- 3300 XL 8mm Proximity Transducer
- 330101-00-08-05-02-05
In Stock
Ships by Wednesday, July 15
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330101-00-08-05-02-05
-
Product Model330101-00-08-05-02-05
-
Product Parameters3300 XL 8mm Vibration Sensor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size20.5x22.4x3.3cm
-
ManufacturerBently Nevada
-
Weight0.1 kg
-
Unthreaded Length Option0.0 in
-
Overall Case Length Option0.8 in
-
Total Length Option0.5 meter (1.6 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector standard cable
-
Agency Approval OptionCSA, ATEX, IECEx Approvals
Description
Bently Nevada 330101-00-08-05-02-05 is a 3300 XL 8mm Proximity Probe featuring a 3/8-24UNF thread configuration without armor, designed as a core component of the 3300XL 8mm Proximity Transducer System that delivers the most advanced performance in Bently Nevada's eddy current proximity transducer systems.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
Alternative Names
330101 00 08 05 02 05
33O1O1-OO-O8-O5-O2-O5
330I0I-00-08-05-02-05
330101-00-08-05-02-00
330101-00-08-05-02-CN
330101-00-08-05-02-BR
330101-00-08-05-02-RU
Information
Overview
Manuals
Engineering Considerations
Product Applications
Mechanical Installation & Gapping
Features:
- API 670 Standard Compliance
- Complete Interchangeability & Backward Compatibility
- Improved RFI/EMI Immunity
- SpringLoc Terminal Strips
- Patented TipLoc & CableLoc Design
Bently Nevada 330101-00-08-05-02-05 incorporates a patented TipLoc molding method that provides a more robust bond between the probe tip and the probe body, while the probe's cable incorporates a patented CableLoc design delivering 330N (75 lbf) pull strength to more securely attach the probe cable and probe body.
The 330101-00-08-05-02-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330101-00-08-05-02-05 Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Featuring an 8 mm sensing tip with a nominal 2 mm (80 mils) linear measurement range, the probe delivers exceptional accuracy with a scale factor of 7.87 V/mm (200 mV/mil) and ±5% system accuracy. The eddy-current sensing principle generates a voltage output precisely proportional to the gap distance between the probe tip and a conductive target surface, enabling both static position tracking and dynamic vibration analysis with 0.1 micron resolution. The probe is factory-calibrated for standard AISI 4140 steel targets and requires an initial gap setting of approximately 1.27 mm (50 mils) to achieve the nominal -9 VDC output reference point.
- Power Generation: Used on heavy steam turbine shafts, gas turbines, and large generator sets
- Hydroelectric Facilities: Monitors wide-clearance water and hydroelectric turbine setups
- Oil & Gas Processing: Applied to high-load centrifugal process gas compressors, large multi-stage pumps, and expanders
- Steam and Gas Turbines:Housing temps, fuel valves & oil pressures
- Heavy Manufacturing: Tracks industrial assets like steel rolling mill drives, paper mill rollers, and mining machinery
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Recommended Gap: Set the initial probe gap to 1.27 mm (50 mils).
Target Requirements: The target must be a flat surface with a minimum diameter of 15.2 mm (0.6 in). The recommended minimum shaft diameter is 76.2 mm (3 in).
Case Torque: Do not overtighten the probe. When tightening the probe into a bracket or machine case, adhere strictly to the Bently Nevada case torque limits.
Technical notes
The Bently Nevada 330101-00-08-05-02-05 is a precision-engineered 8 mm eddy-current proximity probe from the industry-leading 3300 XL Proximity Transducer System, manufactured by Bently Nevada (a Baker Hughes business) in the USA. This probe is specifically designed for non-contact vibration monitoring, shaft position measurement, and displacement sensing in critical rotating machinery applications across power generation, oil & gas, petrochemical, and heavy industrial sectors.
FAQs
-
What is the 330101-00-08-05-02-05?
+The Bently Nevada 330101-00-08-05-02-05 is a highly reliable, 3300 XL 8mm proximity probe assembly designed to measure vibration and displacement in critical rotating machinery -
What does this transducer system measure?
+It measures both static (positional) and dynamic (vibration) values in fluid-film bearing machines, large compressor units, gas/steam turbines, and heavy-duty motors. -
Can I replace components without recalibrating?
+Yes. All 3300 XL 8mm components are completely interchangeable. You can swap out a probe, extension cable, or Proximitor sensor without matching individual components or performing bench recalibration -
What is the minimum recommended target size?
+For accurate readings, the minimum diameter of the planar conductive target should be 15.2 mm (0.6 in), and the standard calibration target is AISI 4140 steel.
