PRODUCT DESCRIPTION
IS220UCSAH1A Standalone turbine control processor
General Electric IS220UCSAH1A is a UCSA standalone controller in the Mark VIe platform for executing configured turbine and plant-control applications. Its PowerQUICC II Pro processor and Ethernet interfaces support control projects for electricity generation, gas compression and other documented turbine-driven industrial processes.
The controller contains a 667 MHz processor, 256 MB DDR SDRAM and application-dependent CompactFlash storage. Two primary Ethernet ports serve plant and engineering communication, while three IONet ports connect the configured I/O networks. QNX Neutrino provides the real-time operating environment, with ToolboxST supporting configuration and diagnostics; the controller firmware, stored application and network assignments must match the installed system.
The controller contains a 667 MHz processor, 256 MB DDR SDRAM and application-dependent CompactFlash storage. Two primary Ethernet ports serve plant and engineering communication, while three IONet ports connect the configured I/O networks. QNX Neutrino provides the real-time operating environment, with ToolboxST supporting configuration and diagnostics; the controller firmware, stored application and network assignments must match the installed system.
BEFORE YOU BUY
Confirm the complete standalone turbine control processor
ACTUAL APPLICATIONS
Application context for IS220UCSAH1A
IS220UCSAH1A is a standalone Mark VIe turbine controller with a 667 MHz processor and five Ethernet ports. Its documented platform serves power generation, gas compression and hydropower projects. The installed application, firmware and network configuration determine suitability.
-
01 · POWER GENERATION
Electric Power and Turbine Energy Production
Gas Turbine Power GenerationSteam Turbine Power Generation -
02 · OIL & GAS
Natural Gas Processing and Pipeline Transportation
Natural Gas CompressionPipeline Gas Transportation -
03 · HYDROPOWER
Hydroelectric Power and Renewable Energy Production
Hydroelectric Power GenerationRenewable Electric Power Production
Technical specifications for IS220UCSAH1A
-
Product ModelIS220UCSAH1A
-
Product ParametersStandalone turbine control processor
-
In stock6 units
-
ManufacturerGeneral Electric
-
Processor clock667 MHz
-
Processor familyFreescale PowerQUICC II Pro
-
Working memory256 MB DDR SDRAM
-
Supply operating range18–32 V DC
-
Hazardous-location supply rating27.4–28.6 V DC; 28.0 V DC nominal
-
Maximum rated supply current0.62 A DC, HazLoc rating
-
Primary Ethernet ports2
-
IONet ports3
-
Ethernet line rate10/100 Mbps
-
Ethernet connectorsRJ45
-
Operating systemQNX Neutrino
-
Serial setup interface1 RS-232C port
-
Internal regulated supply5 V DC
-
Ambient enclosure design rating0–65 ℃
-
Available CompactFlash capacities128 MB / 2 GB, application dependent
View all additional
Alternative Names
IS220UCSAH1A
Mark VIe UCSA controller
UCSA standalone controller
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM INTEGRATION
Integrate IS220UCSAH1A standalone turbine control processor
General Electric IS220UCSAH1A is a UCSA standalone controller in the Mark VIe platform for executing configured turbine and plant-control applications. Its PowerQUICC II Pro processor and Ethernet interfaces support control projects for electricity generation, gas compression and other documented turbine-driven industrial processes.
Match the documented processor clock (667 MHz) and processor family (Freescale PowerQUICC II Pro) to the installed Mark VIe configuration. Preserve the complete suffix, hardware interfaces and required mating components.
Use the applicable General Electric mounting, connection and commissioning instructions. Save the existing configuration and validate the affected functions before returning the equipment to operation.
Features:
- Processor clock: 667 MHz
- Processor family: Freescale PowerQUICC II Pro
- Working memory: 256 MB DDR SDRAM
The IS220UCSAH1A standalone turbine control processor requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify IS220UCSAH1A standalone turbine control processor
Before exchanging IS220UCSAH1A, verify the complete article identification, installed hardware revision and documented standalone turbine control processor role. Matching appearance alone does not establish interchangeability.
Record the installed Mark VIe connections and settings. Preserve the applicable configuration, application records and diagnostic information before disconnecting the current item.
After installing the verified IS220UCSAH1A, restore the controlled configuration and perform the manufacturer-defined functional checks. Record the completed inspection and test results before release.
Features:
- Processor clock: 667 MHz
- Processor family: Freescale PowerQUICC II Pro
- Working memory: 256 MB DDR SDRAM
The IS220UCSAH1A standalone turbine control processor requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the IS220UCSAH1A standalone turbine control processor must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size3.80 × 15.80 × 20.20 cm
-
Shipping weight0.85kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8537101190
-
OriginUnited States
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about IS220UCSAH1A
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Which processor is fitted in IS220UCSAH1A?
IS220UCSAH1A contains the 667 MHz Freescale PowerQUICC II Pro processor with 256 MB DDR SDRAM. It is distinct from the later UCSB and UCSC processor designs. -
How many Ethernet ports does IS220UCSAH1A provide?
IS220UCSAH1A provides two primary Ethernet interfaces and three IONet interfaces. These use 10/100 Mbps twisted-pair connections with RJ45 connectors. -
Which power ratings apply to IS220UCSAH1A?
The UCSA system guide gives IS220UCSAH1A an 18–32 V DC operating range. For the listed hazardous-location rating, GEH-6725 specifies 27.4–28.6 V DC and 0.62 A maximum; apply the rating required by the actual installation. -
Can any CompactFlash card be installed in IS220UCSAH1A?
IS220UCSAH1A uses application-dependent CompactFlash media. Match the GE media specification, firmware image and installed application; capacity alone does not establish suitability. -
What operating system runs on IS220UCSAH1A?
IS220UCSAH1A uses QNX Neutrino for real-time operation. The controller application and firmware must correspond to the configured Mark VIe project. -
What must be retained when exchanging IS220UCSAH1A?
Record the IS220UCSAH1A network assignments and control configuration. The manufacturer replacement procedure addresses transferring functional CompactFlash media and restoring the approved controller state. -
What details help quote a UCSA replacement?
For IS220UCSAH1A, provide the controller label, quantity, installed Mark VIe redundancy arrangement, firmware and CompactFlash identification, plus the delivery destination. -
How should a delivered IS220UCSAH1A be checked?
Inspect the IS220UCSAH1A model label, five Ethernet connectors, power connection, mounting points and CompactFlash retention before using the manufacturer replacement procedure.
