input type: 12/24 V DC sinking
          • Validate operating voltage: 10 to 31.2 V DC
          The 1756-IB16 16-point 12/24 v dc input module requires appropriate configuration before system integration and commissioning.
          INTERCHANGEABILITY

          Verify 1756-IB16 16-point 12/24 v dc input module

          Record the full 1756-IB16 identity, installed revision, wiring and configuration before removal. Isolate the applicable power and field circuits under the site maintenance procedure.
          Compare the replacement article's off-to-on hardware delay (290 us typical; 1 ms maximum) and selectable on filter (0, 1 or 2 ms) with the removed unit and purchase record.
          After installation, inspect connection integrity, confirm on-to-off hardware delay (700 us typical; 2 ms maximum) and verify selectable off filter (0, 1, 2, 9 or 18 ms) before return to service.

          Features:

          • Record off-to-on hardware delay: 290 us typical; 1 ms maximum
          • Inspect selectable on filter: 0, 1 or 2 ms
          • Test selectable off filter: 0, 1, 2, 9 or 18 ms
          The 1756-IB16 16-point 12/24 v dc input module requires replacement verification against the complete installed configuration and current manufacturer documentation.
          DOCUMENTATION STATUS

          Browse the Manuals, Datasheets, Official Documents, Links

          Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.

          Features:

          • Verify document identity before procurement or installation
          • Match the complete order to the manufacturer document scope
          • Accessories are supplied only when listed in the quotation
          Documentation for the 1756-IB16 16-point 12/24 v dc input module must be checked for document applicability before installation or commissioning.

          Also searched as

          1756-CNB 1756-L62 1756-DNB 1756-PB75 1756-L75

          Important notice

          Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
          This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
