Technical specifications for 3500/05-01-01-00-00-01
-
Product Model3500/05-01-01-00-00-01
-
Spare Model3500/05
-
Product ParametersSystem Rack
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size48.4x27x26.7cm
-
ManufacturerBently Nevada
-
Weight6.55 kg
-
Rack Size19-inch Rack (14 module slots)
-
Mounting OptionsPanel Mount Option, Full-Size Rack
-
Agency Approval OptionNone
-
ReservedNone
-
European Compliance OptionCE
Description
Full-size rack
01 19-inch Rack (14 module slots)
00 None
00 None
01 CE
01 19-inch Rack (14 module slots)
00 None
00 None
01 CE
Information
Overview
Manuals
Technical notes
Product Applications
Full-Size Rack and Mini-Rack Functional Differences
Features:
- Full-Size Rack and Mini-Rack
- Panel Mount, Rack Mount, and Bulkhead Mount
- 7 or 14 Rack Postitions
- Holds All 3500 Monitor Modules and Rack Power Supplies
Use the 3500 System rack to mount all 3500 monitor modulesand power supplies. The rack allows you to place 3500modules near one another, enabling them to easilycommunicate, and to mount power supplies necessary todistribute power to each module.
The 3500/05-01-01-00-00-01 Bently Nevada 19-inch Rack may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 3500/05-01-01-00-00-01 19-inch Rack Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
This rack format mounts to rectangular cutouts in panels, and secures to the panel using clampssupplied with the rack. Wiring connections and I/O modulesare accessible from the rear of the rack.
This rack format mounts the 3500 Rack on 19-inch EIA rails. Wiring connections and I/O modules areaccessible from the rear of the rack
This rack format mounts the rack against awall or panel when it is not possible to access the rear of therack. Wiring connections and I/O modules are accessiblefrom the front of the rack. The 3500/05 Mini-Rack is notavailable in this format.
The power supplies and rack interface module must occupythe far-left rack positions. The remaining 14 rack positions(seven rack positions for the mini-rack) are available for anycombination of modules.
- Oil & Gas: Production, refining, and hydrocarbon treatment.
- Power Generation: Thermal, hydropower, and wind energy facilities.
- Heavy Manufacturing: Pulp and paper, mining, and water/wastewater treatment.
- Maritime & Offshore: Approved by bodies like ABS and DNV GL for use on ships and offshore units.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Mounting Restrictions: Unlike the Full-Size Rack, the Mini-Rack cannot be bulkhead mounted. If you need to install a Mini-Rack into a standard 19-inch EIA rail, you must use an EIA Adapter Panel (Part #144863-01).
Expansion Limits: Both racks reserve the two leftmost positions for Power Supplies (3500/15) and the Transient Data Interface (3500/22M). Because the Mini-Rack has only 7 remaining slots, it is strictly for smaller machinery trains that do not require extensive monitoring modules.
Hardware Compatibility: The Mini-Rack is incompatible with the 3500/93 System Face Mount display and the 3500/06 weatherproof housing.
Internal Barriers: If you use internal barriers in either rack, a dedicated slot is required for the 3500/04-01 Internal Barrier Earthing Module to provide the necessary IS Earth connection.
FAQs
-
What is 3500/05-01-01-00-00-01?
+The Bently Nevada 3500/05-01-01-00-00-01 is a 19-inch Full-Size System Rack (14 slots) designed for machinery condition monitoring, featuring panel-mount capability and CE compliance. -
What is the capacity of the 19-inch rack?
+It has 14 usable slots for monitoring modules, plus dedicated slots on the far left for two power supplies and a Rack Interface Module (RIM). -
What is the difference between the full-size and mini-rack?
+The full-size rack offers 14 slots, while the mini-rack (12-inch) offers 7 slots. -
Where are the wiring connections located?
+For the Panel Mount (01) and Rack Mount (02) formats, wiring and I/O modules are accessed from the rear of the rack. -
What software is required for configuration?
+Configuration is typically performed using the 3500/01 Rack Configuration Software, which is Windows-based.
