IC660BBD024
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product image is representative; revision or series may vary. Contact us to request a specific version.
Product Information
Product Describe
I/O MODULE
GENIUS BLOCK
SOURCE I/O BLOCK
32 CIRCUIT
12/24 VDC POWER
FOR USE WITH 2/3 WIRE SENSORS
GENIUS BLOCK
SOURCE I/O BLOCK
32 CIRCUIT
12/24 VDC POWER
FOR USE WITH 2/3 WIRE SENSORS
Technical specifications for IC660BBD024
-
Product ModelIC660BBD024
-
Product ParametersI/O MODULE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size9x11x22.4cm
-
ManufacturerGeneral Electric
-
Weight1.44 kg
-
Maximum output current (steady state)0.5 Amps per circuit
-
Input processing time (typical)1.4 ms (plus selectable filter delay)
-
Input filters1, 2, 3, 4, 5, 10, 20, 30, 40, 50, 60, 70, 80, 90, or 100ms
-
Power supply drop out4 ms at 12 Volts, 20 ms at 24 Volts
-
No. of channelsThirty-Two (32); configurable as input / output and output with feedback
-
SeriesGenius Block I/O
-
Input voltage12/24VDC
-
Block output current (total)16 Amps
-
Output turn-on delay0.5 ms, maximum
-
Output DiagnosticsSwitch Fault
-
DescriptionBlock I/O
-
Isolation850 Volts
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
Does the IC660BBD024 able to operate as input or output device?+The IC660BBD024 is a 32-point module that may be configured as input and output or output with feedback.
-
What is the current per point of the module when configured as output device?+The IC660BBD024 is able to deliver 0.5 Ampere per point when configured as output.
-
What is the IC660BBD024?+The GE IC660BBD024 is a 32-circuit DC Source Input/Output (I/O) block belonging to the GE Genius I/O family. It is to interface controllers with devices that either provide or accept binary signals, such as relays, contactors, and proximity switches
-
What are the 32 circuits configured as?+The 32 circuits are highly flexible and can be configured as inputs, outputs, or outputs with feedback, allowing for mixed use.
-
What is the output capacity?+When used as an output, it delivers 0.5 Amperes per point, with a total block output current of 16 Amps.
Get a quick price fo IC660BBD024
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Revisions
Revision Part #
Also known as
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Wiring Requirements
Features:
- Source and Sink versions each operate at nominal 12 to 24 voltsDC
- Sink version is also +5 volt TTL-compatible
- Thirty-two configurable I/O circuits, inputs and outputs can be mixedon block
- Resettable self-protecting circuits
- Software configurable
- Advanced diagnostics
These blocks have 32 identical discrete I/O circuits, each easilyconfigured to be an input, an output, or an output with feedback. Thisflexibility provides maximum design and application efficiency.Each circuit contains built-in protection when used as an output,protecting the driver while allowing short-time surges. It also protectsagainst shorted loads caused by wiring errors.Block LEDs verify proper block operation and CPU communications.Individual circuit LEDs on the logic side indicate voltage present oninputs and outputs
The IC660BBD024 GE I/O Block may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE IC660BBD024 I/O Block Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The IC660BBD024 is a GE Fanuc intelligent Block I/O module. This module is a high-density Thirty-Two (32) point Discrete I/O block that features individually configurable channels as input, output or output with feedback. This module supports Source wiring and provided with resettable self-protecting circuits and advanced diagnostics.
The IC660BBD024 input characteristics include compatibility with 12/24VDC as ON-state signal values. Specifically, for 12VDC, On-state range is 8-12VDc while 18-24VDC for 24VDC On-state. It has an input impedance of 3.3 K Ohms, 1.4 ms input processing time, affected by the configured signal filtering with a wide variety of options such as 1, 2, 3, 4, 5, 10, 20, 30, 40, 50, 60, 70, 80, 90, or 100ms.
When configured as output, each channel is able to deliver 0.5 Ampere with turn-ON delay of 0.5 ms and able to withstand a maximum Inrush current of 4 Amperes for 10 ms that may be repeated once every .5 sec. This block I/O is capable of up to 16 Amperes. Each configured output channel has a voltage drop of 2.0 volts maximum at 4 Amps inrush and capable of detecting switch fault.
- Turbine Control:High-density discrete I/O for Mark I/II turbine controle
- Power Generation:Genius Modular Redundancy for safety-critical plant systems
- Oil & Gas / Hydrocarbon Processing:Remote I/O blocks minimize long wiring to field sensors
- Industrial Automation & Robotics:Proximity/actuator interface for CNC, robots & assembly lines
- Marine Technology:Onboard control & monitoring for shipboard electronics
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Wire Size: Terminal connections should use #12 AWG wire or two #14 AWG wires.
Power Disconnect: For safety, wire the block so that block power and input power are disconnected simultaneously. This prevents the block from powering up unexpectedly during maintenance.
Grounding: The mounting screws must connect to a reliable grounding system to protect both personnel and equipment.
