PRODUCT DESCRIPTION
Axial position loop transmitter
Bently Nevada 991-06-70-02-05 is a thrust position transmitter associated with the 991 transmitter family. It converts axial shaft position from a compatible proximity transducer into a two-wire current-loop signal. Internal signal conditioning supports connection to a control system without a separate external Proximitor Sensor.
This order selects a 0.6-0-0.6 mm position range, seven-metre transducer system and bulkhead mounting. Check the delivered approval marking and matching NSv probe arrangement; external zero and span controls must be set for the installation.
This order selects a 0.6-0-0.6 mm position range, seven-metre transducer system and bulkhead mounting. Check the delivered approval marking and matching NSv probe arrangement; external zero and span controls must be set for the installation.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Applications for 991 transmitter family
These applications describe manufacturer-documented family use. They do not establish that this exact ordering code was installed at a named customer site.
-
01 · COMPRESSOR MONITORING
Compressor thrust position
The loop signal provides axial position information to the compressor control system. Verify the complete 991-06-70-02-05 configuration for the installed system. -
02 · PUMP SUPERVISION
Pump axial movement
A compatible NSv sensing chain supplies a continuous position signal for the control-system input. Verify the complete 991-06-70-02-05 configuration for the installed system. -
03 · MACHINE CONTROL
Small machine monitoring channels
The manufacturer documents use with small motors and fans; select the appropriate conductive target, sensing chain and control-system interpretation. Verify the complete 991-06-70-02-05 configuration for the installed system.
Technical specifications for 991-06-70-02-05
-
Product Model991-06-70-02-05
-
Spare Model991
-
Product ParametersAxial position loop transmitter
-
In stock4 units
-
ManufacturerBently Nevada
-
Full-scale range0.6-0-0.6 mm
-
Transducer system length7.0 m
-
Mounting hardwareBulkhead screws
-
Approval option05; verify delivered certification
-
Measurement output4-20 mA two-wire current loop
-
Terminal supply+12 to +35 VDC
-
Maximum loop resistance1000 ohm at 35 VDC
-
Typical current limit23 mA
-
Not-OK outputLess than 3.6 mA
-
Buffered probe outputPROX OUT; not electrically isolated
-
Signal conditioningInternal Proximitor circuitry
-
Compatible sensing family3300 NSv; matched system length required
-
Operating temperature-35 to +85 deg C
-
Storage temperature-51 to +100 deg C
-
Calibration adjustmentsIndependent zero and span potentiometers
View all additional
Alternative Names
991 06 70 02 05
991-06-70-02-05 thrust position transmitter
Bently Nevada 991-06-70-02-05
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
AXIAL POSITION LOOP TRANSMITTER
Integrating 991-06-70-02-05
It converts axial shaft position from a compatible proximity transducer into a two-wire current-loop signal. Internal signal conditioning supports connection to a control system without a separate external Proximitor Sensor.
Match the NSv probe and any extension cable to the transmitter system-length setting. The loop output is a process signal, not a complete machinery-protection rack; compare measurement type and range before substitution.
Verify loop supply and load together. PROX OUT is not isolated from the measuring circuit; use the documented 122115-01 test adapter when connecting grounded AC-powered test equipment to avoid disturbing the signal.
Features:
- Match complete order, mounting, connections and environmental limits
- Follow the applicable installation instructions
- Confirm unverified configuration details
The 991-06-70-02-05 thrust position transmitter requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Replacement of 991-06-70-02-05 requires comparing complete order, mounting, connections and environmental limits. A shared base family or similar appearance does not establish a drop-in replacement for the complete ordered assembly.
Match the NSv probe and any extension cable to the transmitter system-length setting. The loop output is a process signal, not a complete machinery-protection rack; compare measurement type and range before substitution.
No verified exact-order discontinuation date, product revision or designated successor is asserted. Document revisions identify the reference literature, not hardware changes to the supplied product. Unconfirmed replacement options must be resolved before substitution.
Features:
- Preserve the complete ordering identity
- Compare the installed electrical and mechanical interfaces
- Do not infer hardware revisions or successor models
The 991-06-70-02-05 thrust position transmitter requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.
Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the 991-06-70-02-05 thrust position transmitter must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size10x7.4x6 cm
-
Shipping weight0.5 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference9031809090
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 991-06-70-02-05
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
What is 991-06-70-02-05?
It converts axial shaft position from a compatible proximity transducer into a two-wire current-loop signal. Internal signal conditioning supports connection to a control system without a separate external Proximitor Sensor. -
Which options identify this 991 configuration?
This order selects a 0.6-0-0.6 mm position range, seven-metre transducer system and bulkhead mounting. Check the delivered approval marking and matching NSv probe arrangement; external zero and span controls must be set for the installation. -
Which system compatibility checks are required?
Match the NSv probe and any extension cable to the transmitter system-length setting. The loop output is a process signal, not a complete machinery-protection rack; compare measurement type and range before substitution. -
Where is the documented product family applied?
A compatible NSv sensing chain supplies a continuous position signal for the control-system input. -
What installation precautions apply to this configuration?
Verify loop supply and load together. PROX OUT is not isolated from the measuring circuit; use the documented 122115-01 test adapter when connecting grounded AC-powered test equipment to avoid disturbing the signal. -
Can a similar part number be substituted directly?
No. Compare complete order, mounting, connections and environmental limits. Match the NSv probe and any extension cable to the transmitter system-length setting. The loop output is a process signal, not a complete machinery-protection rack; compare measurement type and range before substitution. -
Are hardware revisions or a direct successor confirmed?
No exact-order hardware revision, discontinuation date or manufacturer-designated successor has been verified. The reference document revision is not the supplied product hardware revision.
