PRODUCT DESCRIPTION
Sixteen channel temperature monitor
Bently Nevada 3500/65 145988-02 is a temperature monitor. The monitor conditions sixteen temperature channels and compares readings with user-configured alarm setpoints. It accepts supported RTDs and isolated-tip thermocouples with the matching I/O. Sensor type, lead arrangement and firmware must agree with the complete installed configuration.
The manufacturer identifies 145988-02 as the 3500/65 temperature monitor. Confirm the installed I/O revision and firmware before replacement. Four-wire RTD applications require the documented modification; do not assume it is present on an unspecified spare.
The manufacturer identifies 145988-02 as the 3500/65 temperature monitor. Confirm the installed I/O revision and firmware before replacement. Four-wire RTD applications require the documented modification; do not assume it is present on an unspecified spare.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Applications for 3500/65 temperature monitoring system
These applications describe manufacturer-documented family use. They do not establish that this exact ordering code was installed at a named customer site.
-
01 · TEMPERATURE CHANNELS
Multi-point machinery temperature monitoring
The manufacturer documents sixteen temperature channels from supported RTDs and isolated-tip thermocouples. Each channel must match the connected sensor and permitted temperature range. -
02 · MIXED SENSORS
RTD and thermocouple configurations
The monitor can use RTD and isolated-tip thermocouple inputs together. Select the correct wiring, termination arrangement and any required four-wire RTD modification. -
03 · REDUNDANT TEMPERATURE
Three-monitor TMR groups
The documented TMR arrangement uses groups of three adjacent temperature monitors. A spare I/O or single monitor alone does not establish that redundant configuration.
Technical specifications for 3500/65 145988-02
-
Product Model3500/65 145988-02
-
Spare Model145988-02
-
Product ParametersSixteen channel temperature monitor
-
In stock9 units
-
ManufacturerBently Nevada
-
Channel capacity16
-
Nominal power consumption3 W
-
Lead input impedanceGreater than 1 Mohm
-
Input familiesRTD or isolated-tip thermocouple
-
RTD wiringThree-wire or four-wire; correct I/O modification required
-
RTD current source913 +/-7 microampere at 25 C per transducer
-
Temperature resolution1 deg C or 1 deg F
-
Temperature accuracy at 25 C+/-3 deg C
-
Cold-junction sensor accuracy+/-2 deg C at 25 C
-
Alarm setpointsUnder/over Alert and Danger
-
Alert delay1-60 s, 1 s increments
-
Danger delay1-60 s, 0.5 s increments
-
Operating temperature-30 to +65 deg C
-
Storage temperature-40 to +85 deg C
-
Rack locationOne full-height front slot
View all additional
Alternative Names
3500/65 145988 02
3500/65 145988-02 temperature monitor
Bently Nevada 3500/65 145988-02
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SIXTEEN CHANNEL TEMPERATURE MONITOR
Integrating 3500/65 145988-02
The monitor conditions sixteen temperature channels and compares readings with user-configured alarm setpoints. It accepts supported RTDs and isolated-tip thermocouples with the matching I/O. Sensor type, lead arrangement and firmware must agree with the complete installed configuration.
The 3500/65 requires compatible 3500/22 firmware and configuration software; 3500/02 and 3500/03 software are not supported. For four-wire RTDs, the manufacturer specifies I/O modification 179952-01. External blocks cannot be used with internal-termination I/O.
Follow user guide 172931 for the selected RTD or isolated-tip thermocouple. When replacing with 172109-01 Rev D, 172103-01 Rev F, 172115-01 Rev E or later, update the monitor firmware as instructed and remove the I/O before the firmware upgrade.
Features:
- Match monitor generation, matched front and rear assemblies, wiring and software
- Follow the applicable installation instructions
- Confirm unverified configuration details
The 3500/65 145988-02 temperature monitor requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Replacement of 3500/65 145988-02 requires comparing monitor generation, matched front and rear assemblies, wiring and software. A shared base family or similar appearance does not establish a drop-in replacement for the complete ordered assembly.
The 3500/65 requires compatible 3500/22 firmware and configuration software; 3500/02 and 3500/03 software are not supported. For four-wire RTDs, the manufacturer specifies I/O modification 179952-01. External blocks cannot be used with internal-termination I/O.
No verified exact-order discontinuation date, product revision or designated successor is asserted. Document revisions identify the reference literature, not hardware changes to the supplied product. Unconfirmed replacement options must be resolved before substitution.
Features:
- Preserve the complete ordering identity
- Compare the installed electrical and mechanical interfaces
- Do not infer hardware revisions or successor models
The 3500/65 145988-02 temperature monitor requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: No verified product PDF is currently available on this page. Amikong-hosted reference documents will be listed only after their product identity and scope have been checked. Consult the applicable manufacturer instructions before use; additional documents are included only when expressly listed in the quotation.Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the 3500/65 145988-02 temperature monitor must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size2.5x25.2x24cm
-
Shipping weight0.75 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference9031900090
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 3500/65 145988-02
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
How is 3500/65 145988-02 identified?
The manufacturer identifies 145988-02 as the 3500/65 temperature monitor. Confirm the installed I/O revision and firmware before replacement. Four-wire RTD applications require the documented modification; do not assume it is present on an unspecified spare. -
What is the function of this component?
The monitor conditions sixteen temperature channels and compares readings with user-configured alarm setpoints. It accepts supported RTDs and isolated-tip thermocouples with the matching I/O. Sensor type, lead arrangement and firmware must agree with the complete installed configuration. -
Which installed equipment must be matched?
The 3500/65 requires compatible 3500/22 firmware and configuration software; 3500/02 and 3500/03 software are not supported. For four-wire RTDs, the manufacturer specifies I/O modification 179952-01. External blocks cannot be used with internal-termination I/O. -
Where is this component used?
The manufacturer documents sixteen temperature channels from supported RTDs and isolated-tip thermocouples. Each channel must match the connected sensor and permitted temperature range. -
What must be checked during installation?
Follow user guide 172931 for the selected RTD or isolated-tip thermocouple. When replacing with 172109-01 Rev D, 172103-01 Rev F, 172115-01 Rev E or later, update the monitor firmware as instructed and remove the I/O before the firmware upgrade. -
Why can a new I/O cause Mismatch or 562 ADC Failure?
The manufacturer warns that the listed newer I/O and block revisions require updated monitor firmware. Follow its sequence, including removing the I/O module before upgrading; verify the actual revisions against user guide 172931. -
Can every 3500/65 I/O be assumed ready for four-wire RTDs?
No. The ordering instructions specifically call for modification 179952-01 for four-wire RTD use. Confirm the delivered configuration instead of inferring that modification from the base spare number.
