PRODUCT DESCRIPTION
External transducer interface module
Bently Nevada 170180-01-00 is an external transducer I/O module. The external I/O module connects two compatible transducers to their respective FieldMonitor monitoring module. It occupies one terminal-base slot and provides the selected sensor interface. It is not a 3500 rack monitor, and the I/O version determines the supported transducer type.
The 01 selection provides two inputs for external Proximitor sensors or accelerometers using a negative twenty-four-volt supply. The final 00 denotes the historical Division 2 or Zone 2 option. Check the delivered marking and applicable installation drawing before hazardous-area use.
The 01 selection provides two inputs for external Proximitor sensors or accelerometers using a negative twenty-four-volt supply. The final 00 denotes the historical Division 2 or Zone 2 option. Check the delivered marking and applicable installation drawing before hazardous-area use.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Where 170180-01-00 Fits Across Industrial Application Areas
Industrial uses span production and utility equipment, subject to verified product compatibility, installation requirements and operating conditions.
-
01 · MINING & MINERALS
Mining Operations and Mineral Processing
Ore crushers and grinding mills at mineral processing plants.Process pumps and conveyors serving mineral processing plant operations. -
02 · METALS & MINING
Steel Production and Metallurgical Plant Utility Equipment
Rolling mills and extraction fans in steel production plants.Coke oven compressors and combustion blowers serving steel plants. -
03 · PULP & PAPER
Pulp Manufacturing and Paper Production
Pulp refiners and process pumps in integrated pulp mills.Paper machine press rolls and winders in papermaking facilities.
Technical specifications for 170180-01-00
-
Product Model170180-01-00
-
Product ParametersExternal transducer interface module
-
In stock1 unit
-
ManufacturerBently Nevada
-
Transducer inputsTwo
-
Input typeExternal Proximitor or -24 Vdc accelerometer
-
Base allocationOne FieldMonitor terminal-base slot
-
Input voltage range0 to -Vt
-
Current excluding transducers2.0 mA maximum
-
Operating temperature-34 to +85 deg C
-
Storage temperature-40 to +85 deg C
-
Humidity limit100% condensing, nonsubmerged, +7 to +85 deg C with protected connector
-
Historical approval selectionDivision 2 / Zone 2, option 00
-
Historical hazardous-area temperature-30 to +70 deg C
-
Applicable approval drawing139255
-
Current-limit setpoint33.6 to 37.6 mA at 25 deg C
View all additional
Alternative Names
170180 01 00
170180-01-00 external transducer I/O module
Bently Nevada 170180-01-00
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
EXTERNAL TRANSDUCER INTERFACE MODULE
Integrating 170180-01-00
The external I/O module connects two compatible transducers to their respective FieldMonitor monitoring module. It occupies one terminal-base slot and provides the selected sensor interface. It is not a 3500 rack monitor, and the I/O version determines the supported transducer type.
Use the corresponding FieldMonitor terminal base and two-channel monitoring module. The 01 Proximitor/accelerometer, 02 two-wire velocity and 03 Velomitor versions are distinct interfaces. A 1701/06 isolator terminal base requires option 05, not this option 00.
Match each field transducer to its documented input type and protect the connector as required. Follow drawing 139255 and the delivered approval conditions. The general operating-temperature range must not override the narrower historical hazardous-area temperature range.
Features:
- Match exact assembly, interface generation, connection and installation instructions
- Follow the applicable installation instructions
- Confirm unverified configuration details
The 170180-01-00 external transducer I/O module requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Replacement of 170180-01-00 requires comparing exact assembly, interface generation, connection and installation instructions. A shared base family or similar appearance does not establish a drop-in replacement for the complete ordered assembly.
Use the corresponding FieldMonitor terminal base and two-channel monitoring module. The 01 Proximitor/accelerometer, 02 two-wire velocity and 03 Velomitor versions are distinct interfaces. A 1701/06 isolator terminal base requires option 05, not this option 00.
No verified exact-order discontinuation date, product revision or designated successor is asserted. Document revisions identify the reference literature, not hardware changes to the supplied product. Unconfirmed replacement options must be resolved before substitution.
Features:
- Preserve the complete ordering identity
- Compare the installed electrical and mechanical interfaces
- Do not infer hardware revisions or successor models
The 170180-01-00 external transducer I/O module requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: No verified product PDF is currently available on this page. Amikong-hosted reference documents will be listed only after their product identity and scope have been checked. Consult the applicable manufacturer instructions before use; additional documents are included only when expressly listed in the quotation.Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the 170180-01-00 external transducer I/O module must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size12.7x2.1x10.5cm
-
Shipping weight0.28 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference9031900090
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 170180-01-00
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
How is 170180-01-00 identified?
The 01 selection provides two inputs for external Proximitor sensors or accelerometers using a negative twenty-four-volt supply. The final 00 denotes the historical Division 2 or Zone 2 option. Check the delivered marking and applicable installation drawing before hazardous-area use. -
What does this component do?
The external I/O module connects two compatible transducers to their respective FieldMonitor monitoring module. It occupies one terminal-base slot and provides the selected sensor interface. It is not a 3500 rack monitor, and the I/O version determines the supported transducer type. -
Which equipment and interfaces must match?
Use the corresponding FieldMonitor terminal base and two-channel monitoring module. The 01 Proximitor/accelerometer, 02 two-wire velocity and 03 Velomitor versions are distinct interfaces. A 1701/06 isolator terminal base requires option 05, not this option 00. -
Where is this product used?
The I/O brings supported proximity or acceleration signals into the corresponding FieldMonitor channels. The matching monitor performs the machinery measurements. -
What matters when installing this component?
Match each field transducer to its documented input type and protect the connector as required. Follow drawing 139255 and the delivered approval conditions. The general operating-temperature range must not override the narrower historical hazardous-area temperature range. -
Does option 00 mean that no hazardous-area approval was requested?
Not for this product family. Its historical ordering table defines 00 as Division 2 / Zone 2. Always use the current delivered marking and applicable controlled drawing; do not decode it using another family table. -
Can option 00 be fitted to a 1701/06 isolator terminal base?
The manufacturer directs users to select option 05 for the 1701/06 isolator terminal base. The option 00 listed here must not be treated as equivalent.
