1746OB16
I/O MODULE
16 OUTPUTS
10 TO 50 VOLT DC
280 MA @5 VOLT
BACKPLANE CURRENT LOAD
GENERAL PURPOSE DC OUTPUTS
FUNCTIONAL REPLACEMENT FOR 1746-OB8
I/O MODULE
16 OUTPUTS
10 TO 50 VOLT DC
280 MA @5 VOLT
BACKPLANE CURRENT LOAD
GENERAL PURPOSE DC OUTPUTS
FUNCTIONAL REPLACEMENT FOR 1746-OB8
Technical specifications for 1746-OB16
-
Product Model1746-OB16
-
Spare Model1746OB16
-
Product ParametersI/O MODULE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size24.5x16.5x5.5cm
-
ManufacturerAllen-Bradley
-
Weight0.4 kg
-
Voltage category24V DC Signal Output
-
Number of outputs16
-
Points per common16
-
Voltage, operating (V DC)10...50 (source)
-
Backplane currentconsumption 5V DC0.280 A
-
Off-state leakage, max1 mA
-
Load current, min1 mA
-
On-state voltage drop, max1.2V @ 0.50 A
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the 1746-OB16？+The Allen-Bradley 1746-OB16 is a 16-point DC digital output module for the SLC 500 programmable controller family. It is a sourcing output module, commonly used to switch 10-50V DC loads
-
How does the electronic protection work?+The 1746-OB16 features electronic protection against short circuits and overloads based on a thermal cut-out principle, which limits the current on a channel. It features auto-reset capability.
-
Does it have internal fusing for protection?+No, the 1746-OB16 has no internal fuse. External fusing is required to protect the module from short circuits or overloads.
-
What is the operating voltage of 1746-OB16?+In some specifications, its operating voltage is 10-50V DC or 10-30V DC.
-
What does the E-Fuse LED indicate?+The "E-Fuse" LED on the front panel lights up when an overload or short circuit condition is detected, indicating that the module is currently limiting the current on one or more outputs.
Get a quick price fo 1746-OB16
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Revisions
Revision Part #
Also known as
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Comparison with Related Models
Features:
- SLC 500 series
- 24V DC for signal output
- Electronically Protected Module
The 1746-OB16 output module, part of Allen Bradley's SLC 500 series, excels in facilitating automated control systems. With a total of 16 outputs grouped together for streamlined functionality, this module is rated for a voltage of 24V DC, ensuring compatibility with many signal output requirements. The operational voltage range extends from 10V to a maximum of 50V DC, providing flexibility in various applications.
The 1746-OB16 Allen Bradley I/O Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen Bradley 1746-OB16 I/O Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
In terms of performance, the module has a heat dissipation rating of 0.388 watts per individual output point, accumulating to a total output heat dissipation of 7.6 watts across the module. It has a minimum heat dissipation requirement of 1.4 watts, ensuring appropriate thermal management during operation.
Backplane current consumption is specified at 0.28 Amps when operating at 5V DC, with no current draw at 24V DC. When it comes to response times, users can expect a signal delay of 0.1 milliseconds when switching on and 1 ms for switch-off under maximum resistive load conditions. The maximum off-state leakage is recorded at 1 mA, while the module requires a minimum load current of 1 mA. Additionally, the maximum voltage drop in the on-state is limited to 1.2 volts when subjected to a current of 0.5 Amps.
- Manufacturing Automation:Controls actuators, solenoids & relays in high-speed linesC
- Material Handling:Drives conveyors, sorters & robotic pick-and-place units
- Process Control:Manages pumps, valves & level controls in small-scale process
- HVAC and Building Systems:Automates lighting, HVAC & access control
- SCADA and Remote Monitoring:RTU control signals from polled remote location data
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
The Allen-Bradley 1746-OB16 and 1746-OB16E are both 16-channel, current-sourcing DC output modules designed for the SLC 500 programmable controller platform. The primary distinction lies in their protection mechanisms: the 1746-OB16E provides enhanced electronic protection against short circuits and overloads, while the 1746-OB16 is a standard electronic module.
Module Type: Both are 16-channel sinking/sourcing (sourcing output) DC modules.
Protection:
1746-OB16E: Features electronic protection that detects short-circuit and overload conditions, designed to protect the module from damage.
1746-OB16: Standard electronic output module.
Voltage: Both typically operate within a range suitable for 24V DC systems.
Compatibility: Both use the same 1746 chassis and wiring, often with color-coded removable terminal blocks.
