Bently Nevada

3300 XL 11 mm Extension Cable

080 8.0 meters (26.2 feet)
01 Armored cable
00 Not required

3301300400105
CABLE

330104 3300 XL 8 mm Probe

330104  3300 XL 8 mm Probe
M10 x 1 thread,with armor
Example: 0 8 = 8 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

2174708000
PROXIMITOR PROBE EXTENSION CABLE
8 METER

5 & 8 mm Proximitor Sensor

1874503
PROXIMITOR SENSOR
5 MM / 8 MM
200 MAV/MIL
24 VDC

General Purpose Equipment Monitor

Vibration Variables:±1% of full scale range
3-wire VoltageMode:10 kΩ
Bias Filter:0.09 Hz 1-pole low-pass
OK Filter: 2.4 kHz 1-pole low-pass
BiasVoltage:-24 V

22010301
DISCONTINUED BY MANUFACTURER
MONITOR
4 CHANNEL

Transducer

Recip Cylinder Pressure Monitor

Series: 3500 Series
Standard: 0-5,000 psi (0-345 bar)
Sampling Rate: Up to 100 kHz per channel
ADC Resolution: 16-bit
Power Supply: 24 VDC (±10%)

3300 XL 8mm Proximity Probe

Frequency Response: 0 Hz (DC) to 10 kHz
Noncontacting
Gap-to-Voltage Transducer Systems
Measures Static and Dynamic Distances

3500/60 I/O Module

Analog inputs: 4–20 mA, ±10V
Analog outputs (4–20 mA
Voltage range: ±10V, 0–10V.
Current range: 4–20 mA, 0–20 mA
Digital Inputs:24V DC (±10%)
Relay contacts: 2A @ 30V DC / 250V AC
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 5–95% non-condensing

RTD/Isolated Tip TC I/O Module

Temperature monitoring is available in 16 channels.
Temperature inputs can be RTD or TC
Accepts isolated tip thermocouples,
3-wire or 4-wire RTDs
or a combination of
TC and RTD inputs

Standard Extension Cable

3300 XL 8 mm Probe
M10 x 1 thread
withoutarmor
0 1 Miniature coaxial
ClickLocconnector with connector
0 5 Multiple Approvals

3300 XL Standard Extension Cable

040 4.0 meters (11.5 feet)
01 Armored cables
00 Not required
Voltage Rating:300V AC/DC
Operating Temp:-40°C to +150°C (-40°F to +302°F)
Capacitance:≤ 98 pF/m (30 pF/ft) ±5%
Max. System Length:8 meters

Proximity Probes

3300 XL 8 mm Probe
M10 x 1 thread
without armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

3300 XL 8 mm Proximity

3300 XL 8 mm Probe
M10 x 1 thread,without armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

3300 XL 11 mm Proximity Probes

330709 3300 XL 11 mm Probe
M16 x 1.5 thread,without armor
Minimum length:50 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 1.0 in
Maximum case length: 2.7 in
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 11 mm Proximity Probes

330703 3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 70 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
