1747-L542
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product image is representative; revision or series may vary. Contact us to request a specific version.
Product Information
Product Describe
PROCESSOR MODULE
SLC 500 SERIES
SLC 5/04
5-24 VDC
32K
1000 MA
200 MA
8192 DIGITIAL I/O MAX
RSLOGIX 500
DH+ AND RS-232
FLASH EEPROM
0.9 MS/K
3/30 LOCAL CHASSIS / MAX SLOTS
SLC 500 SERIES
SLC 5/04
5-24 VDC
32K
1000 MA
200 MA
8192 DIGITIAL I/O MAX
RSLOGIX 500
DH+ AND RS-232
FLASH EEPROM
0.9 MS/K
3/30 LOCAL CHASSIS / MAX SLOTS
Technical specifications for 1747-L542
-
Product Model1747-L542
-
Spare Model1747L542
-
Product ParametersPROCESSOR MODULE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size3.5x13x14.5cm
-
ManufacturerAllen-Bradley
-
Weight0.32 kg
-
Memory (words)32 K
-
I/O capacity,max4096 discrete inputs/4096 discrete outputs
-
Local system,max3 chassis / 30 slots
-
Programminginstructions107
-
Typical scantime0.9 ms/K
-
Bit execution0.37 µs
-
Power supply loading at 5V dc500 mA for the SLC 5/03 processor
-
Program scan hold-up time after loss ofpower20 ms...3 s
-
Ambient temperature rating, operating0...60 °C (32...140 °F)
-
Ambient temperature rating, storage-40...85 °C (-40...185 °F)
-
Humidity5 to 95% without condensation
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the 1747-L542？+The Allen-Bradley 1747-L542 is a 32K memory, SLC 5/04 CPU controller module within the SLC 500 family
-
What 1747-L542 programming software is required?+RSLogix 500 software, version 7.10 or higher, is required to program this processor.
-
Does the 1747-L542 require a battery?+Yes, it uses a battery-backed RAM to retain memory during power outages. It is recommended to replace batteries while the power is on to avoid memory loss, or use a memory module.
-
Is this product brand new?+Yes, AB 1747-L542 is brand new, original, unused, and factory sealed
-
Do you provide warranty as standard?+We provide a full 12-month warranty for the 1747-L542. So, if you have any problems within 12 months from the date of delivery, then you can contact our Team who will be happy to help and explain what your next steps should be.
Get a quick price fo 1747-L542
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Revisions
Revision Part #
Also known as
- What happens next
- Get the quote now Write Email to INFO@AMIKON.CNEmail confirmation You will get an email confirming that we have received your enquiry.Dedicated Account Manager One of our team will be in touch to confirm your part(s) specification and condition.Your quote You will receive a comprehensive quote tailored to your specific needs.Need Moore Help? Get fast and efficient help from our experienced sales or customer service teams.
- Delivery and payment
- Delivery
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from warehouse inventory
Warranty
All parts new original are covered by Amikon 12 month warranty
Returns
No hassle returns policy
Dedicated customer support team
Payment options
We accept Bank transfers and the following methods of payment:
For more information, please visit our dedicated payments page.
- Why Choose Amikon Limited?
When it comes to industrial automation, reliability, speed, and trust matter. At Amikon Limited, we go beyond just supplying parts — we deliver confidence.
- ● Extensive Inventory Reach: Nearly 1 million automation parts at your fingertips, including legacy and obsolete models.
- ● 20+ Years of Expertise: Trusted by engineers, project managers and government companies worldwide for our professional service.
- ● Quality You Can Trust: Each unit is strictly inspected by the warehouse staff to ensure product quality
- ● Fast Global Shipping: We help you minimize downtime with express logistics worldwide.
- ● 1-Year Warranty Available: Peace of mind with every purchase backed by one year warranty guarantee.
Whether you're maintaining legacy systems or building future-ready projects, Amikon Limited is your dependable partner in precision and performance.
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Comparison with Related Models
Features:
- SLC 5/04 Processor
- Up to 32 KB, Battery Backed-RAM
- Data Highway Plus (DH+), RS-232
- 0 to 60 degrees Celsius
The 1747-L542 Allen-Bradley SLC 500 Modular Hardware may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1747-L542 SLC 500 Modular Hardware Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 1747-L542 SLC is an SLC 5/03 controller. This controller is one of the Three (3) controllers under the 1747-L52 SLC 5/03 category. This controller is the mid-range controller of SLC 5/03 which has 32 KB user memory while still capable of handling 4096 Input and outputs.
The 1747-L542 is used with the modular style hardware. This processor is installed to slot Zero (0) of any SLC chassis such as 1746-A2, 1746-A7, 1746-A10 and 1746-A13. It is powered though the power supplied in the backplane, provided by the system power supply installed at the leftmost area of the chassis.
This SLC processor has integrated RS232 and Data Highway Plus (DH+) communication port which allows this processor to be communicated with computer-based control systems such as Human Machine Interface (HMI) or Supervisory Control and Data Acquisition (SCADA). This processor may also be used for messaging or implement pass-through communication for other Allen-Bradley Programable Logic Controller (PLC) such as PLC 5, CompactLogix and ControlLogix platforms.
- Industrial Automation:Controls complex manufacturing & automation tasks
- Motion Control:Applications requiring precise motion control
- Material Handling:Conveyor systems & material movement
- HVAC Control:Heating, ventilation & air conditioning management
- SCADA Systems:DF1 half-duplex for SCADA network management
- Process Control:Small-scale process control & assembly operations
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Compared to 1747-L532 (SLC 5/03): The L542 has larger memory (32K vs 16K) and significantly faster processor speeds. The L542 also supports Data Highway Plus for connecting to older PLC-5 systems, which the 5/03 does not.
Compared to 1747-L552 (SLC 5/05): Both offer 32K of memory, but the 1747-L552 is geared toward modern Ethernet connectivity (10/100 Mbps), while the 1747-L542 is optimized for DH+ networking.
Series Differences (A, B, C): The 1747-L542 has evolved through firmware revisions, such as Series C, which provides improved performance and additional instructions compared to older series.
