Bently Nevada

Upgrade Kit

178850-00Upgrade Kit
Non-approved
Voltage:±12V to ±24V DC
Signal Integrity: Maintains API 670
Operating Temp: –30°C to +65°C (–22°F to +149°F)
Humidity: 0–95% non-condensing

Dual Probe Transducer

Standard Range: 0–500 mils
Extended Options: Up to 1000 mils
Sensitivity:200 mV/mil (7.87 V/mm) ±5% per channel
Voltage Output: –2 V to –18 V DC
Current Output (Optional): 4–20 mA
Linearity:±1% of full scale
Power Supply:–18 V to –24 V DC

VELOMITOR CABLE

VELOMITOR CABLE
4METER
XA INTERCONNECT VARIETY

3300 Proximitor Sensor

Product type : 3300 Proximitor Sensor
Total Length Option : 50 = 5.0 metres (16.4 feet)
Agency Approval Option : 03 = Multiple Approvals
Proximitor® Sensor Material : A383 aluminum.
Operating Temperature : -51°C to +100°C (-60°F to +212°F)
Storage Temperature : -51°C to +100°C (-60°F to +212°F)

3300 35mm Series Proximitor

Continuous, Online Monitoring
Temperature, Pressure, and Overspeed Detection
Vibration and Position Monitoring
Designed for Machine Protection
Versatile, Expandable, and Cost-Effective

Condition Monitoring Board

Dynamic range: 0–10 kHz
Filters: High-pass
Power Supply:+24V DC (±10%), 2A typical
Input Voltage Range:±50V (protected inputs)
A/D Resolution:16-bit (typical)
Sampling Rate:Up to 100 kS/s (per channel)

3300 XL 8 mm Reverse Mount Probes

3300 XL 8 mm Reverse Mount Probes
330105-02-12-CC-DD-EE3/8-24 UNF threads
15 1.5 meter (4.9 feet)
02 Miniature ClickLoc coaxialconnector

3300 Proximitor Sensor

Product type : 3300 Proximitor Sensor
Total Length Option : 9.0 metres (29.5 feet)
Proximitor® Sensor Material : A383 aluminum.
Operating Temperature : -51°C to +100°C (-60°F to +212°F)
Storage Temperature : -51°C to +100°C (-60°F to +212°F)

3300 NSv Proximity Probes

330905  3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 80 mm
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable

991 Thrust Transmitter

991 Thrust Transmitter
50 5.0 meters (16.4 feet)
70 7.0 meters (23.0 feet)
01 35 mm DIN-rail clips
01 CSA Division 2

991 Thrust Transmitter

991 Thrust Transmitter
50 5.0 meters (16.4 feet)
70 7.0 meters (23.0 feet)
01 35 mm DIN-rail clips
05CSA Division 2, ATEX Zone 0
ATEXZone 2 and includes
ABSmaritime approval

3300 XL Proximitor Sensor

3300 XL Proximitor Sensor
11 1.0 meter (3.3 feet) system length
51 5.0 meters (16.4 feet) system length
91 9.0 meters (29.5 feet) system length
05 CSA, ATEX, IECEx  Approvals

3300 XL 25 mm Proximitor Sensor

5 1 5.0 metres (16.4 feet) system
Measurement Range: 1.0 to 3.0 mm
Sensitivity: 7.87 V/mm (200 mV/mil) ±5%
Output Signal: -2V to -18V DC
Frequency Response: 0 to 10 kHz (±1dB)
Linearity: ±1% of full scale
Power Supply: -18V to -24V DC

Accelerometers

12 M8x1.25 Adhesive Stud Mount
00 No Approvals
Broadband ElectricalNoise:350 µg
Output Bias Voltage: 8 to 12 VDC
Excitation Voltage:18 to 28 VDC
Constant CurrentExcitation: 2 to 20 mA

3300 NSv Proximity Probes

330909 3300 NSv Probe
3/8-24 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length:  6.0 in
10 1.0 meter (39 in)
01Miniature coaxial ClickLoc connector
with connector protector, standardcable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330104  3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 80 mm
Minimum case length: 150 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe,
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 5.0 in.
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable

3300 XL Proximitor Sensor

3300 XL Proximitor Sensor
11 1.0 meter (3.3 feet) system length
51 5.0 meters (16.4 feet) system length
91 9.0 meters (29.5 feet) system length
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330103  3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 120 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable

3300 XL 25 mm Extension Cable

3300 XL 25 mm Extension Cable
0 8 0 8.0 metres (26.2 feet)
2 4 High Temperature FluidLoccable

3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 80 mm
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

330910 3300 NSv Probe
M10X1 thread, witharmor
Minimum unthreaded length:60 mm
Maximum length: 250 mm
05 0.5 meter (20 in)
11Miniature coaxial ClickLoc connector
with connector protector, FluidLoccable
00 Not required

3300 NSv Proximity Probes

330910 3300 NSv Probe
M10X1 thread, witharmor
Minimum unthreaded length:30 mm
Maximum length: 200 mm
05 0.5 meter (20 in)
11Miniature coaxial ClickLoc connector
with connector protector, FluidLoccable
00 Not required

990 Vibration Transmitter

04 0-4 mils pp (0-100 μm pp)
50 5.0 meters (16.4 feet)
70 7.0 meters (23.0 feet)
01 35 mm DIN rail clips
01 CSA Division 2

990 Vibration Transmitter

10 0-10 mils pp (0-250 μm pp)
50 5.0 meters (16.4 feet)
70 7.0 meters (23.0 feet)
01 35 mm DIN rail clips
