General Electric

Discrete output module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL940
Product Description:Relay output module
Description:Relay Output Module
Response time:15 ms
Product Lifecycle Status:Active
No. of channels:Eight (8)
No. of groups:Four (4)
Switching current:2.0 Amps
No. of channels per group:Four (4)
Output voltage, range:5 - 30 VDC; 5 - 250VAC (50/60 Hz);
Max. Backplane Draw:135 Milliamps
Rated voltage:24 VDC; 120/240 VAC
Inrush Rating:5.0 Amps
Max. Response Time:15 Milliseconds
Minimum load:10 mA
Location:PacSystems PLC I/O Slots
Maximum inrush:5:00 AM

Thermocouple Input Board

Voltage: 24 V DC ±10%
Consumption: ≤15 W (typical)
Channel-to-Channel: ≥250 V AC
Field-to-System: 1500 V AC
Signal Range: -200°C to +1800°C

ETHERNET CONNECTION BOARD

PC BOARD ASSEMBLY
ETHERNET CONNECTION BOARD
CONTROLLER WITH 2 IS BUS CHANNELS
MARK VI

Discrete Input Pack

Channels:16x isolated
Voltage Range:24-125V DC
Current Rating:5mA (min)
Isolation:1500V AC
Power Supply:24V DC (±10%) from backplane
Power Consumption:6W (typical)
Response Time:<1ms (input), <0.5ms (output)
Contact Rating:50,000 operations @ rated load

Vibration Transducer Interface Module

Series: Mark VI
Product Type: Vibration Transducer Interface Module
Board rating: 125 V dc
Common Mode Voltage Range: ±5 V
Dimensions: 11.00 x 9.00 x 3.00
Operating temperature: 0 to 60 °C
No.of Analog Voltage Inputs: 6

Relay Output Terminal Board

Product Type: Relay Output Terminal Board
Number of channels: 16
Relay Type: SPDT
Relay Contact Rating: 10A
Input Voltage Range: 12V, 24V
Number of Relay Channels: 4, 8
Relay Switching Current: Max 10A
Mounting Type: DIN rail
Output Resolution: 12-bit
Output Impedance: 10 Ohm
Analog outputs: 0-20 mA

MICRO EXPANSION UNIT

IC200UEX211
MICRO EXPANSION UNIT
VERSAMAX
28 POINT
16 INPUTS AT 24 VDC
12 RELAY OUTPUTS
120/240 VAC POWER SUPPLY

Ethernet interface module

Compatible:System RX7i system
Part Number:IC698ETM001
Series:Rx7i PACsystem
Brand:GE Fanuc
Speed:200 MHz
Voltage:5 Volts DC
Current:1.2 Amperes
Connector:10 Base T/100 Base Tx, RJ 45
Maximum Number of IP Addresses:One

CPU MODULE

Brand:GE Fanuc
Series:Versamax
Part Number:IC200CPU005
Description:CPU module
Serial Ports:RS 232, RS 485
I/O:2048 points
Boolean Execution Time:0.8 m sec/k

PROFIBUS Slave Module

Series:RX3i PacSystem
Part Number:IC695PBS301
Product Line:RX3i
Catalog:IC695
Product Type:PROFIBUS Slave Module
Backplane Support:Universal
Number of Slots:1 (single slot)
Ports:9-pin connector
Backplane Compatibility:RX3i PCI

Relay Output module

Series:Series 90-70
Manufacturer:GE Fanuc
Part number:IC697MDL940
Current draw:750 mA
Switching frequency:20 Cycles per minute
Response time:10 ms
Number of outputs:16
No. of groups:Two (2) Groups of Form A
No of Channels:Sixteen (16) Relay outputs
Required current:750 milliAmps
Minimum load:10 mA
Isolation voltage:1500 Volts

FEEDBACK I/O PACK

POWER DISTRIBUTION SYSTEM
FEEDBACK I/O PACK
PDM DIAGNOSTICS TYPE
FOR MARK VIE
TURBINE CONTROL SYSTEMS
AMBIENT TEMPERATURE:
-30 TO 65 DEGREES C

Profinet network interface unit

Series:Versamax
Manufacturer:Emerson Automation / GE Fanuc (former)
Part Number:IC200PNS001
Series:VersaMax
Part Number:IC200PNS001
Power Consumption:0.60 Amperes at 5 Volts DC
Product type:Remote I/O Profinet Network Interface Unit
Supported protocol:PROFINET version Version 2.2 Class A IO-Device
Proficy Machine Edition Version Required:Version 7.0 or later
Supported topologies:Linear, Star, Ring (redundant)
No. of Ports:Two (2) RJ45ports
Mounting:DIN Rail

Profibus DP Slave Module

PROFIBUS DP SLAVE MODULE
SERIES 90-30
2 COMMUNICATION PORTS

Serial Communications Module

Series:PACSystem RX3i
Manufacturer:Emerson Automation
Part Number:IC695CMM004
Product Type:Communications module
No of ports:Two (2) RS232 / RS422 / RS485
Serial Ports:4
Physical Interface:RJ-45
Connectors:RJ45
Supported Configurations:RS-232, RS-422/485
No. of installations per rack:Up to Six (6) modules
Baud Rates:1200 baud to 115.2 kilobaud
Status LED indicators:Module OK, Port Fault, Port Status
Current rating:0.7 mA at 3.3 VDC, 0.150 mA at 5 VDC
Operating Temperature:0 to 60 degrees Celsius
Parity:Even, odd, none
Data bits:7, 8
Stop bits:1, 2

Accessory module

Brand:GE Fanuc
Series:RX3i PacSystem
Part Number:IC695ACC412
Description:Cap Pack
Compatibility:RX3i

CABLE

Series:RX3i PacSystem
Part Number:IC695CBL001
Compatibility:PACSystems RX3i
Cable Type:Energy pack cable
Type of Input/Output:Analog
Termination Resistor:Yes

Output Module

Brand:GE Intelligent Platforms/GE Fanuc
Series:Series 90-70
Part Number:IC697MDL340
Product Type:Output Module
Rated Voltage:120 V AC
Outputs:16
DC Power:No
AC Power:Yes
LED Indicators:Yes

Universal analog input module

Series:PACSystem RX3i
Manufacturer:Emerson Automation
Part Number:IC695ALG600
Module Type:Universal Analog
No of Channels:Eight (8)
Number of Inputs:8 general purpose
No. of groups:Two (2)
Cold Junction Compensation:2 channels
No. of channels per group:Four (4)
Power Dissapation:5.4W max
Humidity:5 to 95%, non-condensing
Module conversion method:Sigma-delta
Module resolution:11-16 Bits
Internal Power:3.3V: 350mA; 5V: 400 mA

printed circuit board

Input Voltage: 24V DC
Operating Temperature: Typically between -30°C to +65°C
Humidity: Typically 0-95% (non-condensing)

PACSystems RX3i Power Supply module

Part Number:IC695PSD140
Product Description:Power Supply module
Input voltage range:85 to 264 VAC 100 to 300 VDC
Power Supply:40 Watts
Nominal Rated Voltage:120/240 VAC or 125 VDC
Input Voltage Range:18 to 30 VDC
Input Power:60 Watts maximum at full load
Ripple:150 mV
Output Current:5.1 VDC
Noise:150 mV
Isolation:None
Number of Daisy-Chained PSD140:Up to 4
Terminal Current:6 Amps

NETWORK INTERFACE MODULE

Brand:GE Fanuc
Series:Versamax
Part Number:IC200BEM003
Description:VersaMax master module
Data:3854 input/output
Data Rate:9.6 k baud to 12 M baud
Connector:9 Pin D-sub
Bus Voltage:5 Volts
Slave Devices:125

POWER SUPPLY

POWER SUPPLY
24 VDC
40 WATT
OCCUPIES ONE SLOT ON SYSTEM BASE

I/O MODULE

Brand:GE Fanuc
Series:Genius I-O
Part number:IC660BRD020
Output circuits:16
Circuit type:Source
Weight:1.8 kilograms
Maximum ripple:10%

DS200GDPAG1AEB
DISCONTINUED BY MANUFACTURER
POWER SUPPLY BOARD
HIGH FREQUNCY
25 KHZ
MARK V
