Technical specifications for 27465-01
-
Product Model27465-01
-
Product ParametersValve Position Transducer
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size15.2x24.6x5.6cm
-
ManufacturerBently Nevada
-
Weight1.2 kg
-
Linear Range254 mm (10.0 in)
-
ElectricalLinearity0.25% of full-scale
-
Null Voltage0.5% of full-scale, maximum
-
Linearity0.25% of full-scale
-
Null Voltage0.5% of full-scale, maximum
-
Core MaterialNickel-iron
-
Operating Temperature-54°C to +149°C (-65°F to +300°F)
Description
The Bently Nevada 27465-01 is a valve position transducer used in turbine supervisory and industrial control systems to provide continuous feedback of valve stem or actuator position. It is commonly deployed in steam turbine control systems, where accurate valve position information is required for regulating steam flow and maintaining stable turbine operation.
The transducer converts mechanical motion of a valve (linear or rotary depending on installation) into a proportional electrical signal. This signal is transmitted to control systems such as DCS or turbine control platforms, where it is used for real-time monitoring and closed-loop control of valve position.
The transducer converts mechanical motion of a valve (linear or rotary depending on installation) into a proportional electrical signal. This signal is transmitted to control systems such as DCS or turbine control platforms, where it is used for real-time monitoring and closed-loop control of valve position.
Alternative Names
27465-0I
27465-O1
Z7465-01
27465 01
27465 0I
27465 O1
2746501
Information
Overview
Manuals
Application Notes
Product Applications
Insertion Guidelines
Features:
- Valve position feedback for turbine and industrial control systems
- Converts mechanical motion into proportional electrical signal
- Integrates with turbine supervisory instrumentation (TSI) systems
- Compatible with steam turbine governor valve applications
The AC LVDT Valve Position Transducer system must be attached to the 3500/45Position Monitor or the 3300/70 Dual Valve Position Indicator to measure valveposition. The 1-, 2-, and 4-inch models can also measure steam turbine caseexpansion for high temperature applications when used with the 3500/45monitor.The transducer may require a core connecting rod to link up with a flange on thegovernor valve. This rod is made of aluminum and is available in six lengths.
The 27465-01 Bently Nevada Valve Position Transducer may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 27465-01 Valve Position Transducer Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The housing measures 368 mm (14.5 in) in overall length, 343 mm (13.5 in) in body length, and 508 mm (20.0 in) in overall height. Four oval mounting holes, 7.9 mm × 12.7 mm (0.312 in × 0.500 in), are provided for secure attachment. A 1/2-inch NPT conduit fitting is supplied but not factory-installed.
The LVDT delivers 0.25% of full-scale linearity with a maximum null voltage of 0.5% of full-scale. The unit operates over a temperature range of -54°C to +149°C (-65°F to +300°F). The system connects to the 3500/45 Position Monitor or the 3300/70 Dual Valve Position Indicator for signal processing and display.
- Oil/Gas Refineries: Tests eddy current probes tracking turbo-machinery like process compressors and high-pressure pumps.
- Power Generation: Calibrates vibration probes on turbine rotors and differential expansion in gas/steam/hydro plants
- Industrial Manufacturing: Confirms specs on critical rotating elements, mixers, and fluid-film bearing assets
- Marine Automation: Used in service/acceptance testing of shipboard propulsion, automation, and thrusters
- Radial Vibration Loops: Verifies calibration of proximity probes measuring shaft movement and orbit trajectories
- Axial Position Loops: Calibrates sensors tracking static thrust displacement of rotor relative to casing
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Calibration Check: Before physical insertion, ensure the sensor is properly powered and calibrated using the Bently Nevada 3500 Machinery Protection System to verify the electrical zero and span.
Proximity Mounting: Secure the transducer to the mounting bracket so the sensing rod has a straight, frictionless path of travel against the valve stem or machine casing.Spring-Return vs. Free-Floating: If using a spring-return model, ensure the spring provides consistent, unimpeded contact with the moving surface. Thread the unit to the proper gap voltage and mechanically lock it in place with jam nuts.
Technical notes
The 27465-01 is often associated with turbine supervisory instrumentation architectures and may be used in conjunction with Bently Nevada monitoring and control modules. It supports critical functions such as steam admission control, load regulation, and turbine efficiency optimization by providing reliable valve position feedback.
FAQs
-
What is 27465-01?
+The Bently Nevada 27465-01 is a specialized Valve Position Transducer designed for steam turbine governor valves -
What is the primary function of the 27465-01?
+It is a Turbine Supervisory Instrumentation (TSI) component. By measuring the physical position of governor valves, it ensures that your system can monitor steam distribution across individual valves for maximum machine operating efficiency. -
How do you verify and calibrate this sensor?
+Calibration requires performing a static probe curve test by documenting the changes in negative DC gap voltage at precise physical distances from a targeted steel block. A dynamic linearity test can also be executed using a portable vibration calibrator. -
How does the transducer function?
+The assembly contains a reverse-mount proximity probe driven by the eddy current principle. The internal Proximitor sensor emits a radio frequency signal to measure the exact distance between the probe tip and a moving valve component without making physical contact.
