Technical specifications for 330103-00-10-10-12-05
-
Product Model330103-00-10-10-12-05
-
Product Parameters3300 XL 8 mm Proximity Probes
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size1.8x1.6x123cm
-
ManufacturerBently Nevada
-
Weight0.06 kg
-
Unthreaded Length Option0 mm
-
Overall Case Length Option10 mm
-
Total Length Option1.0 meter (3.3 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector FluidLoc cable
-
Agency Approval OptionCSA, ATEX, IECEx Approvals
Description
330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 10 mm
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx Approvals
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 10 mm
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx Approvals
Information
Overview
Manuals
Technical notes
Product Applications
Mechanical Installation & Mounting
Features:
- Armored and Unarmored Options
- Multiple Connector Options
- Complete Interchangeability of Units and Cabling
The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components
The 330103-00-10-10-12-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330103-00-10-10-12-05 3300 XL 8 mm Proximity Probes Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL probe and extension cable alsoreflect improvements over previous designs. Apatented TipLoc molding method provides amore robust bond between the probe tip andthe probe body. The probe’s cable incorporatesa patented CableLoc design that provides 330N (75 lbf) pull strength to more securely attachthe probe cable and probe tip.You can also order 3300 XL 8 mm probes andextension cables with an optional FluidLoccable option. This option prevents oil and otherliquids from leaking out of the machine throughthe cable’s interior.
- Centrifugal Air Compressors: High-speed rotating equipment where space for sensors is limited
- Refrigeration Compressors: Specialized industrial cooling units
- Process Gas Compressors: Systems handling various industrial gases; the probe's chemical resistance makes it ideal for these environments
- Turbo Expanders: High-speed turbines used in gas processing
- Electric Motors & Generators: Specifically those with tight internal clearances or small fluid-film bearings
- Pumps & Fans: Centrifugal or positive displacement pumps where mounting between bearing pads is required
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Hole Preparation: The probe uses 3/8-24 UNF threads. Prepare the mounting hole using a 0.332 in (Drill Size) and a Q (Tap Drill Size).
Reverse Mounting: Thread the probe into the machine case or a probe adapter. The maximum thread engagement should not exceed 0.562 inches to prevent the tip from bottoming out.
Gapping: For standard AISI 4140 steel targets, the probe should be gapped at 1.27 mm (50 mils), which is the center of its linear range (-9 Vdc).
Tightening Torque: The recommended torque for the 3/8-24 probe case is 11.3 N·m (100 in·lb).
FAQs
-
What is 330103-00-10-10-12-05 ?+The Bently Nevada 330103-00-10-10-12-05 is a specific configuration of the 3300 XL 8 mm Proximity Probe, used for non-contacting vibration and displacement measurements in industrial machinery.
-
What is the 330103-00-10-10-12-05 ideal gap voltage for this probe?+For the Bently Nevada 3300 XL system, the ideal gap voltage is typically -9.0 VDC, which corresponds to a gap of approximately 1.27 mm (50 mils). The linear range generally falls between -1.0 VDC and -17.0 VDC.
-
Is this probe interchangeable with older models?+Yes. The 3300 XL series is designed to be electrically and mechanically interchangeable with previous non-XL 3300 8 mm systems. However, for best performance, it is recommended to use 3300 XL probes with 3300 XL Proximitor sensors.
-
What is the primary use of the 330103-00-10-10-12-05?+It is designed for non-contacting vibration and displacement measurements in harsh industrial environments, such as monitoring turbines, compressors, and motors.
