Technical specifications for 3700A
-
Product Model3700A
-
Product ParametersAnalog Input Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size49x45.3x6.8cm
-
ManufacturerInvensys
-
Weight2.85 kg
-
Channels32 differential
-
Ranges0 – 5 V DC
-
Resolution12 bits
-
Accuracy≤ ±0.15 % of full scale
-
Input Impedance> 30 MΩ
-
Surge Protection150 V DC / 115 V AC
-
Operating Temp–40 … +70 °C (rack air)
-
Storage–55 … +85 °C
-
Humidity5 … 95 % RH non-condensing
Description
ANALOG INPUT MODULE
TMR TYPE
0-5 VDC DIFFERENTIAL
DC COUPLED
32-POINT
TMR TYPE
0-5 VDC DIFFERENTIAL
DC COUPLED
32-POINT
Information
Overview
Manuals
Technical notes
Product Applications
Field Wiring and Termination
Features:
- Analog Input Module
- 0-5 VDC
- Differential, DC Coupled
Sensing of each input point isperformed in a manner that prevents asingle failure on one channel from affecting another channel. Each analoginput module sustains complete,ongoing diagnostics for each channel.Failure of any diagnostic on anychannel activates the Fault indicator forthe module, which in turn activates thechassis alarm signal. The module’sFault indicator merely reports a channelfault, not a module failure—the modulecan operate properly with as many astwo faulty channels.
The 3700A TRICONEX Analog Input Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
TRICONEX 3700A Analog Input Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The module accepts 32 differential, DC-coupled analog input channels supporting 0–5 VDC or 0–10 VDC nominal input ranges with +6% overrange tolerance. The DC-coupled architecture (as opposed to the transformer-isolated design of the 3701 module) enables accurate measurement of slowly varying and near-DC process signals without the low-frequency roll-off characteristic of AC-coupled systems. The differential input architecture rejects common-mode noise induced by adjacent power cabling, variable-frequency drives, and electromagnetic interference sources, while the high 10 MΩ input impedance minimizes current draw from high-impedance sensor outputs such as pH probes and ion-selective electrodes. Input impedance is 10 MΩ (DC) typical with 10 MΩ (DC) typical power-off resistance, ensuring that sensor circuits are not loaded down even when the Tricon system is de-energized
- Emergency Shutdown Systems:Monitors reactor/compressor; auto shutdown on upsets
- Fire & Gas Systems:Processes smoke/heat/gas detectors; manages suppression
- Burner Management Systems (BMS):Safe steam boiler/furnace startup/operation/shutdown
- Oil & Gas Production:Upstream, offshore & midstream pipeline management.
- Petrochemical & Chemical Processing:Continuous control for refineries & manufacturing
- Power Generation:Controls turbines, boilers & nuclear plants
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
The 3700A handles 32 high-precision analog input channels. You must route all field sensor signals (such as 4-20mA loops, transmitters, or voltage inputs) through the corresponding External Termination Panel (ETP) rather than wiring them directly to the chassis
2-Wire / 3-Wire Transmitters: Wire your self-powered or loop-powered instruments directly to the ETP terminal blocks.Redundancy Configuration: If configuring a hot-spare for online module replacement, install the second 3700A module into the designated adjacent hot-spare slot.
FAQs
-
What is the 3700A？
+The Triconex 3700A is a 32-point, 0-5 VDC differential Analog Input (AI) module used in the Tricon Triple-Modular Redundant (TMR) safety system -
What is a TMR Analog Input Module?
+It features three isolated, parallel processing channels ("legs"). Each channel receives a variable voltage signal from the field, converts it to a digital value, and transmits it to the main processors. -
Can I replace the module while the system is running?
+Yes. The 3700A supports hot-spare capability, which means you can perform online replacements of a faulty module without shutting down your critical processes. -
What is the resolution and accuracy?
+It features 12-bit resolution and maintains an accuracy of < 0.15% of Full Scale Range (FSR) across 0° to 60°C.
