129957-085-310-05
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
3300XL 8MM EXTENSION CORDSET CABLE
8.5 meters, standard mount
75 Ω triaxial, PFA insulated
Gold-plated ClickLoc connectors
8.5 meters, standard mount
75 Ω triaxial, PFA insulated
Gold-plated ClickLoc connectors
Technical specifications for 129957-085-310-05
-
Product Model129957-085-310-05
-
Product Parameters3300 XL 8mm Extension Cable
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size8.8x3.6x7.1cm
-
ManufacturerBently Nevada
-
Weight0.2 kg
-
Characteristic Impedance50 Ω ±2 Ω
-
Capacitance98 pF/m (30 pF/ft)
-
Attenuation< 0.28 dB/m @ 10 MHz
-
Withstand Voltage2 kV AC shield-to-conductor
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is 129957-085-310-05?+The Bently Nevada 129957-085-310-05 is a 3300 XL 8mm Proximity Probe component for high-accuracy static/dynamic vibration displacement measurement
-
What is the function of 129957-085-310-05?+It can be used as a proximity sensor, converting eddy currents, induced voltages into signals that measure displacement, which is crucial for detecting vibrations or changes in position.
-
What systems is it used with?+It is designed for use with the Bently Nevada 3300 XL Proximity Probe system.
-
Is it compatible with older Bently Nevada systems?+Yes, the 3300 XL series is designed with complete interchangeability and is backwards compatible with other non-3300 XL transducer system components.
Get a quick price fo 129957-085-310-05
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Connection & Handling Procedures
Features:
- Armored and Unarmored Options
- Multiple Connector Options
- Complete Interchangeability of Units and Cabling
The 3300 XL probe and extension cable alsoreflect improvements over previous designs. Apatented TipLoc molding method provides amore robust bond between the probe tip andthe probe body. The probe’s cable incorporatesa patented CableLoc design that provides 330N (75 lbf) pull strength to more securely attachthe probe cable and probe tip.
The 129957-085-310-05 Bently Nevada 3300 XL 8mm Proximity Extension Cable may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 129957-085-310-05 3300 XL 8mm Proximity Extension Cable Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Each 3300 XL extension cable includessilicone tape that you can use instead ofconnector protectors. We do not recommendsilicone tape for applications that will exposethe probe-to-extension cable connection toturbine oil.
3300 XL8 mm components are bothelectrically and physically interchangeablewith non-XL 33005 mm and8 mmcomponents. Although the packaging of the3300 XL Proximitor Sensor differs from itspredecessor, its design fits in the same 4-holemounting pattern when used with the 4-holemounting base, and will fit within the samemounting space specifications (whenminimum permissible cable bend radius isobserved).
- Turbines: Includes steam turbines, gas turbines, and hydroelectric turbines
- Compressors: Centrifugal air compressors, process gas compressors, and refrigeration compressors
- Motors: Large industrial electric motors used in heavy processing
- Generators: Large-scale power generators in utility and industrial plants
- Pumps: Critical process pumps in oil, gas, and chemical industries
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Finger-Tight Only: Connect the cable to the probe and the Proximitor Sensor by hand until you hear or feel a "click". Do not use pliers or wrenches, as the maximum recommended torque is only 0.565 N·m (5 in·lb).
Bend Radius: Maintain a minimum bend radius of 25.4 mm (1.0 inch). Kinking or sharp bends can damage the internal coaxial structure and cause signal noise.
Connector Protection: Use connector protectors (or silicone tape in non-oil environments) for every connection to prevent moisture or oil ingress from degrading the signal.
