IC200MDL330
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
IC200MDL330
OUTPUT MODULE
VERSAMAX
DISCRETE
120 VAC
0.5 AMP PER POINT
ISOLATED
16 POINTS
OUTPUT MODULE
VERSAMAX
DISCRETE
120 VAC
0.5 AMP PER POINT
ISOLATED
16 POINTS
Specifications
-
Product ModelIC200MDL330
-
Product ParametersVERSAMAX OUTPUT MODULE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size11x5.8x6.6cm
-
ManufacturerGeneral Electric
-
Weight0.15 kg
-
Output voltage85 to 132 VAC (47 to 63Hz)
-
Output voltage drop2.0V maximum
-
Output leakagecurrentLess than2mA at 132 VAC
-
External power supply85 to 132VAC
-
Current Drawn from BIU power supply140 mA, maximum
-
Number of Outputs16 Discrete Outputs
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the IC200MDL330?+It is a 16-point, 120VAC rated, isolated output module, providing 0.5 Amps per point, belonging to the GE VersaMax Modular I/O series
-
Does it have isolated channels?+Yes, the IC200MDL330 features 16 output channels that are individually isolated, enhancing safety and troubleshooting.
-
What is the backplane current draw?+The maximum backplane current draw is 140 mA.
-
Does the module include output protection?+Yes, it is equipped with built-in snubber and Metal Oxide Varistor (MOV) protection for each output to guard against transients.
-
What is the voltage range for the outputs?+The outputs are rated for 120VAC, providing 0.5 Amp.
Get a quick price fo IC200MDL330
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Revisions
Revision Part #
Also known as
- What Happens Next
-
Get the quote now Write Email to: INFO@AMIKON.CNEmail confirmation You will get an email confirming that we have received your enquiry.Dedicated Account Manager One of our team will be in touch to confirm your part(s) specification and condition.Your quote You will receive a comprehensive quote tailored to your specific needs.Need Moore Help? Get fast and efficient help from our experienced sales or customer service teams.
- Delivery and Payment
-
Delivery
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from warehouse inventory
Warranty
All parts new original are covered by Amikon 12 month warranty
Returns
No hassle returns policy
Dedicated customer support team
Payment options
We accept Bank transfers and the following methods of payment:
For more information, please visit our dedicated payments page.
- Why Choose Amikon Limited?
-
When it comes to industrial automation, reliability, speed, and trust matter. At Amikon Limited, we go beyond just supplying parts — we deliver confidence.
- ● Extensive Inventory Reach: Nearly 1 million automation parts at your fingertips, including legacy and obsolete models.
- ● 20+ Years of Expertise: Trusted by engineers, project managers and government companies worldwide for our professional service.
- ● Quality You Can Trust: Each unit is strictly inspected by the warehouse staff to ensure product quality
- ● Fast Global Shipping: We help you minimize downtime with express logistics worldwide.
- ● 1-Year Warranty Available: Peace of mind with every purchase backed by one year warranty guarantee.
Whether you're maintaining legacy systems or building future-ready projects, Amikon Limited is your dependable partner in precision and performance.
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Installation and Wiring
Features:
- VersaMax I/O and Control System
- Discrete Output Module
- 16 Individually Numbered LEDs and 1 Backplane LED
- less than 2 mA maximum at 132 VAC
In addition, each output provides a maximum output current of 0.5 Amperes and minimum of 10 mA per point. The maximum inrush current generated by each channel is 5.0 Amperes with a duration of 20 ms or one cycle. In addition, the output voltage drop is maximum of 2.0 V while the output leakage current is less than 2 mA at 132 VAC output voltage.
The IC200MDL330 GE Discrete Output Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE IC200MDL330 Discrete Output Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Furthermore, the maximum On and Off response time of each output channel is ½ cycle for both signal transitions. The IC200MDL330 comes with an internal protection circuit that is composed of Snubber circuit which is essentially a resistor and capacitor network and a Metal Oxide Varistor (MOV) on each output of the module. Integrated status indicators include Sixteen (16) LEDs assigned to each of the output, depicting the actuation state of each output channel. In addition, an OK LED is also provided which indicated power being actively received from the backplane. This output module has backplane current draw of 140 mA, maximum.
- Packaging Machinery:Controls AC solenoids for case sealers & labeling heads
- Material Handling & Conveyors:Activates motor starters, relays & status towers on lines
- HVAC & Industrial Pumping:Manages contactors for large fans, pumps & heating elements.
- Assembly Stations:Drives indicator lamps, push-button panels & small AC clamps
- Standard Industrial Tools:Drill presses, arc welders & hydraulic valve control systems
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Wiring: Connect output loads to the terminals. For inductive loads, external suppression circuits are recommended.
Backplane Power: The module requires power from the backplane (5VDC), which increases with the number of points active.
Thermal Management: Consider thermal derating based on ambient temperature, voltage, and mounting orientation to avoid overheating.
