Technical specifications for WDP3-014.0801
-
Product ModelWDP3-014.0801
-
Product ParametersSTEPPER DRIVE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size5.3x25.3x29.8cm
-
ManufacturerBerger Lahr
-
Weight3.5 kg
-
Supply voltage20 VDC to 30 VDC
-
Power consumption1 A max
-
Ripple voltage< 2 Vpp
-
WDP3-0140.1 A to 2.5 A
-
No. of steps1000 steps per revolution
-
Pulse ratemaximum 40 kHz
-
Motor voltage3 x 325 VDC
-
Signal voltage Uhigh15 VDC to 30 VDC
-
Signal voltage Ulow< 5 VDC
-
Input current at24 VDC 7 mA
Description
STEPPER DRIVE
WDP3 SERIES
3 PHASE
MAINS: 230...240 V 2.0A / 115V 3.6A / 50..60 HZ
PROFIBUS DP INTERFACE
WDP3 SERIES
3 PHASE
MAINS: 230...240 V 2.0A / 115V 3.6A / 50..60 HZ
PROFIBUS DP INTERFACE
Information
Overview
Manuals
Technical notes
Product Applications
Electrical Connections
Features:
- Controls WDP3-014 Motors of Type Size 90
- Controls WDP3-018 Motors of Type Size 110
- One Unit is Used for Controlling One Axis
The WDP3-014.0801 Berger Lahr STEPPER DRIVE may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Berger Lahr WDP3-014.0801 STEPPER DRIVE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
When replacing a WDM3 product with an SD3 product the existing motor cable canbe used. The motor cable will connect to the SD3 drive via terminal screws so inmost cases it will not be necessary to purchase a replacement motor cable.Please refer to the SD3 product catalogue for motor cable information in the eventthat your existing motor cable is damaged or needs to be replaced.You can review SD3 catalogue for detailed information on the complete SD3 productoffering including motor cables and other accessories.
- Automated Assembly & Robotics:Pick-and-place & multi-axis gantry robotics
- Packaging & Labeling:High-speed sync labeling/conveyor motion for food/pharma
- Metalworking & Machine Shops:CNC milling/grinding/drilling for industrial parts
- Laboratory & Analytical Facilities:Precision positioning for medical devices/analytical instruments
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Mains Connection: Connect to either 115 VAC or 230 VAC. You must set the selector switch to the correct voltage before powering on the device.
Motor Connection: Uses a dedicated 3-phase motor connector for size 90 stepper motors.
Bleed Resistor: If your application involves high braking energy (deceleration), an external bleed resistor should be connected to the base panel.
Signal Interface: Used for signal inputs/outputs, including pulse/direction or gate/enable signals (typically 5V or 24V levels depending on the specific revision).
FAQs
-
What is the WDP3-014.0801?
+It is a positioning controller for 3-phase stepping motors, often used with VRDM 39xx/50 LWB motors. -
hat is the voltage rating?
+The unit is designed for a rated motor voltage of 325 V. -
What are the primary power and signal requirements?
+The unit typically operates on a mains voltage of 220-240V AC (50/60 Hz) and uses a 24V signal voltage. It has a current rating of approximately 2A to 3.6A depending on the specific configuration. -
What is the difference between the WDP3-014 and WDP3-018?
+The main difference lies in their power ratings, with the WDP3-014 being the lower-power version designed for smaller motors (size 90 vs. size 110 for the 018).
