Technical specifications for 6SE7041-2WL84-1JC0
-
Product Model6SE7041-2WL84-1JC0
-
Product ParametersInverter control board
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size62.2x14.5x3.5cm
-
ManufacturerSiemens
-
Weight0.35 kg
-
DC-Bus Voltage675 – 930 V DC
-
Operating Temperature–25 °C to +60 °C
-
Storage Temperature–40 °C to +85 °C
-
Relative Humidity5 % to 95 % RH, non-condensing
Description
The Siemens 6SE7041-2WL84-1JC0 is an IGD9 Inverter Gating Module used in the SIMOVERT MASTERDRIVES variable frequency drive platform. The module forms part of the inverter control section and is responsible for generating and distributing gate drive signals to the power semiconductor devices within high-power inverter assemblies.
Designed for drive systems operating with DC link voltages from 675 VDC to 930 VDC and current ratings up to 1230 A, the module provides precise gate control required for stable switching of high-power IGBT inverter stages. Its control circuitry ensures synchronized operation between the drive controller and the inverter power section during motor acceleration, speed regulation, torque control, and regenerative operation
Designed for drive systems operating with DC link voltages from 675 VDC to 930 VDC and current ratings up to 1230 A, the module provides precise gate control required for stable switching of high-power IGBT inverter stages. Its control circuitry ensures synchronized operation between the drive controller and the inverter power section during motor acceleration, speed regulation, torque control, and regenerative operation
Information
Overview
Manuals
Application Notes
Product Applications
Connection and Wiring
Features:
- Siemens SIMOVERT MASTERDRIVES spare module
- IGD9 inverter gating module
- Supports DC link voltages from 675–930 VDC
- Rated for inverter systems up to 1230 A
- High-voltage electrical isolation
The module implements an RCD (Resistor-Capacitor-Diode) or RC snubber circuit connected in parallel with the IGBT modules across the DC link. During IGBT turn-off, energy stored in stray inductance of the power circuit generates voltage spikes that can exceed the IGBT breakdown voltage. The snubber circuit absorbs this energy, limiting both the rate of voltage rise (dv/dt) and the peak voltage magnitude to safe levels below the IGBT maximum rating.
The 6SE7041-2WL84-1JC0 SIEMENS Inverter snubber Module SML4 may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6SE7041-2WL84-1JC0 Inverter snubber Module SML4 Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The snubber circuit typically consists of a series resistor and capacitor network, sometimes with an antiparallel diode, designed to present a low-impedance path to high-frequency voltage transients while presenting high impedance to the DC link voltage under steady-state conditions. This selective filtering action clamps voltage spikes without dissipating significant power during normal operation.
Operating temperature is 0°C to +50°C without derating when installed within the drive enclosure. The module is protected by the drive enclosure IP20 rating and relies on the drive's forced air cooling system for thermal management.
- Heavy Manufacturing: Manages large-capacity motors in production lines
- Metal Processing/Mining: Powers heavy-duty conveyors, mills, and rolling equipment drives
- Oil/Gas/Water: Regulates pumps and compressors requiring up to 1230A current
- Material Handling: Controls high-torque applications with precise speed and signal management
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Control Terminals: Route control cables and fiber optic connections (if applicable) through the designated wire channels to prevent electromagnetic interference. Fiber Optic/ ribbon cables: Connect the gating and feedback ribbon cables from the IGD9 board to the corresponding power interface boards (PER/IGD interfaces). Make sure they are seated correctly and locked with the retaining clips. Re-commissioning: Upon powering the drive back up, navigate through the Parameter Menu (via the PMU keypad or DriveMonitor software) to perform initial parameter tuning.
