Technical specifications for 135613-01-01
-
Product Model135613-01-01
-
Product ParametersHigh Temperature Case ExpansionTransducer System
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size26.2x11.8x9cm
-
ManufacturerBently Nevada
-
Weight1.74 kg
-
Linear Range Option25.4 mm (1.0 in) with a 127 mm (5.00)rod
-
Spring OptionWith spring return
-
Input Power+13.5 to +26 Vdcunregulated, 30 mAminimum
-
Voltage+1 to +6 Vdc, all models
-
Output Noise<10 mV
Description
01 25.4 mm (1.0 in) with a 127 mm (5.00)rod
01 With spring return
High Temperature Case Expansion
Transducer Assembly
01 With spring return
High Temperature Case Expansion
Transducer Assembly
Information
Overview
Manuals
Technical notes
Product Applications
Mechanical Mounting & Location
Features:
- LVDT-Based Thermal Growth Measurement
- Weatherproof Protective Housing
- High Temperature Type 4 Design
- Dual Transducer Arrangement Support
- 3500/45 Position Monitor Compatibility
The 135613-01-01 Bently Nevada Case ExpansionTransducer Systems may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 135613-01-01 Case ExpansionTransducer Systems Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 135613 high temperature design is engineered to meet TYPE 4 requirements. The system is typically mounted on the foundation at the opposite end from where the turbine casing is attached to the foundation, providing information about the growth of the machine case relative to the foundation. Case expansion measurements enable operators to determine whether machine conditions are exceeding expected temperature growth differentials and whether the machine casing and rotor grow thermally at nearly the same rate during startup.
- Gas & Steam Turbines: Relays vital casing vibration metrics during rapid thermal and speed transitions
- Centrifugal & Reciprocating Compressors: Insulates delicate sensor telemetry against high-frequency vibration and flow turbulence
- Industrial Pumps & Motors: Identifies localized unbalance, structural misalignment, and early bearing defects
- Fans & Blowers: Collects raw velocity data used for prognostic balancing and structural health validation
- Chemical Processing: Fits environments requiring resistance to aggressive chemical vapors, corrosive oils, and solvents
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Orientation: Mount the protective, weatherproof enclosure onto the machine foundation at the opposite end from where the turbine casing is anchored to the foundation. This ensures you capture the maximum relative thermal growth.Footprint Dimensions: The physical footprint spans 88.9 mm (3.50 in) in height, 117 mm (4.60 in) in width, and 241 mm (9.50 in) in length.Fasteners: Secure the main housing using the four supplied 1/4-20 UNC bolts, flat washers, and lock washers. Mount the base to a clean, flat, vibration-free plate or bracket.
FAQs
-
What is the Bently Nevada 135613-01-01?+The Bently Nevada 135613-01-01 is a high-temperature DC Linear Variable Differential Transformer (LVDT) case expansion transducer designed to monitor thermal growth in heavy-duty machinery.
-
Does this model include an internal spring return?+The standard "-00" suffix version does not feature a spring return, meaning the core must be physically attached to the machine casing to track movement in both directions.I
-
What is the primary function of this transducer?+It measures the absolute thermal growth (case expansion) of a machine casing relative to its foundation. This monitoring prevents mechanical stress, binding, or misalignment as a turbine heats up to operating temperatures.
-
What is the difference between the 135613-01-01 and 135613-01-00?+What is the difference between the 135613-01-01 and 135613-01-00?The final two digits dictate the spring option. The -01 version includes an internal spring return for continuous rod extension, while the -00 (or "-10") designates a model without a spring return.
