- 6AV2123-2DB03-0AX0
Warranty Policy
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
Return Notice
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
How to order?
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Parts Availability
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 6AV2123-2DB03-0AX0
-
Product Model6AV2123-2DB03-0AX0
-
Spare ModelKTP400
-
Product ParametersKTP400 Basic Panel
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
Estimated Shipping Size21.3x15.7x4.5cm
-
ManufacturerSiemens
-
Weight0.78 kg
-
Design of displayTFT widescreen display, LED backlighting
-
Horizontal image resolution480 pixel
-
Vertical image resolution272 pixel
-
Type of supply voltageDC
-
Rated value (DC)24 V
-
permissible range, lower limit (DC)19.2 V
-
permissible range, upper limit (DC)28.8 V
-
Current consumption (rated value)125 mA
Description
SIMATIC HMI
KTP400 Basic
Basic Panel, Key/touch operation
4" TFT display,65536 colors
PROFINET interface
configurable from WinCC Basic
V13/ STEP 7Basic V13
KTP400 Basic
Basic Panel, Key/touch operation
4" TFT display,65536 colors
PROFINET interface
configurable from WinCC Basic
V13/ STEP 7Basic V13
Information
Overview
Manuals
Technical notes
Product Applications
Electrical & Power Connections
Features:
- 4.3-Inch TFT Widescreen Display with LED Backlighting
- Combined Key/Touch Operation Interface
- Integrated PROFINET Industrial Ethernet Interface
- 10 MB User Memory & ARM Processor Architecture
- Rugged IP65 Front Protection & Marine Certifications
The 6AV2123-2DB03-0AX0 Siemens Touch Control Panel may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6AV2123-2DB03-0AX0 Touch Control Panel Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The panel features a 4.3-inch TFT widescreen display with a 16:9 aspect ratio, 480 × 272 pixel resolution, and a palette of 65,536 colors for clear, detailed process visualization. LED backlight technology provides uniform illumination with a rated service life of 20,000 hours MTBF at 25°C, and the backlight is fully dimmable to accommodate low-light operating conditions or energy-saving requirements. The analog-resistive touchscreen supports operation with gloved hands, while 4 dedicated function keys offer tactile control for safety-critical or frequently used functions. On-screen alphanumeric and numeric keyboards eliminate the need for external keyboards or mice, minimizing panel clutter and potential contamination ingress points.
- Status Monitoring:Real-time process values, temps, pressures & health
- Parameter Setting:Target variables, setpoints & recipe entry
- Machine-Level Operation:Simple HMI for conveyors, pumps & material handling
- Light Manufacturing:Assembly, pick-and-place & automated testing
- Food & Beverage / Packaging:Product changeovers, fill quantities & belt speeds
- Water/Wastewater:Lift stations & filtration: flow rates & valve states
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Supply Voltage: Requires a 24 V DC power supply (functional range: 19.2 V to 28.8 V DC).
Terminal Block: Connect the power via the supplied 2-pin terminal block. Ensure correct polarity (+ and -).
Grounding: Connect a low-impedance ground wire to the grounding screw terminal on the back of the HMI to protect against electrical noise.
Network: Use a standard RJ45 Ethernet cable to connect the PROFINET port to your PLC (e.g., S7-1200) or network switch.
FAQs
-
What is the 6AV2123-2DB03-0AX0？+The Siemens 6AV2123-2DB03-0AX0 is a SIMATIC HMI KTP400 Basic operator panel for machine-level control and monitoring. It features a 4-inch TFT color display, four programmable function keys, and a combined touchscreen/keypad interface.
-
What software is used to program this HMI?+You can configure the KTP400 Basic using Siemens WinCC Basic
-
What are the key differences between touch and key inputs?+The HMI features an analog-resistive touchscreen alongside 4 tactile function keys. The keys are typically configured for direct, critical operations, while the screen facilitates menu navigation and data entry.
-
What are the key display specifications?+It comes with a 4.3-inch TFT widescreen display supporting 65,536 colors and a resolution of 480 x 272 pixels.
-
What is the required power supply?+It operates on 24 V DC power with a permissible voltage range between 19.2 V and 28.8 V.
