Technical specifications for 1756-OF8
-
Product Model1756-OF8
-
Spare Model1756OF8 1756-OF8/A
-
Product ParametersControlLogix 8 Pt A/O I or V Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size23.3x18.3x5.3cm
-
ManufacturerAllen-Bradley
-
Weight0.35 kg
-
Output Current Range0-20 mA
-
Output Voltage Range+/- 10VDC
-
Resolution15bit
-
Overvoltage protection24V DC
-
Outputs8 Current-Voltage
-
Backplane Current (5Volts)140 milliamps
-
Backplane Current (24 Volts)210 milliamps
Description
OUTPUT MODULE
CONTROLLOGIX
ANALOG
8 POINT
SINGLE ENDED OUTPUTS
CURRENT AND VOLTAGE
CONTROLLOGIX
ANALOG
8 POINT
SINGLE ENDED OUTPUTS
CURRENT AND VOLTAGE
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
Core Electrical Protections
Diagnostic and Monitoring Functions
Features:
- ControlLogix voltage/current output analog module
- Analog I/O Modules
- All terminals marked RTN are connected internally
The 1756-OF8 Allen-Bradley Analog output module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1756-OF8 Analog output module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 1756-OF8 requires removable terminal blocks for wiring of input signals. Appropriate terminal blocks are 1756-TBNH and 1756-TBSH. For 1756-TBNH, applicable wire size is 0.33…2.1 mm2 (22…14 AWG) solid or stranded copper wire, rated at 105 °C (221 °F) or greater, 1.2 mm (3/64 in.) insulation max. for single wire connection and 0.33…1.3 mm2(22…16 AWG) solid or stranded copper wire, rated at 105 °C (221 °F) or greater, 1.2 mm (3/64 in.) insulation max. for double wire connection. When 1756-TBSH is used, appropriate wire size is 0.33…2.1 mm2 (22…14 AWG) solid, or stranded shielded copper wire rated at 105 °C (221 °F), or greater, 1.2 mm (3/64 in.) insulation max. Only single wire connection is applicable for the 1756-TBSH.
- Process Control & Optimization:Regulates flow, temperature, and pressure via proportional valves & actuators.
- Water & Wastewater Treatment:Manages chemical dosing pumps and modulates filtration flow.
- Food & Beverage Production:Controls pasteurization heaters & adjusts motor speeds for consistency.
- Pharmaceutical Manufacturing:Ensures climate/pressure control in clean rooms & manages batch reactors.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Short-Circuit Protection: All channels are electronically current-limited to 21 mA or less. This prevents damage if an output is inadvertently shorted to common.
Overvoltage Protection: The module can withstand external voltages up to 24V DC on its output terminals without sustaining damage. Some technical datasets from Rockwell Automation specify protection up to ±30V DC for certain isolated variants.
Reverse Current Protection: Built-in protection prevents damage from back-fed current, making the module an exception to standard output fusing recommendations in many applications.
Open-Circuit Detection: Available specifically for current outputs. It triggers when the output is set to more than 0.1 mA but the loop is broken.
Module Health Indicators: Front-panel LEDs provide immediate visual status on module power, communication, and individual channel faults.
Electronic Keying: A software-based protection that ensures the physical module in the chassis matches the configuration in the Studio 5000 Logix Designer (exact match or compatible revision) to prevent incorrect module replacement.
